Original Instruction Manual
LED-Driver
E
LED POWER SUPPLY BILTON PSU 60
LED POWER SUPPLY BILTON PSU 100
quantity
1 BILTON LED-Driver
1 Orginal Instruction Manual
CONTENT
DESIGNATED USE
The LED driver feeds LED luminaires LED modules.They are
suitable:
// For the connection to power grids (AC input) and the DC output of
devices which are compatible with the electrical characteristics
of the power supply. (http://www.biltongroup.com/downloads/).
// For indoor use only.
// For service in compliance with the technical data.
The following restrictions apply:
// Never use the power supply for life-saving or life-sustaining
equipment.
// Never use outdoors.
// Never immerse in water or other fluids.
// Dry location use only.
// Protect from spray water.
// Avoid the following ambient conditions:
/ High humidity with risk of water condensation.
/ Permanent vibrations.
/ Strong temperature fluctuations.
CONNECTION OF LED-DRIVER
The connection may occur exclusively through an electrician /
electric expert.
AC input (mains supply):
Power leads min 2x1mm², insert stripped litz wires into terminal
“PRI” 220-240V~
DC output:
Detailed information you will find in the datasheet for each unit.
FOR YOUR SAFETY
SEC + / - LED connection
Read instruction manual
This manual contains information for the safe handling of those
LED drivers / control units which are listed on the front page. It
explains the installation of the mains (AC) and secondary (DC)
adapters.
// Always read the instruction manual first before using the power
supply.
// The instruction manual is part of the product and should always
be at hand.
// The Illustrations in this instruction manualmay di er from the
actual look of the power supply.
Prevent shock-hazard
// Never use a power supply with damagedhousing or cable.
// Never modify a power supply or open itshousing.
// Connect the power supply to a regularinstalled outlet only.
// Protect connectors from moisture.
Prevent property damage
// Never carry the power supply by it selectrical cable or pull at
the cable.
// For separating the connection always pull on the plug, never on
the cable.
// Cables must be installed safely to avoid tripping over.
// Disconnect the power supply during thunderstorms.
NOTICE
Reversed polarity (plus and minus) can damage the connected
LEDs!
/ Double check the polarity before switch-on
In order to solve the connection push down the terminal carefully
with a screw driver and pull out the leads.
MAINTENANCE AND TROUBLESHOOTING
WARNING
Risk of lethal electric shock if fluid leaks into the power supply!
// Disconnect power supply before cleaning.
// Do not use fluids for cleaning.
// Wipe with a dry cloth only.
Do not use chemical cleaning agents.The power supply is main -
tenance-free.In case of a faulty power supply or malfunctions
that cannot be solved, please contact BILTON.
DISPOSAL
Environmental contamination caused by incorrect disposal!
// Cut o le of the power supply and dispose the unit via
the designated take-back system.
TECHNICAL DATA
IP20
AUSTRIA
General
Service temperature -20 … +45 °C
Storage temperature -40 … +70 °C
Humidity <95 %, non- condensing
Protection rating IP20
Protection class II
Electrically
See printing on power supply
BILTON International GmbH
Lofererstrasse 23
5760 Saalfelden / Austria
Tel.: +43 6582 71164
Fax.: +43 6582 71164-10
office@bilton.at
www.BILTON.at
Imprint: BILTON International GmbH // Lofererstrasse 23 //5760 Saalfelden // Austria // +43 6582 71164 // +43 6582 71164-10 // office@bilton.at // www.BILTON.at
Version:July 2016, Errors and omissions excepted.
