Extend High-Definition Multimedia Interface

(HDMI) or Digital Visual Interface (DVI) signals

up to 192 feet (60 m) using CAT5/5e/6/7 cable.

HD View—HDMI Quick Start Guide

August 2009

AC3010A

AC3011A

Order toll-free in the U.S.: Call 877-877-BBOX (outside U.S.

call 724-746-5500) • FREE technical support 24 hours a day, 7 days a

week: Call 724-746-5500 or fax 724-746-0746 • Mailing address:

Black Box Corporation, 1000 Park Drive, Lawrence, PA 15055-1018

• Web site: www.blackbox.com • E-mail: [email protected]

Customer

Support

Information

724-746-5500 | blackbox.com

HD View—HDMI Quick Start Guide

Page 1

TRADEMARKS USED IN THIS MANUAL

Black Box and the Double Diamond logo are registered trademarks of

BB Technologies, Inc.

Blu-ray Disc is a trademark of the Blu-ray Disc Association.

Any other trademarks mentioned in this manual are acknowledged to be

the property of the trademark owners.

1. Introduction

With repeaters, the HD View—HDMI extends High-Definition Multimedia

Interface (HDMI) or Digital Visual Interface (DVI) signals to a distance of 640 feet

(200 m) over CAT5/5e/6/7 cable. Without repeaters, the HD View—HDMI extends

HDMI or DVI signals up to 192 feet (60 m). It delivers rich multimedia content in

real-time, without degrading video or sound quality.

The HD View—HDMI supports virtually all types of media players including com-

puters with HDMI video cards, Blu-ray Disc™players, and game consoles. Plus, it pro-

vides digital sound so it’s perfect for applications requiring top sound quality.

2. What’s Included

Your package should contain the following items. If anything is missing or dam-

aged, contact Black Box Technical Support at 724-746-5500.

• Transmitter

• Receiver

• (2)powersupplies

• (2)powercables

• Quickinstallguide

An optional HD View—HDMI Repeater (part number AC3011A) is also available

separately.

724-746-5500 | blackbox.com

Page 2

HD View—HDMI Quick Start Guide

3. HDMI Units

3.1 Transmitter

3.1.1 Side 1 of Transmitter

Figure 3-1 illustrates the transmitter‘s side 1. Table 3-1 describes its components.

Figure 3-1. Transmitter, side 1.

Table 3-1. Components on transmitter side 1.

No. Component Description

1 Get button Press and hold to restore the default data.

2 Stored/screen Player reads data from data previously

selector DIP switch stored in the transmitter.

3 HDMI connector System In connector

724-746-5500 | blackbox.com Page 3

HD View—HDMI Quick Start Guide

3.1.2 Side 2 of Transmitter

Figure 3-2 shows the components on the transmitter’s side 2. Table 2-2 describes

these components.

9 7 10 8

Figure 3-2. Transmitter, side 2.

Table 3-2. Components on transmitter side 2.

No. Component Description

4 RJ-45 connector Video out port

5 RJ-45 connector DDC port

6 Video out port LED 1 Lights when the transmitter detects a signal

from the player.

7 DDC port LED 1 Lights when the cable from the transmitter is

connected to the receiver and the cable from

the receiver is connected to a screen. Note

that it does not indicate whether the screen

is powered on or off.

724-746-5500 | blackbox.com

Page 4

HD View—HDMI Quick Start Guide

Table 3-2 (continued). Components on transmitter side 2.

No. Component Description

8 4-pin Molex connector Power: Connects to 5-VDC power supply

9 Video out port LED 2 Lights when the transmitter is connected to a

powered player.

10 DDC port LED 2 Lights when power is on.

3.2 Receiver

Figures 3-3 and 3-4 illustrate the two sides of the receiver. Tables 3-3 and 3-4

describe the components.

3.2.1 Receiver’s Side 1

Figure 3-3. Receiver, side 1.

724-746-5500 | blackbox.com Page 5

HD View—HDMI Quick Start Guide

Table 3-3. Components on receiver‘s side 1.

No. Component Description

1 Equalization(EQ) Ingeneral,thelongerthecable,the

selector switch higher the number that has to be set. Adjust

theEQselectoronestepatatime,upto

position “7.” After each adjustment, wait to

see the results of the adjustment at the

screen.

2 4-pin Molex connector 5-VDC power

3 HDMI connector Video in port

3.2.2 Receiver’s Side 2

576

Figure 3-4. Receiver, side 2.

724-746-5500 | blackbox.com

Page 6

HD View—HDMI Quick Start Guide

Table 3-4. Components on receiver‘s side 2.

No. Component Description

4 RJ-45 connector Video in

5 RJ-45 connector DDC in

6 Dual LED Lights when the Receiver detects a video sig-

nal from the Transmitter.

7 DDC LED 2 Lights when power is on.

3.3 Repeater (AC3011A)

3.3.1 Repeater’s Side 1

Figure 3-5 illustrates the repeater’s side 1. Table 3-5 describes its components.

123

Figure 3-5. Repeater, side 1.

724-746-5500 | blackbox.com Page 7

HD View—HDMI Quick Start Guide

Table 3-5. Components on repeater’s side 1.

No. Component Description

1 RJ-45 connector Video in

2 RJ-45 connector DDC

3 4-pin Molex connector 5-VDC power

3.3.2 Repeater’s Side 2

Figure 3-6 shows the repeater’s side 2. Table 3-6 describes its components.

Figure 3-6. Repeater side 2.

Table 3-6. Components on repeater’s side 2.

No. Component Description

4 RJ-45 connector Video out

5 HDMI connector HDMI

724-746-5500 | blackbox.com

Page 8

HD View—HDMI Quick Start Guide

4. Compatible Cabling

HD View—HDMI works with CAT5/5e/6/7 data cabling. Some skew-free CAT5

cabling is specific to a particular vendor and is not compatible with Black Box prod-

ucts. Because of the manufacturing methods, CAT6 cable can exhibit greater skew

than standard CAT5/5e and may require skew compensation beyond what the HD

View—HDMI offers.

NOTE: Transmission distance and performance depend on the cables’ signal

resolution, graphics card, and display used in the system. We suggest test-

ing the cable with the product before installation.

For maximum distance runs and/or applications in which uptime is critical, we

recommend using screened twisted pair (ScTP) cable (EYNC770A [bulk PVC cable],

EYNC771A [bulk plenum cable], or EVNSL74-80 [patch cable]) and compatible

screened RJ-45 connectors. This minimizes EMI interference from external sources.

5. Pre-Installation Guidelines

Make sure that the player and the screens are compatible. Check that they work

together before connecting the HD View—HDMI system.
