Biochef Astro Vacuum Guida rapida
UNLOCK THE
GOODNESS
FEEL THE
GREATNESS
Astro Vacuum
Blender
MANUAL AND RECIPE BOOK
Astro_Blender_Manual.indd 1Astro_Blender_Manual.indd 1 22/6/18 2:46 pm22/6/18 2:46 pm
ENGLISH 5
FRANÇAIS 19
DEUTSCH 33
ESPAÑOL 47
Astro
Vacuum
Blender
& Accessories
3
Astro_Blender_Manual.indd 3Astro_Blender_Manual.indd 3 22/6/18 2:46 pm22/6/18 2:46 pm
4
Astro_Blender_Manual.indd 4Astro_Blender_Manual.indd 4 22/6/18 2:46 pm22/6/18 2:46 pm
5
UNLOCK THE
GOODNESS
FEEL THE
GREATNESS
Astro Vacuum
Blender
MANUAL AND RECIPE BOOK
Astro_Blender_Manual.indd 5Astro_Blender_Manual.indd 5 22/6/18 2:46 pm22/6/18 2:46 pm
PLEASE READ AND SAVE THESE INSTRUCTIONS
1. Please read all the instructions before use.
2. Before plugging in the appliance, check that the electrical rating shown on the
rating plate corresponds with your household electricity supply.
3. Close supervision is necessary when the appliance is used near children or
incapacitated persons.
4. To avoid and protect against the risk of electrical shock, never immerse the
blender in water or other liquid. If there is water inside the unit base, please
contact your authorised service centre.
5. Unplug from outlet when not in use and before cleaning.
6. Do not leave your blender unattended when operating.
7. Do not operate the appliance with a damaged cord or plug or if the appliance
malfunctions, is dropped or damaged in any manner. If purchased outside
Australia, please contact your dealer.
8. Do not use outdoors. The unit is designed for indoor use only.
9. Do not let the cord hang over the edge of table or counter.
10. Keep hands and utensils out of the jug container. Only use the tamper provided
with the blender. A rubber scraper or spatula may be used but only when the
blender is not running.
VACUUM
SMOOTHIES DIPS & DRESSINGS NUTS AND
SEEDS
6
Astro_Blender_Manual.indd 6Astro_Blender_Manual.indd 6 22/6/18 2:46 pm22/6/18 2:46 pm
11. The use of attachments not authorised or sold by the manufacturer for use with
this blender may void warranty.
12. Always operate with the lid and lid plug/measuring cup firmly in place.
13. If in the event the motor overheats, the temperature monitoring system will
trigger and the motor will stop. Switch off and unplug the appliance and let the
motor cool down. The motor temperature monitoring system resets after the
blender is unplugged from wall socket for 45 minutes.
14. Blades are sharp. Use caution when handling the blade. Do not attempt to
disassemble blade and blade assembly.
15. Any servicing should be performed by Vitality 4 Life or an authorised service
representative. Do not attempt to disassemble, repair or modify the appliance.
NOTICE: FAILURE TO FOLLOW ANY OF THE IMPORTANT SAFETY PRECAUTIONS IS A
MISUSE OF YOUR BLENDER AND CAN CREATE THE RISK OF SERIOUS INJURY AND
VOID YOUR WARRANTY.
ICE
DICE GRIND COFFEE
BEANS
7
To prevent overheating, never allow the blender to run
for more than two minutes at a time, as it can cause
permanent damage to the motor.
Astro_Blender_Manual.indd 7Astro_Blender_Manual.indd 7 22/6/18 2:46 pm22/6/18 2:46 pm
Japanese Stainless Steel
Blades - RPM 22000
Unlock valuable nutrients
inside the skin, seeds
and pulp to make
phytonutrients more
bio-available to you.
Speed setting
from 1 to 9
1lt capacity
borosilicate
glass jug
High
Performance
Motor
1000W
Nonslip feet
Lid opening and closing
Jug Lid
8
700ml Vacuum Jar
with Lid
Press for
any length
of time
Vacuum only
for use with
Glass Jug
or 700ml
Vacuum Jar
Pre-programmed
Vacuum and
Blend mode
Astro_Blender_Manual.indd 8Astro_Blender_Manual.indd 8 22/6/18 2:46 pm22/6/18 2:46 pm
9
Operating Instructions
1. Place ingredients in glass jug (not past maximum level) and secure jug lid with
wide rim side sitting directly over jug handle.
2. Place the jug into the main blender unit with the jug handle directly over the
control panel.
3. Close lid of main blender unit and you will hear the magnets engage. Now you
are ready to begin vacuum blending.
Vacuum Blend MODE
1. Plug cord into power socket. Lights will show on front of unit and the unit will
beep. Press the ON/OFF button to turn on.
2. Press the Vacuum Blender button and then the ON/OFF button again to start the
Vacuum Blend mode. The Vacuum Blend mode will begin by removing the air
from the jug and will then blend at varying speeds until programme is finished.
3. The blender will continue to beep until ON/OFF button is pressed.
4. When you have finished blending, turn blender unit off at power socket.
5. Unlock and open lid of main blender housing. Remove blender jug. Before
opening the jug lid, lift the red valve to release the vacuum pressure. Remove jug
lid and pour to enjoy.
6. To vacuum preserve the remainder of blender jug contents, transfer into the
vacuum jar and use Vacuum (Only) mode - instructions below.
Vacuum MODE
1. Unlock and open lid of main blender housing.
2. Place ingredients into vacuum jar and attach the lid.
3. Close lid of main blender housing.
4. Press the ON/OFF button to turn on. Press Vacuum button and press ON/OFF
button again to start the Vacuum mode.
5. Programme will end when air has been optimally removed from vacuum jar.
Use the vacuum jar to preserve sauces, raw fruits and vegetables and many more
ingredients
Manual Speed / Pulse / Clean MODE
Fill jug with ingredients and place into main unit. Press ON/OFF to activate the blender.
• Manual Speed: Press the + or - to select the speed from 1 to 9. Press ON/OFF button.
Blender will operate at selected speed until ON/OFF button is pressed again to stop.
• Pulse: Press and hold the Pulse/Clean button in bursts until you have blended to the
desired consistency. Pulse mode will always operate at maximum speed setting.
To prevent overheating, never allow the blender to run
for more than two minutes at a time, as it can cause
permanent damage to the motor.
Astro_Blender_Manual.indd 9Astro_Blender_Manual.indd 9 22/6/18 2:46 pm22/6/18 2:46 pm
10
Cleaning your Astro Vacuum Blender
After finishing your blending session, you can clean the jug in various ways depending
on the ingredients you have used.
a. For thick or oily ingredients, use warm water into the jug with a few drops
detergent. Place jug into main unit. Press ON | OFF to activate the blender.
Press and hold the Pulse | Clean button and continue to press until jug looks
clean. Press ON | OFF to place the blender in Standby mode. Remove the jug
and rinse with clean water. Wipe the main unit with a wet or dry cloth.
b. Rinse the jug and lid directly under the tap and use a clean cloth to wipe up the
residual water.
***Always place jug in upright position when leaving to dry. Try not to have liquid
contacting the underside of the drive shaft.
Troubleshooting
PROBLEM PROBABLE CAUSE SOLUTION
When the jug is
on the base and
the control panel
does not light up.
Not plugged into electricity.
Electricity not turned on.
Replug cord into power
outlet. Check switch is
turned to ON position.
Ingredients are
difficult to blend
Too many solid ingredients Add more liquid
Motor stops
suddenly during
operation.
Too much food may cause motor
to cut out.
Long durations of operating
or adding too much hard food
may trigger the protection
mechanism, causing the motor
to stop.
Voltage shortage. The power
voltage is unmatched or
insufficient for the blender.
Adding too much food takes
the working current beyond the
preset maximum.
Turn off. Remove some
of the food and power up
again.
Rest the blender for 20 –
45 minutes and restart it.
Make sure the power
supply is correct.
Rest the blender for 20 –
45 minutes and restart it.
Astro_Blender_Manual.indd 10Astro_Blender_Manual.indd 10 22/6/18 2:46 pm22/6/18 2:46 pm
11
Vacuum Blending in general
Vacuum blenders have been developed for people who are looking to maximize
nutrition and reduce spoilage.
A characteristic of a normal household blender is that the high speed blades
immediately whisk lots of air into whatever ingredients you are blending.
The process of blending smashes ingredients into tiny particles, giving the biggest
possible surface area of contact between your food and oxygen.
Practically every molecule of the ingredients in a traditional blender is swimming in
an oxygen rich bath, and your blended food immediately starts to lose its nutritional
value and flavours as a result.
This is why we always recommend that a fresh smoothie is best consumed
immediately.
The Astro Vacuum Blender is a fantastic solution to this problem.
The first thing you will notice about a smoothie made in a vacuum blender will be
the colour.
Think about how quickly the brown discoloration occurs when you peel a carrot for
example. This is exactly what happens when you blend and these millions of parts of
surface area are exposed to the air. The colour of the blended ingredients will start to
darken and deteriorate with exposure to oxygen.
With the Astro Vacuum Blender, with the touch of a button, the air is removed from
the blending jug, reducing the exposure to oxygen and creating a vibrant coloured
smoothie.
Secondly, the air in a normal blender will create lots of bubbles or froth. When using
the Astro Vacuum Blender, this froth is avoided and results in a more full-bodied
smoothie which tastes rich and fresh.
Use the vacuum function with the vacuum preservation container to remove air
from smoothies, dips, sauces, baby food and more to prolong freshness.
Standard Blending Vacuum Blending
Preserve Colour, Flavour, Freshness
••• 1 min ••• 10 mins ••• 30 mins ••• 60 mins ••• ••• 1 min ••• 10 mins ••• 30 mins ••• 60 mins •••
Astro_Blender_Manual.indd 11Astro_Blender_Manual.indd 11 22/6/18 2:46 pm22/6/18 2:46 pm
