BLADEZ MOBY X Manuale utente

Page 1 of 15

Product Handbook

FOR THE BLADEZ MOBY X

GAS POWERBOARD

Model: PB-SE801-25

PB-SE801-25C

PB-SE801-26C

PLEASE BE SAFE WHEN RIDING . . .

ALWAYS WEAR A HELMET AND OBEY ALL LAWS!

GAS POWERED

Personal Transportation

Page 2 of 15

IMPORTANT

THIS IS A 2-CYCLE ENGINE!

IT REQUIRES A MIXTURE OF GASOLINE AND

2-CYCLE ENGINE OIL

1. 50:1 Gas/Oil Mixture Recommended. 2.6 oz of 2-cycle engine

oil mixed with one gallon of gasoline.

(Follow charging instructions in your Product Handbook)

2. Premium Unleaded (High-Octane) Recommended. Use only 89

octane or higher

3. Never start the engine inside a closed room or building.

Breathing exhaust fumes can be fatal.

USING REGULAR GASOLINE ONLY WILL

VOID YOUR WARRANTY!

This PRODUCT IS NOT INTENDED FOR EXTREME or

OFF-ROAD Use! Please take care of your POWERBOARD!

DO NOT JUMP or ABUSE THIS PRODUCT!

Failure to follow these instruction and abuse will

VOID YOUR WARRANTY!

If you have any questions, please contact Bladez customer service

(866) 325-2339 x 1

or visit us on the web at

www.ebladez.com

Page 3 of 15

IMPORTANT

PLEASE READ THIS BEFORE USING THIS PRODUCT

READ THIS FIRST!

WARNING

This product does not conform to Federal Motor Vehicle Standards and is not

intended for operation on public streets, roads or highways. Serious injury can

result from the unsafe operations of this vehicle. Operator can minimize these

risks by using certain safety equipment such as: safety helmet, goggles,

gloves, elbow and kneepads and appropriate footwear.

DO NOT operate this product in traffic, on wet, frozen, oily or unpaved

surfaces or under the influence of drugs and/or alcohol. Avoid uneven

surfaces, potholes, surface cracks and obstacles.

BE CAFEFUL when riding this product in the rain or in wet conditions.

Recommended for users 16 YEARS OF AGE and older. CHECK with local

law enforcement about laws regarding the safe and legal use of your

POWERBOARD.

Ride SAFELY and OBEY ALL LAWS!

SAFETY

This product should not be used by pregnant people, persons without

excellent vision, balance, coordination, reflex, muscle and bone strength

and good decision-making capabilities.

Operators ONLY! – No passengers.

This product should not be used by minors without adult supervision.

This product should not be used by persons unwilling or unable to take

responsibility for their own actions.

•The user of this product assumes ALL risks associated with its use. To

minimize these RISKS, the user must wear safety helmet, goggles, gloves,

elbow and knee pads and appropriate footwear.

•High speed, jumps and trick manoeuvres may result in loss of control or

accidents.

Page 4 of 15

QUICK REFERENCE

Fuel

WARNING!

This is a two-stroke engine. Only run the engine on fuel, which is properly

mixed with 2-cycle engine oil.

Provide good ventilation when fueling or handling fuel.

Always use gas with a minimum octane number of 89.

Use 2-stroke engine oil only. Mix 50:1, gas:oil mixture.

Never use multi-grade (10W/30) or waste oil.

Always mix fuel and oil in a separate clean, gas safe container. Always

start by adding half the amount of fuel, which is to be used. Then add the

whole amount of 2-cycle oil. Mix (shake) the fuel container. Add the

remaining amount of fuel. Mix (shake) the fuel-oil thoroughly before filling

the fuel tank.

Fueling

WARNING!

Always shut the engine off when refuelling.

Slowly open the fuel tank, so that possible over-pressure disappears.

Before fueling, clean the tank cap area carefully, to insure that no dirt falls

into the tank. Make sure that the fuel is well mixed by shaking the

container.

Tighten the fuel cap carefully, after fueling.

Always move the unit at least 10 feet from the fueling area before starting.

Starting

Set the CHOKE LEVER to the CLOSED (UP) position.

Pull the recoil starter handle briskly, making sure to keep the handle in

your grasp, and not allowing it to snap back.

Once the engine is running, move the CHOKE LEVER to the RUN

(DOWN) position.

Note!

At this stage, if the engine does not start, repeat the starting procedure.

After starting the engine, allow the engine 2-3 minutes to warm up prior to

riding.

Stopping

Gradually decrease the engine speed to an idle speed and press the stop-

switch on the handlebar tube.

If a situation arises that is not covered in the manual, proceed

with caution and use good judgement.

Page 5 of 15

IF YOU HAVE ANY QUESTIONS OR NEED

ASSISTANCE,

PLEASE CALL BLADEZ, TOLL FREE AT:

(866) EBLADEZ

(866) 325-2339

MONDAY thru FRIDAY, 8am to 5pm PST

or visit us on the web at:

www.ebladez.com

BLADEZ AND AUTHORIZED TANAKA DEALERS

FOR ALL YOUR POWERBOARD NEEDS

DO NOT TAKE YOUR

BLADEZ POWERBOARD BACK

TO THE STORE!

Page 6 of 15

TABLE OF CONTENTS

QUICK REFERENCE 4

GETTING TO KNOW YOUR BLADEZ POWER BOARD 7

PACKAGE CONTENTS 8

GETTING STARTED 8

Unfolding................................................................................................................................ 8

Fueling.................................................................................................................................... 8

Starting................................................................................................................................... 9

Riding ................................................................................................................................... 10

Braking ................................................................................................................................. 10

FOLDING AND STORAGE 10

MAINTENANCE 11

RECOMMENDED TOOLS .................................................................................................... 11

CARBURETOR ADJUSTMENT............................................................................................ 11

TIRES AND WHEELS ........................................................................................................... 12

MAINTENANCE SCHEDULE................................................................................................ 13

Page 7 of 15

GETTING TO KNOW YOUR BLADEZ POWER BOARD

Before riding your MOBY X, please get acquainted with the following features:

PowerBoard Features:

1. THROTTLE LEVER

2. BRAKE LEVER

3. FRONT WHEEL V-BRAKE

4. 2-STROKE ENGINE

5. FOLDING HANDLE

6. KICKSTAND

7. DECK

8. REAR BAND BRAKE

9. KILL SWITCH

10.T-Handle Stem

11.DRIVE CHAIN

12.MUD GUARD

Motor Features:

13.RECOIL STARTER

14.GAS TANK

15.CHOKE LEVER

16.PRIMER BULB

17.CARBURETOR

18.MUFFLER

19.SPARK PLUG

Page 8 of 15

PACKAGE CONTENTS

Your Bladez MOBY comes with the following items in the box. Please locate all of

the following:

1. The Bladez MOBY X Gas Power Board

2. Tanaka Spark Plug Wrench

3. Allen Wrench

4. Product Handbook

GETTING STARTED

Please read and understand these instruction and the OPERATING

PROCEDURES section, prior to starting or riding your Power Board

Unfolding

1. To unfold the MOBY, begin by pressing

down on the FOLDING HANDLE with

one hand (Fig. 1), while gently pulling up

on the handlebars with the other.

2. Fully extend the handlebars to their

upright position until you feel the

mechanism lock into place.

3. When you first take the MOBY out of the

box, the Handlebar is not connected to

the T-Handle Stem. Remove the top

bracket from the stem and attah BRAKE

LEVER and Throttle LEVER are in the

down position for shipping. Using the

provided Allen Wrench, loosen the

tension bolt, and adjust the levers to a

comfortable position.

Fueling

This is a two-stroke engine. Always run

the engine using fuel, which is mixed

with 2-cycle engine oil.

PLEASE READ OPERATING

PROCEDURES BEFORE FUELING!

4. Mix fuel (minimum 89 octane) and 2-

cycle engine oil in separate container

(Fig. 3). Use Tanaka Perfect Mix or a

quality 32:1 2-cycle oil. Make sure the

Page 9 of 15

fuel is well mixed by shaking the

container.

5. Make sure that the engine is OFF while

fuelling.

6. Slowly open the GAS CAP, so that

possible over-pressure disappears.

7. Clean the tank cap area to make sure

that it is free from excess dirt and debris.

* Make sure that no dirt falls into the gas

tank.

8. Pour pre-mixed Gas/Oil mixture into the

GAS TANK. * Do not overfill.

9. After fueling, replace the GAS CAP and

tighten.

Starting

Move at least 10 feet away from where

you filled up the gas.

10.Push on the bladder (Primer Bulb)

several times to draw gas into the

engine. (Fig. 4)

11.Set the CHOKE LEVER to the CHOKED

(UP) position. (Fig. 5)

12.Pull the RECOIL STARTER briskly,

making sure to hold the handle in your

grasp. (Fig. 6) * Note: Do not allow it to

snap back, let it back slowly. You may

want to give it a little throttle by gently

squeezing the GAS LEVER.

13.It may be necessary to REPEAT step 11

several times.

When starting the MOBY X for the first

time, it may be necessary to pull the

starter handle 15-20 times until it starts.

14.Once the engine has started, quickly

move the CHOKE LEVER into the RUN

(DOWN) position. (Fig. 5)

15.After engine is started, let it warm up for

2-3 minutes before riding.

Page 10 of 15

IF THE MOTOR STALLS AT IDLE SPEED,

IT MAY BE NECSSARY TO ADJUST THE

IDLE SPEED ON THE CARBURETOR.

Please refer to Carburetor Adjustment in the

Maintenance section on page 12 for

instructions on how to adjust idle speed.

Riding

16.Makes sure that all of the exposed bolts

and screws are tightened.

17.Raise the kickstand to its upright

position.

18.Make sure the engine is running.

19.Put one foot on the deck of the MOBY X.

While pushing off with the other foot,

gently depress the THROTTLE LEVER,

on the right side of the handlebars. The

MOBY will begin to move on its own

power.

20.Control your speed by pressing and

releasing the accelerator lever. The

harder you squeeze, the faster you will

go.

NOTE: Stand firm but relaxed. Keep weight

between the wheels. Don’t stand too close

to the front or lean too far back. Shift your

weight to the rear when applying brakes,

and lean toward the front when

accelerating. Keep feet apart for more

stability.

Braking

21.To brake, release the THROTTLE

LEVER and depress the BRAKE LEVER

(on the left side of the handlebars).

22.Gradually decrease the engine speed to

idle.

23.To turn the unit off press the kill switch

button on the handlebar tube. (Fig. 7)

This will turn the engine OFF.

FOLDING AND STORAGE

When you are done riding the MOBY X you can fold it down for compact storage,

carrying and transportation. To fold down the MOBY X, use one hand to push down

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali BLADEZ Scooter

BLADEZ

BLADEZ ION 150 Manuale utente

BLADEZ

BLADEZ MOBY XS PB-SE830PF Manuale utente

BLADEZ

BLADEZ E-LITE 250 Manuale utente

BLADEZ

BLADEZ Travel Mate DKS280 Manuale utente

BLADEZ

BLADEZ PRESIDENT Manuale utente

BLADEZ

BLADEZ ION 150 Manuale

BLADEZ

BLADEZ XTR-COMP IIPB-SM 818 Manuale utente

BLADEZ

BLADEZ PB-SM 817 Manuale utente

BLADEZ

BLADEZ PB-SM804SA Manuale utente

BLADEZ

BLADEZ Sport DKS200 Manuale utente

BLADEZ

BLADEZ ION 450 Manuale utente

BLADEZ

BLADEZ DKS500 AMBASSADOR Manuale utente

BLADEZ

BLADEZ DKS320 EXECUTIVE Manuale utente

BLADEZ

BLADEZ XTR-HD Manuale utente

BLADEZ

BLADEZ PB-SE802 Manuale utente

BLADEZ

BLADEZ PB-SM1816 Manuale utente

BLADEZ

BLADEZ XTR Street PB-SM1806 Manuale utente

BLADEZ

BLADEZ Travel Mate DKS280 Manuale utente

Manuali Scooter popolari di altre marche

TEKTRO

TEKTRO CHEETAH Manuale utente

Douglas

Douglas Vespa Sprint Guida all'installazione

PLAYTIVE

PLAYTIVE AS-2448 Manuale utente

Ebinger

Ebinger DONKEY XL Manuale utente

Flyer

Flyer Mountain Guida utente

BackCountry eBikes

BackCountry eBikes Storm Manuale utente

equipmed

equipmed FreeRoam II Manuale utente

Yoto

Yoto Lion Manuale utente

WESTHILL BIKES

WESTHILL BIKES LINK Manuale utente

BAnff

BAnff eProdigy series Manuale utente

Winther

Winther 475 Manuale utente

Jetson

Jetson JBZL17 Manuale utente

First Choice Mobility

First Choice Mobility Roma Medical Corella S741 Manuale utente

Carrera

Carrera impel Manuale utente

Afikim

Afikim Superlight SL-3 Manuale utente

CareCo

CareCo ZOOM Manuale utente

Douglas

Douglas Vespa G.S. Manuale utente

Gazelle

Gazelle with BOSCH System Manuale utente
