Bitmore 4K ULTRA CAM Manuale utente

4K ULTRA CAM

USER GUIDE

IMPORTANT: READ AND RETAIN THIS MANUAL BEFORE FIRST USE!

BM-4K03H 4K ULTRA CAM | 1

4K ULTRA CAM

GENERAL PRECAUTIONS :

• Keep the camera away from direct sunlight and keep the lens of the camera away f

rom directing sunshine. Otherwise, the image sensor of the camera can be damaged.

• Please be careful with the camera to avoid water, sand, or other debris from entering the camera.

Water, sand, dust, or particles containing salt may damage the camera.

• Keep the camera away from dust and chemical materials.

• Store the camera in a cool and dry place with good ventilation.

• DO NOT place the camera in places with high temperature, humidity, or dust.

• If the camera or case becomes dirty, clean with a s clean, soft, and dry cloth.

Clean the camera lens regularly. In case of sand or other debris on the lens, gently blow

it off to avoid scratching the surface of the camera lens. After blowing off sand or debris,

wipe the lens with a soft material cloth suitable for optical instruments. If needed,

please clean camera with an appropriate cleanser. DO NOT use organic solutions.

• To avoid static electricity, DO NOT use the camera in a very dry atmosphere.

SPECIFICATIONS

•

Sensor 5MP Ultra HD sensor

LCD Screen 2.0 Inch HD LCD screen

Photo Resolutions 16MP/ 12MP / 10MP / 8MP / 5MP/3MP/2M/VGA

Photo Format JPEG

Video Resolution 4K 30FPS,2.7K 30FPS, 1080FHD (1920x1080), 1080P (1440X1080),

720P (1280X720), WVGA (848X480), VGA (640X480)

Video format AVI

Ports Micro SD (up to 32GB) - No internal memory

Waterproof casing Down to 30 meters

Field of View 120°

Lens F2.5/ f=3.53mm

Light Frequency Automatic, 50 Hz-60 Hz

PC Cam YES via Micro USB

Battery capacity Removable 900mAh re-chargeable lithium battery

Battery Charge Time c.3 hours

Language Options English, French, German, Italian, Spanish, Portuguese, Japanese,

Simplified Chinese, Traditional Chinese.

Size / Weight 60 x 40 x 29 mm / 38g (w/o battery & case)

BM-4K03H 4K ULTRA CAM | 2

4K ULTRA CAM DIAGRAM

DOWN

OPERATION

INDICATOR

SWITCH MODE

MICRO

SD CARD

MIC

LENS

MICRO

USB INPUT

BATTERY DOOR

SPEAKER

OPERATION

INDICATOR

SCREEN

CHARGING

INDICATOR

SWITCH OF

WATERPROOF CASING

LENS

SWITCH /

MODE

DOWN

BM-4K03H 4K ULTRA CAM | 3

WATERPROOF

HOUSING HANDLE BAR /

POLE MOUNT CLIP 1 MOUNT 1

MOUNT 2 MOUNT 3 MOUNT 4 ADHESIVES

ACCESSORIES

HOW TO USE THE WATERPROOF CASE

1. Push along in the direction of the arrow and lift (see red arrows).

2. Open the waterproof casing.

3. Put in the camera and fasten

the waterproof casing.

Note: Take care when connecting the charging cable to the camera. Before submerging in water,

make sure the camera is inside the waterproof case and that it is securely sealed and locked.

BM-4K03H 4K ULTRA CAM | 4

CHARGING

Charge the battery when the battery icon is empty and flashes on the screen, if the camera powers

itself off, or when it won’t power on. Please ensure the battery is securely fitted inside the battery

compartment and that the cover is firmly closed before charging.

Insert the Micro USB cable into the Micro USB port on the camera, connect the other end to a USB

port (mains adaptors are best – not included).

USB Cable

The battery can be accessed by inserting a slim, blunt object into the battery door slot, and gently

prising the door open. There is a small tab on the battery that will allow you to pull it out. Make sure

the camera is switched off and not connected to a power source first.

SWITCHING ON/OFF AND MEMORY CARD

To switch on and off press and hold the POWER button on the front of the camera.

Memory Card

There is no built-in memory unit in the camera, please insert a Micro SD (max 32GB) into the slot

before use. Format the Micro SD card before use.

Gently insert the Micro SD into the slot as shown (make sure it is the correct way round so you don’t

damage the card or camera)

To remove the Micro SD card, gently push in the Micro SD card, it will pop-up automatically.

Note: Before inserting or removing the memory card, make sure the camera is switched off and not

connected to a power source.

MICRO SD CARD

The following situations may cause data loss on the memory card:

1. Improper use of the memory card

2. Bending, dropping or any kind of impact on the memory card

3. High temperatures, humidity, or direct sunlight

4. Static field or electromagnetic fields close to the card

5. Contact on the metal surface of the memory card with finger or sharp object

DO NOT unplug the camera during a format or data transfer operation as this may damage the

camera software, the memory card and its data or your connected device. Data loss for any reason is

not covered by the Bitmore guarantee.

MODE SWITCHING

Switch between video recording / photo shooting / playback /system setting by pressing the Mode

Selector button.

Recording mode , photo shooting mode , symbols are displayed on upper left corner of

screen. Refers to the function of video playback , and the last one is system setting

TAKING PHOTOS/VIDEOS

Video Recording

Switch to recording mode and there’ll be an icon in the upper left corner of the screen. Press OK to

start recording and the icon in the upper left corner will start to flash.

Press OK again to stop video recording.

Photo shooting and Settings

Switch the camera on and press the Mode Selector to select “Photo shooting Mode”, there’ll be an icon

in the upper left corner of display screen and the camera is in photo shooting mode.

Press OK to take photos.

Note: When the camera is busy recording or taking photos, the blue indicator light will show.

Playback Mode

- Use this mode to view video and photos recorded on the camera.

- Use the side Up and Down buttons to scroll through your recordings.

- Tapping the top OK button will begin playing back video recordings.

BM-4K03H 4K ULTRA CAM | 5

System Setup

- Switch Mode button to access the settings mode.

- Then use the side Up and Down buttons to change the highlighted setting.

- Press the top OK button to select the highlighted setting of your choice.

Now use the side Up and Down buttons to change the individual selection and press the

top OK button to confirm.

USB Connection Mode (PC)

When connecting a USB to Micro USB cable to a computer and the camera,

2 options are displayed, use the side buttons to change mode and the top button to select.

Mass Storage this will show the contents of the memory card on the computer. Use your computer file

manager to view or copy files.

PC Cam Mode: The LCD will display the lens icon. Now you can start the web cam

through application.

BM-4K03H 4K ULTRA CAM | 5

SAFETY INFORMATION:

DO NOT place any metals or mental objects (including a device case/cover that has metal

components) on your device or this product whilst in use and connected to a power source. You

risk potential electrical shocks, static or other more dangerous incidents such as ﬁre or death

DO NOT leave your device connected to this product when not in use or when charging

is complete

DO NOT cover this product or your device when in use

DO NOT expose this product to heat sources (including ﬁre or direct sunlight)

DO NOT use or expose this product or your device to areas of high humidity, any liquids, gels or

aerosols or heavy dust, keep it dry and clean If this product encounters any liquid, immediately

unplug the product from any connected power sources or devices

DO NOT disassemble or modify this product – this could cause risk of injury, death,

or damage to property

This product must only be used and stored in an ambient environment with a temperature

between 0-45 °C

Avoid dropping this product (or any other heavy impact which might damage the internal circuit)

Avoid cleaning this product using liquids or chemical substances (use a dry cloth only)

Only use attachments/accessories supplied by Bitmore or those certiﬁed by your

device manufacturer

This product is not a toy, DO NOT leave children unsupervised with this product.

Please use a genuine certiﬁed wall adaptor, such as one that is supplied with your

device manufacturer

DO NOT use a wall adaptor with a fast charge or high AMP output

DO NOT leave your device unattended for charging overnight

DO NOT use faulty, damaged or none certiﬁed (by your device manufacturer) plugs to charge

or discharge your devices

DO NOT use a plug with more than a 5W output

DO NOT operate this product where aerosols are or have recently been used or where oxygen is

being administered

DO NOT operate in a closed environment such as a pocket, handbag, backpack, under

a pillow etc

BM-4K03H 4K ULTRA CAM | 6

Get your 24-month Limited Guarantee and become a Bitmore member!

You must register your device via bitmore.co.uk within 30 days of purchase for the manufactur-

ing guarantee to be valid.

Plus get a “bit more” by gaining access to exclusive product giveaways, membership rewards and

discounts!

Subject to applicable law, parent company Bitmore Limited (UK) and Nuwave Channel Partners

BV (operating in the EU on behalf of Bitmore Limited) (hereinafter “Bitmore”4), sell its

products (hereinafter “Product(s)”) with the intent that they are free of defects in manufacture

and workmanship for 24-months from the date of original purchase, except as noted below.

Bitmore warrants that its Products will be free of defects in material and workmanship under

normal use and service. This guarantee extends only to consumers and does not extend to

Retailers. Bitmore does not authorize anyone, including, but not limited to, retailers, the

subsequent consumer purchaser of the product from a retailer or remote purchasers, to obligate

Bitmore in any way beyond the terms set forth herein. This guarantee does not cover damage

caused by misuse or abuse; accident; the attachment of any unauthorized accessory; alteration

to the product; improper installation; unauthorized repairs or modiﬁcations; improper use of

electrical/power supply; loss of power; dropped Product; malfunction or damage of an operating

part from failure to provide manufacturer’s recommended maintenance; transportation damage;

theft; neglect; vandalism; or environmental conditions; loss of use; or any other conditions

whatsoever that are beyond the control of Bitmore.

THE GUARANTEE PROVIDED HEREIN SHALL BE THE SOLE AND EXCLUSIVE GUARANTEE.

THERE SHALL BE NO OTHER WARRANTIES EXPRESS OR IMPLIED INCLUDING ANY

IMPLIED GUARANTEE OF MERCHANTABILITY OR FITNESS OR ANY OTHER OBLIGATION

ON THE PART OF THE COMPANY WITH RESPECT TO PRODUCTS COVERED BY THIS

GUARANTEE. BITMORE SHALL HAVE NO LIABILITY FOR ANY INCIDENTAL,

CONSEQUENTIAL OR SPECIAL DAMAGES. IN NO EVENT SHALL THIS GUARANTEE

REQUIRE MORE THAN THE REPLACEMENT OF ANY PART OR PARTS WHICH ARE FOUND

TO BE DEFECTIVE WITHIN THE EFFECTIVE PERIOD OF THE GUARANTEE. REFUNDS WILL

BE GIVEN IF REPLACEMENT PARTS FOR DEFECTIVE MATERIALS ARE NOT AVAILABLE,

BITMORE RESERVES THE RIGHT TO MAKE PRODUCT SUBSTITUTIONS IN LIEU OF REPAIR

OR REPLACEMENT.

BM-4K03H 4K ULTRA CAM | 7

This guarantee does not extend to the purchase of opened, used, repaired, repackaged and/or

resealed products, including but not limited to sale of such products on Internet auction sites

and/or sales of such Products by surplus or bulk resellers. All warranties or guarantees shall

immediately cease and terminate as to any Products or parts thereof which are repaired,

replaced, altered, or modiﬁed, without the prior express and written consent of Bitmore.

This Agreement is made for the beneﬁt of the parties and is not intended to beneﬁt any third

party or be enforceable by any third party. The rights of the parties to terminate, rescind, or

agree any amendment, waiver, variation, or settlement under or relating to this Agreement are

not subject to the consent of any third party.

This guarantee provides you with speciﬁc legal rights. You may have additional rights which may

vary from country to country. Because of individual regulations, some of the above limitations

and exclusions may not apply to you.

NOTE:

Failure to follow the instructions in this manual will result in the manufacturing guarantee being

void. Please take extra care when connecting cables to your devices or the product to avoid

damaging the ports.

Wear and tear aren’t covered by the guarantee. Submersion in liquids will void the guarantee.

Devices connected to this product or App are not covered by the Bitmore guarantee.

For Bitmore products containing a Lithium-ion battery:

Lithium-ion battery powered devices are dispatched from our factory with a partial charge,

depending on the storing temperature and the length of storage during transit and with the

retailer, the charge held by the device will naturally decrease, for best performance we recom-

mend charging the device fully,

Any product that is powered by a Lithium-ion battery, as with all devices using Lithium, the

amount of charge the lithium cells can hold decreases over time and with use or if left in a cold

environment, experiencing ﬂuctuations in temperature or when unused for long periods of time

(charge and discharged the battery often, even if you are not using it). Therefore, you may ﬁnd

that the amount of charge this product holds and oers may be slightly less. This is typically a

slow process and a naturally recurring phenomenon and is not covered by the guarantee

or guarantee.

BM-4K03H 4K ULTRA CAM | 8

Indice

Manuali Macchina fotografica digitale popolari di altre marche

Mercury

Mercury 350K Manuale utente

Pentax

Pentax Optio LS 465 Manuale utente

Sanyo

Sanyo VPC-S1085 Manuale utente

GE SMART A1255 Manuale utente

Point Grey

Point Grey Gazelle Manuale utente

Nikon

Nikon COOLPIX A Manuale utente

Pentax

Pentax P-5 Manuale utente

BlazeVideo

BlazeVideo A280 Manuale utente

Sony

Sony MCA-20 Manuale utente

Sony

Sony Alpha DSLR-A290 Manuale utente

ATIK Cameras

ATIK Cameras One Manuale utente

CohuHD Costar

CohuHD Costar 3930 Series Manuale utente

Leica

Leica M10-R Manuale utente

FujiFilm

FujiFilm FinePix A700 Manuale utente

Lorex

Lorex LNZ81P25 Series Manuale utente

GE J1470S Manuale utente

Sony

Sony A6700 Guida utente

Canon

Canon EOS ELAN7 Manuale utente

bitmore 4K ULTRA CAM Manuale utente

Manuali Macchina fotografica digitale popolari di altre marche
