2.2 Specific requirements
The safety information below, broken down into two risk levels, relate specifically to the operating
notions and procedures for installation, use, and maintenance. Where of use, these will be repeated
and detailed in the chapters that describe specific tasks.
We wish to stress that the installer must inform the user of the risk that may arise from not knowing
and abiding by the information below.
A. The charging station is designed exclusively for charging compatible electric vehicles
that do not require ventilation while charging. In no circumstances must it be used for
other purposes, modified even partially, or integrated into electrical systems for
different or complementary purposes.
B. Before and during installation and use of the charging station, check that its parts are in
good condition. Never install or use a device that has clearly visible damage or defects,
especially to the plastic parts, cables, or connectors.
C. Always inform the user that if the charging station is damaged after installation, it is
essential that the electricity supply to it be interrupted immediately, using the relevant
switch on the electrical panel. Before using it again, always have work done on it by a
specialist technician.
D. Do not disassemble the charging station and do not install it outdoors when there is rain,
snow, or hail, when there is severe humidity, or at temperatures outside the operating
range (from -30°C to +50°C).
E. Never install the unit on walls that are mobile or semi-mobile, flammable, or clad in
flammable material, adjacent to passageways or emergency exit routes, with plumbing
or gas plants even if not flammable.
F. Also make sure that there are no excessive heat or electromagnetic sources, highly
flammable or explosive materials in the vicinity of the charging station. Make sure that
these recommendations are also applied to the charging cables that are often subjected
to damage and wear.
G. Do not immerse the connectors in liquids of any kind and avoid exposing the charging
station of direct or any strong water jets. (For instructions on washing the surfaces, see
the "MAINTENANCE" chapter).
A. The charging station is designed for indoor or outdoor use, in accordance with the criteria
laid down by the current norm. Despite this, we advise against using it in heavy rain or
when directly exposed to bad weather. Before use, always check that the connectors
(including that on the vehicle side) are not wet, too damp, or dirty.
B. Handle the charging cable carefully, avoiding pulling it with excessive force, and
protecting it against tears, impacts, and abrasion. Always grip the connector, without
pulling on the cable. When charging is complete, wind the cable in the relevant support
or, if it is removable, put it where it is protected against damage.
