Bitspower BP-RAMS44D-D5 Manuale utente

[ 1 ]

Bitspower 4-DIMMS RAM Water Cooling Module (DDR5, Double-sided)

instruction manual

Screw B (M5x4.5mm)

Screw A (M5x5.5mm)

Stando󽗈s

Thermal pad(1mm)

Step1

x 8

The RAM covers only 󽗉t for Double-sided DDR5.

5RAM Heat Sink A x 8

6RAM(Not included)

[ 2 ]

2Water block

Socket head cap screw (M2.5x6mm)

Step2

x 8

x 1

Notice

Before filling in the water, please make sure all the components are

installed correctly. To prevent any leakage which may damage the PC

components, please perform a 24-hour leaking test with only the pump

connected to the power supply.

Bitspower reserves the right to change the product design and

interpretations. These are subject to change without notice. Product

colors and accessories are based on the actual product.

When using leak tester on water cooling loop, in order to avoid product

damage due to excessive pressure, the input pressure should not exceed

0.5kg/cm2 (Bar). If the product is damaged due to

excessive pressure, it will be borne by the customer. Forbidden to use the

leak teser when there is water in the loop or the pump is runing.

Bitspower recommends that consumers use the Bitspower Pellucid

Coolant for their water-cooling liquid. Also, they can add Bitspower Dye

to Pellucid Coolant for the color requirement. If the consumer chooses

di󽗈erent water-cooling liquids, the resulting impurities may cause peeling

off the coating on some of the hardware, water channels blockage by

built-up residue, improper operation of the water pump, water tank tube

breakage, and o-rings deformation leading to leakage. Any issues related

to the use of inappropriate water-cooling liquid will be the responsibility of

the consumer.

[ 3 ]

[ 4 ]

使用說明書

Bitspower 4-DIMMS RAM Water Cooling Module (DDR5, Double-sided) V1

螺絲 B (M5x4.5mm)

螺絲 A (M5x5.5mm)

方型螺柱

導熱墊片 (1mm)

步驟 1

x 8

5記憶體夾片 A x 8

夾片僅適用 DDR5 雙面顆粒。

6記憶體 ( 不包括 )

[ 5 ]

2冷頭

有頭內六角螺絲 (M2.5x6mm)

步驟 2

x 8

x 1

注意

跑水前，請先確認所有零件已安裝在正確的位置上，在不開主機，單開水

泵的情况下，進行 24 小時的跑水測試，確保無漏水情况後再開主機，避

免發生漏水而導致電腦零件的損壞。

本公司保留對產品的設計更改以及解釋的權力，如有更動恕不另行通知，

產品顏色與配件以實物為準。

當使用測氣產品測試水路時 , 為避免由於壓力過大導致產品損壞 , 輸入的

壓力請不要超過 0.5kg/cm2 (Bar), 如因壓力過大造成產品損壞 , 將由客戶

自行承擔 . 嚴禁客戶在水路有水及水泵開啟的情況下進行氣體飽壓測試。

Bitspower 建議消費者使用 Bitspower 透明冷卻液。此外，也可以添加

Bitspower 染料到透明冷卻液中以滿足顏色要求。如果消費者選擇不同的

水冷液，可能會引起水路配件中的塗層剝落、積垢堵塞水道、水泵磨損、

水箱管破裂、破壞 O 型圈密封性導致漏水等。任何因使用不當水冷液導

致相關的問題將由消費者自行負責。

[ 6 ]

[ 7 ]

使用说明书

步骤 1

Bitspower 4-DIMMS RAM Water Cooling Module (DDR5, Double-sided) V1

夹片仅适用 DDR5 双面颗粒。

螺丝 B (M5x4.5mm)

螺丝 A (M5x5.5mm)

方型螺柱

导热垫片 (1mm)

x 8

5內存夹片 A x 8

6內存 ( 不包括 )

[ 8 ]

2冷头

有头内六角螺丝 (M2.5x6mm)

步骤 2

x 8

x 1

注意

[ 9 ]

跑水前，请先确认所有零件已安装在正确的位置上，在不开主机，单开水

泵的情况下，进行 24 小时的跑水测试，确保无漏水情况后再开主机，避

免发生漏水而导致电脑零件的损坏。

本公司保留对产品的设计更改以及解释的权力，如有更动恕不另行通知，

产品颜色与配件以实物为准。

当使用测气产品测试水路时 , 为避免由于压力过大导致产品损坏 , 输入的

压力请不要超过 0.5kg/cm2 (Bar), 如因压力过大造成产品损坏 , 将由客户

自行承担 . 严禁客户在水路有水及水泵开启的情况下进行气体饱压测试。

Bitspower 建议消费者使用 Bitspower 透明冷却液。此外，也可以添加

Bitspower 染料到透明冷却液中以满足颜色要求。如果消费者选择不同的

水冷液，可能会引起水路配件中的涂层剥落、积垢堵塞水道、水泵磨损、

水箱管破裂、破坏 O 型圈密封性导致漏水等。任何因使用不当水冷液导

致相关的问题将由消费者自行负责。
