Black & Decker JE400 Manuale utente

JE400

www.blackanddecker.ae

ENGLISH

Parts Identiﬁcation

A. Pusher

B. Feeding tube

C. Lid

D. Rotary sieve

E. Juice collector

F. Pulp container

G. Clamp

H. Control knob

I. Foam separator

J. Motor unit

K. Juce jug lid

L. Juice jug

M. Spout

ENGLISH

Intended use

Your Black & Decker juicer has been designed

for juicing fruits and vegetables. This product is

intended for household use only.

Read this entire manual carefully

before using the appliance.

Safety instructions

Warning! When using mains-powered

appliances, basic safety precautions, including

the following, should always be followed to

reduce the risk of ﬁre, electric shock and

personal injury.

• The intended use is described in this manual.

The use of any accessory or attachment or

the performance of any operation with this

appliance other than those recommended in

this instruction manual may present a risk of

personal injury.

• Retain this manual for future reference.

Using your appliance

• Always take care when using the appliance.

• Never pull the power supply cord to

disconnect the plug from the socket. Keep

the power supply cord away from heat, oil

and sharp edges.

• Do not place the appliance on or near heat

sources or in a heated oven.

• Do not use the appliance outdoors.

• Always protect the motor unit from water or

excessive humidity.

• If the power supply cord is damaged during

use, disconnect the appliance from the power

supply immediately. Do not touch the power

supply cord before disconnecting from the

power supply.

• Disconnect the appliance from the power

supply when not in use, before ﬁtting or

removing parts and before cleaning.

• Never let the appliance operate unattended.

• Never reach into the feeding tube with your

ﬁngers or an object while the appliance is

running. Only the pusher is to be used for this

purpose.

• Only unlock the clamp after you have

switched the appliance off and any moving

parts have stopped.

• Do not touch the small cutting blades in the

base of the ﬁlter.

• Keep any loose clothing or long hair away

from the feeding tube and any moving parts.

Safety of others

• This appliance is not intended for use by

persons (including children) with reduced

physical sensory or mental capabilities, or

lack of experience and knowledge, unless

they have been given supervision or

instruction concerning use of the appliance by

a person responsible for their safety.

• Children should be supervised to ensure that

they do not play with the appliance.

ENGLISH

After use

• Remove the plug from the socket before

leaving the appliance unattended and before

changing, cleaning or inspecting any parts of

the appliance.

• When not in use, the appliance should be

stored in a dry place. Children should not

have access to stored appliances.

Inspection and repairs

• Before use, check the appliance for

damaged or defective parts. Check for

breakage of parts, damage to switches and

any other conditions that may affect its

operation.

• Do not use the appliance if any part is

damaged or defective.

• Do not use the appliance if the rotary sieve is

damaged.

• Have any damaged or defective parts

repaired or replaced by an authorised repair

agent.

• Before use, check the power supply cord for

signs of damage, ageing and wear.

• Do not use the appliance if the power supply

cord or mains plug is damaged or defective.

• If the power supply cord or mains plug is

damaged or defective it must be repaired by

an authorised repair agent in order to avoid a

hazard. Do not cut the power supply cord

and do not attempt to repair it yourself.

• Never attempt to remove or replace any

parts other than those speciﬁed in this

manual.

Electrical safety

Before use, check that the mains voltage

corresponds to the voltage on the rating plate.

This appliance is double insulated in

accordance with EN 60335-2-14;

therefore no earth wire is required.

• To avoid the risk of electric shock, do not

immerse the cord, plug or motor unit in water

or other liquid.

• Check that the supply voltage shown on the

rating plate of the appliance matches that of

your electrical system. Any connection error

will invalidate the guarantee.

Mains plug replacement

If a new mains plug needs to be ﬁtted:

• Safely dispose of the old plug

• Connect the brown lead to the live terminal of

the new plug

• Connect the blue lead to the neutral terminal

• If the product is class I (earthed), connect the

green/yellow lead to the earth terminal.

Note: If your product is class II double insulated

(only 2 wires in the cord set), no connection is to

be made to the earth terminal.

Follow the ﬁtting instructions supplied with good

quality plugs

Any replacement fuse must be of the same

rating as the original fuse supplied with the

product.

Warning! The above section on mains plug

replacement is for authorized service centre

personals.

ENGLISH

Labels on appliance

The following warning symbols are found on the

appliance:

Warning! Allow moving parts to come

to a stop before approaching.

Assembly

1. Wash all detachable parts (see chapter

‘Maintenance and cleaning’).

2. Place the juice collector into the appliance

and place the pulp container into the

appliance.

3. Put the rotary sieve in the juice collector and

hold the lid over the rotary sieve and lower it

into position.

4. Make sure the rotary sieve is ﬁtted securely

onto the driving shaft (‘click’).

5. Always check the rotary sieve before use. If

you detect any cracks or damage, do not use

the appliance and contact the nearest

service centre or take the appliance to your

dealer.

6. Lock the clamp onto the lid to lock it into

place (‘click’) and slide the pusher into the

feeding tube by aligning the groove in the

pusher with the small protrusion on the

inside of the feeding tube. Never insert your

ﬁngers or an object into the feeding tube.

7. Place the juice jug under the spout.

8. Place the lid on the juice jug to avoid

splattering or if you want to store the juice in

the refrigerator.

ENGLISH

Use

1. Place the appliance on a ﬂat, stable surface

and connect it to the electrical supply.

2. Select the required speed (l or ll) using the

rotary switch.

3. Remove the pusher & add the ingredients,

using the pusher to guide the ingredients

onto the blades.

While you are preparing juice, you can empty

the pulp container by switching the appliance off

and carefully removing the pulp container.

Note: Reassemble the empty pulp container

before you continue juicing.

4. When juicing is completed, return the control

to the O (off) position.

The appliance should be disconnected

from the mains supply before

removing the jug.

The Juicer should not be run for longer than 1

Minute. After each 1 Minute use, the Juicer

should be allowed to cool for at least 1 minute.

After 3 consecutive cycles the juicer must be

allowed to cool for 15 minutes before further

use.

Useful advice

• Wash the fruit carefully before juicing.

• Use fresh fruit and vegetables, as they

contain more juice. Pineapples, celery stalks,

apples, cucumbers, carrots, melons,

tomatoes, oranges and grapes are

particularly suitable for processing in the

juice extractor.

• You do not need to remove the peels or

skins. You only need to peel fruit with thick

skin: citrus fruit, pineapple (remove the

centre stalk).

• Fruits that contain starch, such as bananas,

papayas, avocados, ﬁgs, strawberries and

mangoes are not suitable for processing in

the juice extractor. Use a food processor,

blender or stick blender to process these

fruits.

• The juicer is not suitable for processing very

hard and/or ﬁbrous/starchy fruits or

vegetables such as sugar cane.

• Choose fresh, ripe fruit and vegetables, they

will yield more juice.

• Drink the juice immediately after you have

extracted it. If it is exposed to air for some

time, the juice will lose its taste and

nutritional value.

• To extract the maximum amount of juice,

always press the pusher down slowly.

Maintenance & cleaning

• Switch the appliance off, remove the plug

from the wall socket and wait until the rotary

sieve has stopped rotating before cleaning,

changing accessories or approaching parts

that move during use.

• The appliance is easier to clean if you do so

immediately after use.

• Do not use abrasive cleaning agents,

scourers, acetone, alcohol etc. to clean the

appliance.

• All detachable parts, except the rotary sieve,

are dishwasher-safe. The rotary sieve should

be washed by hand.

ENGLISH

Warning! Care must be take when washing the

rotary sieve. Do not touch the small cutting

blades in the base of the ﬁlter.

• Place the detachable plastic parts on the top

tray of the dishwasher. Make sure they are

placed well away from the heating element.

• Clean these parts with a cleaning brush in

warm water with some washing-up liquid and

rinse them under the tap.

• Remove the dirty parts from the motor unit.

Disassemble the appliance in the following

order:

- Remove the pulp container,

- Remove the pusher,

- Open the clamp& remove the lid,

- Remove the juice collector together

with the rotary sieve.

• Clean the motor unit with a damp cloth.

• Never immerse the motor unit in water nor

rinse it under the tap.

JE400

Voltage 220 – 240 Volts

Supply 50/60 Hz

Power consumption

(Speed I) 111-127W

Power Consumption

(Speed II) 174-208W

Rated power 400W

Weight 2kg

Technical data

ENGLISH

Protecting the environment

Separate collection. This product must not

be disposed of with normal household

waste.

Should you ﬁnd one day that your Black &

Decker product needs replacement, or if it is of

no further use to you, do not dispose of it with

other household waste. Make this product

available for separate collection.

• Black & Decker provides a facility for

recycling Black & Decker products once they

have reached the end of their working life.

This service is provided free of charge. To

take advantage of this service please return

your product to any authorised repair agent

who will collect them on our behalf.

• You can check the location of your nearest

authorised repair agent by contacting your

local Black & Decker ofﬁce at the address

indicated in this manual. Alternatively, a list of

authorized Black & Decker repair agents and

full details of our after-sales service and

contact are available on the Internet at:

www.2helpU.com.

Warranty

Black & Decker is conﬁdent of the quality of its

products and offers an outstanding warranty.

This warranty statement is in addition to and in

no way prejudices your statutory rights.

The warranty is valid within the territories of the

Member States of the European Union and the

European Free Trade Area.

If a Black & Decker product becomes defective

due to faulty materials, workmanship or lack of

conformity, within 24 months from the date of

purchase, Black & Decker warranty to replace

defective parts, repair products subjected to fair

wear and tear or replace such products to ensure

minimum inconvenience to the customer unless:

The product has been used for trade,

professional or hire purposes;

The product has been subjected to misuse

or neglect;

The product has sustained damage

through foreign objects, substances or

accidents;

Repairs have been attempted by persons

other than authorised repair agents or

Black & Decker service staff.

To claim on the warranty, you will need to submit

proof of purchase to the seller or an authorised

repair agent. You can check the location of your

nearest authorised repair agent by contacting

your local Black & Decker ofﬁce at the address

indicated in this manual.

Alternatively, a list of authorised Black & Decker

repair agents and full details of our after-sales

service and contacts are available on the Internet

at: www.2helpU.com.

FRANÇAIS

Parts Identiﬁcation

A. Poussoir

B. Cheminée de remplissage

C. Couvercle

D. Filtre rotatif

E. Collecteur de jus

F. Réservoir à pulpe

G. Bride

H. Bouton de commande

I. Séparateur de mousse

J. Bloc moteur

K. Couvercle du pichet

L. Pichet

M. Bec verseur

FRANÇAIS

Utilisation prévue

Votre presse-agrumes Black & Decker a été

conçu pour extraire le jus des agrumes. Cet

appareil est uniquement destiné à un usage

domestique à l’intérieur.

Lisez ce manuel attentivement avant

d’utiliser l’appareil.

Consignes de sécurité

Avertissement! Lorsqu’on utilise un appareil

électrique, il faut toujours respecter certaines

règles de sécurité fondamentales, notamment

les suivantes, aﬁn de prévenir les risques

d’incendie, de décharges électriques ou de

blessures corporelles.

• Ce manuel décrit la manière d’utiliser cet

appareil. L’utilisation d’un accessoire ou

d’une ﬁxation, ou l’utilisation de cet appareil

à d’autres ﬁns que celles recommandées

dans ce manuel d’instruction peut présenter

un risque de blessures corporelles.

• Conservez ce manuel pour un usage

ultérieur.

Utilisation de votre appareil

• Prenez toutes les précautions nécessaires

pendant l’utilisation de l’appareil.

• Ne tirez jamais sur le cordon d’alimentation

pour débrancher la ﬁche de la prise. Gardez

le cordon d’alimentation éloigné de toute

source de chaleur, de zones graisseuses et

de bords tranchants.

• Ne placez pas l’appareil sur ou près de

sources de chaleur ou dans un four chaud.

• N’utilisez pas l’appareil à l’extérieur.

• Protégez toujours le bloc moteur de l’eau ou

d’une humidité excessive.

• Si le cordon d’alimentation est endommagé

pendant l’utilisation, débranchez

immédiatement l’appareil. Ne touchez pas au

cordon d’alimentation avant d’avoir

débranché l’appareil.

• Débranchez l’appareil de l’alimentation

secteur lorsqu’il n’est pas utilisé, avant de

monter ou de démonter des éléments et

avant de le nettoyer.

• Ne laissez jamais fonctionner l’appareil sans

surveillance.

• Ne mettez jamais vos doigts ou tout autre

objet dans la cheminée de remplissage

lorsque l’appareil est en cours de

fonctionnement. Utilisez exclusivement le

poussoir à cet effet.

• Déverrouillez la bride uniquement après avoir

éteint l’appareil et patienté jusqu’à l’arrêt

complet des parties mouvantes.

• Ne touchez pas les petites lames de coupe à

la base du ﬁltre.

• Tenez les vêtements amples ou les cheveux

longs à l’écart de la cheminée de remplissage

et des parties mouvantes.

Sécurité d’autrui

• Cet appareil ne doit pas être utilisé par des

personnes (y compris les enfants) ayant des

déﬁciences physiques, sensorielles ou

mentales. Cette consigne s’applique aussi

aux personnes manquant d’expérience ou de

connaissances du matériel, à moins que

celles-ci n’aient reçu les instructions

appropriées ou ne soient encadrées par une

personne responsable de leur sécurité pour

utiliser l’appareil.

• Ne laissez jamais les enfants sans

surveillance pour éviter qu’ils ne jouent avec

cet appareil.

Questo manuale è adatto per i seguenti modelli

Indice

Lingue:

Altri manuali Black & Decker Spremiagrumi

Black & Decker

Black & Decker CJ631 Istruzioni per l'installazione

Black & Decker

Black & Decker CJ750 Manuale utente

Black & Decker

Black & Decker CJ700 Manuale utente

Black & Decker

Black & Decker JE500 Manuale utente

Black & Decker

Black & Decker PRJE650 Manuale utente

Black & Decker

Black & Decker CJ800 Manuale utente

Black & Decker

Black & Decker CJ650M-1 Manuale utente

Black & Decker

Black & Decker PRJE600 Manuale utente

Black & Decker

Black & Decker CitrusMate CJ01 Series Istruzioni per l'installazione

Black & Decker

Black & Decker JBGM600-B5 Manuale utente

Black & Decker

Black & Decker HandyJuicer HJ28 Series Istruzioni per l'installazione

Black & Decker

Black & Decker CitrusMate CJ500 Series Istruzioni per l'installazione

Black & Decker

Black & Decker CJ200 Manuale utente

Black & Decker

Black & Decker HandyJuicer HJ29 Istruzioni per l'installazione

Black & Decker

Black & Decker CJ630 Istruzioni per l'installazione

Black & Decker

Black & Decker HandyJuicer HJ29 Istruzioni per l'installazione

Black & Decker

Black & Decker BFCJ300 Manuale utente

Black & Decker

Black & Decker JIS300 Manuale utente

Black & Decker

Black & Decker CJ600 Istruzioni per l'installazione

Black & Decker

Black & Decker CJ630 Manuale utente

Black & Decker

Black & Decker BXJE200E Manuale utente

Black & Decker

Black & Decker CitrusMate CJ500 Series Manuale utente

Black & Decker

Black & Decker BX700G Manuale utente

Black & Decker

Black & Decker CJ630 Manuale utente

Manuali Spremiagrumi popolari di altre marche

GE 169201 Manuale utente

Exquisit

Exquisit ZP 3001 WET Manuale utente

Philips

Philips HR1851 Manuale utente

Sam Cook

Sam Cook MASTERCHEF EXECUTIVE PSC-50 Manuale utente

Termozeta

Termozeta spremiagrumi Manuale utente

ElectrIQ

ElectrIQ WF1000 Manuale utente

Bella

Bella WHOLE FRUIT JUICER Manuale utente

HAEGER

HAEGER Little Juice CJ-025 006A Manuale utente

Havells

Havells Fusion Manuale utente

Siemens

Siemens MK554 SERIES Manuale utente

Beper

Beper 90.302B Guida rapida

NATURSAFT

NATURSAFT 015.401.3 Manuale utente

Moulinex

Moulinex BKB 2 Manuale utente

Royal Catering

Royal Catering RCJU-01 Manuale utente

camry

camry CR 4002 Manuale utente

AIGOSTAR

AIGOSTAR 30HIM Manuale utente

ZUMEX

ZUMEX MINEX Manuale utente

Skymsen

Skymsen EX Manuale utente
