BINATONE “

User Guide - Front Page

1)White background and black letters

2)Material: 80lb Book Paper

3) Size: 105mm(w) x 148mm(H) A6

BINATONE “

User Guide - Back Page

USER GUIDE

THIS EQUIPMENT IS NOT DESIGNED FOR

MAKING EMERGENCY TELEPHONE CALLS

WHEN THE POWER FAILS. ALTERNATIVE

ARRANGEMENTS SHOULD BE MADE FOR

ACCESS TO DIAL EMERGENCY SERVICES.

Before operating this set,

please read these instructions carefully.

DIGITAL CORDLESS

TELEPHONE WITH

ANSWERING

MACHINE

Symphony2210 ” Symphony2210 ”

Symphony 2210

er. 071,UK Argos V Nov.

–

Using a tone-dialling phone, dial your home number

You can also use the keys shown on the other side of this card

Press to play back your messages

While your outgoing message is playing, press

Key in your remote PIN (security code)

The default PIN is . To set a new PIN, see the User Guide.

Go back to the

previous message

Delete the message

currently being played

Switch the machine ON

Switch the machine OFF

0000000000000

Play/Stop

Bypass the outgoing

message (OGM)

Skip forward to the

next message

Remote operation

Symphony 2210

Important note — emergency calls

The Symphony 2210 is not designed for making

emergency calls when the mains power fails. So

you should make alternative arrangements for access

to Emergency Services.

(This means that you should also have a basic phone

that does not need mains power, connected to your

line so that you can make calls during a power failure.)

If you need help …

The Binatone Help Line is available from 9.00 am to

5.00 pm, Monday to Friday, on

0845 345 9677

Calls are charged at Local Call rate.

Or visit our website, at:

http://www.binatone .com/

Unpacking your Symphony 2210 system

In the box are:

■the base unit telephone/answering machine

■atelephone line cable for the base unit

■amains power lead and adapter for the base

unit

■the cordless handset (up to five, depending on

which Symphony 2210 system you’ve bought)

■three rechargeable batteries and a battery

compartment cover for each handset

■up to f, each with a separate

mains power lead and adapter, for multi-handset

systems

Keep the packaging materials in a safe place in case

you later need to transport the unit.

Keep your sales (till) receipt, which is your

guarantee.

Color profile: Generic CMYK printer profile

Composite Default screen

charger pods

online

ive

Redial / CDS/ PAUSE button

Press to open a list numbers you called.

Press records.

number to insert a

need this on a PBX).

Where to find it

Ringer Off /

Scroll button

Press and hold for 2seconds

to turn the ringer off.

When viewing a number with

more than 12 digits, press to

scroll back along the display.

R (Recall) button

You may need this if your

phone is connected to a

PBX, or if you use

network-based services.

Press to start using Menu

functions.

PHONE / OK button

Press to begin or answer a

phone call.

When using Menu functions,

press to confirm your selection.

UP and DOWN

Press during programming

Press to move through

Press during a call to

Keypad Lock /MUTE / Scroll button

Press and hold for 2seconds to lock and unlock the keypad.

Press during a call to mute the mouthpiece.

When viewing a number with more than 12

digits, press to scroll forward along the display.

PHONE BOOK button

Press to open the Phone Book.

INT

Press to make an intercom cal .

HANG UP /ON–OFF /C (Cancel) button

Press to end a call.

Press and hold for 3 seconds to switch the handset on or off.

Press while editing or using Menu functions, to cancel what

you’re doing and return the display to Standby mode.

isplay or

lume

CHARGE light(Red)

This comes on when the handset’s

If the handset’s display is blank

Press the button to switch

the handset on

For details of the answering machine

buttons and lights, go to the ‘Answering

machine’ section of this guide (page )

Color profile: Generic CMYK printer profile

Composite Default screen

of the last phone

l,if youhave more than one handset

HANDSET LOCATOR(PAGE)button

Press to make all registered handsets ring(this is usefull if

you've forgotten where you put a handset.)

and hold to open thelist of Caller Display

IN USE light(Green)

Comes on when the handset is in connection with base station.

This blinks when there is new missed call.

button

MENUbutton

buttons

to move through the

menus and options.

the Caller

Redial list.

adjust the v

speakerphone.

in the earpiece or

batteries are being charged.

Press switchthe speakerphone

on or off.

Press while dialling a pause (you might

Symbols on the handset's display

JANny 2

16 25

When this shows ‘nearly empty’ ( ), put the handset on the

base unit or charger pod as soon as possible, to charge the

batteries. While the batteries are being charged, this blinks.

Appears when you have a connection to the outside line.

Flashes when there’s an incoming call to be answered

(even if the ringer is turned off).

The handset’s number(if you have

The current time

The handset’s name

(the default is )

Phone

Book

Ringer off

Comes on when you’re storing numbers in the Phone Book, and

when you’re making calls to stored numbers.

Comes on when the handset’s ringer is turned off.

Radio link/

signal level Th on steadily when there’s a radio link between

the handset and base unit. lashes while the handset is trying

to establish a link . .

e first symbol It f

to the base unit

The second symbol shows the strength of the signal.

If this symbol flashes while

you’re on a call, move closer to the base unit

Battery

charge

level

Phone

New call You have new Caller Display records.

What the symbols mean

Lock Comes on when your handset’s keypad is locked.

Mute Comes on when your handset’s microphone is muted.

Appears when the handset is set to route non-local calls via an

alternative network service provider (using the Prefix code).

Provider

network

Color profile: Generic CMYK printer profile

Composite Default screen

more than one handset on your

TAM Appears when the answering machine function is on.

Flashes when a new message is received.

http://www.binatone .com/ 1

Symphony 2210 system).

BINATONE

pS en

Your handset's loudspeaker on.

online

Contents

… continued overleaf

Color profile: Generic CMYK printer profile

Composite Default screen

Symbols on the handset’s display

Read these notes first

Choosing a site for the base unit

telephone and charger pod, 4

Radio signals between handset and base

unit, 4

Mains power connection, 4

Installation and set-up

Before you start

Electrical safety, 8

Interference, 8

‘Out of range’ warning,

Setting the date and time 10

Your handset's names 1

Ringer melody and volume 12

Base unit ringer, 1

Handset ringer, 1

Making &answering calls

To answer a call, 1

To end a call ,

To page all handsets, 2

Transfer a call, 2

To store names and numbers,

To call a stored number,

To modify (change) a Phone Book entry,

To delete a Phone Book entry,

To delete all Phone Book entries,

To store a number from the Redial list,

Switching on and off

To make a call, 1

Earpiece volume,

Muting the microphone, 1

Last Number Redial, 1

To delete an entry from the Redial list, 1

To delete all entries from the Redial list,15

Using the Phone Book 16

17 17

Caller Display on the handset

Examples of Caller Display records,

To check Caller Display records, 20

To return a call, 20

To delete a Caller Display record, 20

To delete a Caller Display record , 2ll s

To store a number in the Phone Book 21

Using a multi-handset system 22

Intercom call from the handset, 2

Three-way conference, 2

New call tone, 2

Switch on and off, 2

To change answering mode, 2

Outgoing messages ( OGMs), 29

To record a new outgoing messages, 29

To play back the OGM , 30

To record a memo , 30

To play your Messages and Memos , 31

To delete individual messages, 33

To delete all old messages, 33

To activate remote control, 34

To set the Ring delay, 36

Toll saver 37

Binatone Help Line: 0845 345 9677

(Local Call rate)

1414 5

819

Answering machine - Quick Ref 26

Answering machine - Basis use 27

Answering modes, 7

Answering machine - Remote use 34

Remote operation, 34

Answering machine - Advanced use 35

Call screening, 32

Contents

Color profile: Generic CMYK printer profile

Composite Default screen

Handset name, 3

Key tone, 3

Handset registration 42

To register a new handset, 42

To register to a different brand of

base unit,43

To de-register a handset, 43

44Troubleshooting

Cleaning and care

Guarantee and service information

Technical details 51

Declaration of conformity

Connection and conditions for use

You can connect your Symphony 2210 to a direct exchange line (DEL) — a

line connected to a local exchange, with its own phone number; to an

extension socket connected to a DEL; or to an extension on an

approved compatible PBX. Do not connect the Symphony 2210 as an

extension to a payphone.

The ringer equivalence numbers (RENs) of all instruments (phones,

fax machines, etc.) connected to an exchange line must not add up to

more than 4 — otherwise, one or more of them may not ring and/or

answer calls correctly. The Symphony 2210 has a REN of 1, and most other

telephones have a REN of 1 unless marked otherwise.

http://www.binatoneonline.com/ 3

When the memory is full 37

Default settings on TAM 37

38Customisze your phone system

Display language, 38

PIN code, 39

Dial mode, 39

Flash (recall) timing, 40

Default setting, 41

Read these notes first

Before you install your Symphony 2210 —

Choosing a site

for the base

unit telephone

and charger

pod

The base unit and charger pod(s) should be placed on a

level surface, in a position where:

Ithe mains adapter plug will reach an easily accessible

230-V ACswitched mains supply socket — never try

to lengthen the mains power cable

Ithe base unit’s telephone line cable will reach your

telephone line socket or extension socket (the charger

pod does not have a telephone line connection)

Iit is not close to another telephone - this can cause

radio interference

Iit is not close to a sink, bath or shower, or anywhere

else where it might get wet

Iit is not close to other electrical equipment - fridges,

washing machines, microwave ovens, fluorescent

lights, TVs etc.

Radio signals

between

handset and

base unit

To use your cordless handset and base unit together,

you must be able to establish a radio link between

them. Be aware that:

IAny large metal object

or a filing cabinet - between the handset and the

base unit telephone may block the radio signal.

IOther solid structures , like walls, may reduce the

signal strength.

Mains power

connection IMPORTANT

charger pod must be used with the mains adapters

supplied. Using any other adapter will result in non-

compliance with EN60950, and will invalidate any

approval given to this apparatus.

Color profile: Generic CMYK printer profile

Composite Default screen

- like a refrigerator, a mirror

- The Symphony 2210 base unit and

Binatone Help Line: 0845 345 9677

(Local Call rate)

Installation and set-up

Color profile: Generic CMYK printer profile

Composite Default screen

http://www.binatoneonline.com/ 5

Plug the mains adapter into a

230 V AC, 50 Hz mains socket,

with the switch on the socket

set to OFF,the socket-outlet

Plug the mains adapter into a 230 V AC,50Hz

mains socket, with the switch on the socket

set to OFF,the socket-outlet need to be

Install the charger pod(s) …

Connect the mains power

lead and the telephone

line cord into the

Use the telephone line

supplied with your

don’t

use any other

telephone line cord

cord

See the note

on page 4

See the note

on page 4

1Choose a suitable site for the

base unit telephone

See page 4

DECT Phone-

back of the base unit

near the equipment and shall be easily

accessible.

need to be near the

equipment and shall be

easily accessible.

Installation and set-up

The CHARGE

light comes

The bars on the

battery level symbol

continuously change

as the batteries are

being charged

Make sure the mains socket is

switched on — the phone won’t

work without electrical power

Connect the base unit to the telephone line

Switch off power at the mains socket. Insert the

telephone line plug into the socket Switch mains

NOTE: the charger

Charge the batteries

Before you use the cordless

for the first time,

it’s important to charge

You hear a ‘beep’ when

charging cradle.

To keep the batteries charged,

whenever you don’t need to use thehandset

(such as overnight, or whenyougoout),leave

it on the base unit or charger pod.

Leave the handsets on the

Fit the batteries in the cordless handsets

batteries as shown

Color profile: Generic CMYK printer profile

Composite Default screen

for 15 hours

power back on

base unit

and chargerpod(s) for 15 hours.

pod doesn't have

a connection to the

telephone line.

A.Insert the three rechargeable

the batteries fully.

the handset is correctly placed on the

B.Fit the battery compartment

cover, sliding it into place and

pressing firmly to make sure

it is secure.

handsets

5Switch on at the mains socket(s)

Binatone Help Line: 0845 345 9677

(Local Call rate)

DON'T use non-rechargeable batteries in the

handset-they may burst, causing damage. Use

the rechargeable batteries supplied (1.2V AAA

size 300mAh NiCd or 550mAh NiMH).

Indice

Altri manuali Binatone Telefono senza fili

Binatone

Binatone Vantage 6020 Quad Manuale utente

Binatone

Binatone iDECT Q2i System Manuale utente

Binatone

Binatone FUSION 2925 Manuale utente

Binatone

Binatone Lifestyle 100 Manuale utente

Binatone

Binatone Ultra XD1220 Manuale utente

Binatone

Binatone iDECT Eclipse Plus Single Manuale utente

Binatone

Binatone IHOME PHONE - Manuale utente

Binatone

Binatone 1210 Manuale utente

Binatone

Binatone iDECT C5i System Manuale utente

Binatone

Binatone SYMPHONY 2610 System Manuale utente

Binatone

Binatone e900 System Manuale utente

Binatone

Binatone Activity 2600 Manuale utente

Binatone

Binatone E3200 Manuale utente

Binatone

Binatone e820 System Manuale utente

Binatone

Binatone Elite 2025 Manuale utente

Binatone

Binatone Solas 1520 Triple Manuale utente

Binatone

Binatone Brick 4home edition Manuale utente

Binatone

Binatone ICARUS 1210 Manuale utente

Binatone

Binatone Euro Elite 2825 Twin Manuale utente

Binatone

Binatone Eclipse Plus Manuale utente

Binatone

Binatone The brick Manuale utente

Binatone

Binatone SYMPHONY 2200 Manuale utente

Binatone

Binatone BB3200 Manuale utente

Binatone

Binatone Zest Manuale utente

Manuali Telefono senza fili popolari di altre marche

3Com

3Com NBX Manuale utente

Panasonic

Panasonic KX-TGK210HK Manuale utente

Panasonic

Panasonic KX-TCA181EX Manuale utente

BT FREESTYLE 3200 Manuale utente

AT&T

AT&T CL84102 Manuale utente

BREZZICNI

BREZZICNI CL-3622 Manuale utente

Panasonic

Panasonic KX-TG1831NZ Manuale utente

Panasonic

Panasonic KX-TG7301E Manuale utente

Furuno

Furuno FM-4721 Manuale utente

Sanyo

Sanyo CLT-J70 Manuale utente

Amplicomms

Amplicomms BigTel 201 Manuale utente

GE 26992 Manuale utente

AT&T

AT&T E1812B Manuale utente

Sanyo

Sanyo CLT-670 Manuale utente

GE 15432970 Manuale utente

Curtis

Curtis TC595 Manuale utente

Gigaset

Gigaset Gigaset 3000 Micro Manuale utente

Poly

Poly VVX D230 Guida all'installazione
