Quick User Guide

Mobile phone SL 01

Table of Contents
Safety instructions...............................................................................2
Technical Specifications ......................................................................4
Insert the memory card and SIM card ...............................................5
Switch the device on and off ..............................................................6
Using the Phone’s Buttons..................................................................6
Manage calls........................................................................................6
1 Make calls.................................................................................6
2 Disable Phone Calls (Airplane mode)......................................7
3 Receive a call............................................................................7
4 Emergency calls .......................................................................7
The Home screen ................................................................................7
1 Notification bar ........................................................................8
2 Application Launcher ...............................................................9
Handling and maintenance.............................................................. 10
SIM cards .......................................................................................... 11
Recycling your device..................................................................... 11
Declaration of Compliance ............................................................ 12


1. Safety instructions

ATTENTION: Please read this guide carefully. Failure to comply with

the safety regulations may be dangerous or illegal, and the

manufacturer can not be held liable for any malfunction resulting

from improper use.

Safe switch-on

The owner of the device is responsible for the use of the device.

Never switch the device on in areas where wireless devices are

prohibited or radio interference may be dangerous.

Road safety

Observe the local laws and regulations regarding smartphone usage

while driving. If you make a phone call while driving, observe the

following rules: Focus on driving to become aware of traffic

conditions; If the device has a hands-free function, use handsfree. If

the traffic situation requires, stop the car before you pick up the

phone.

Interference

Wireless devices may be sensitive to interference that affects

performance.

Electronic devices

To avoid demagnetisation, do not leave your device for a long time

close to electronic devices.

Use in hospitals

Hospitals and other healthcare facilities can use devices that are

particularly sensitive to RF signals. Switch off your phone if

prohibited signals are instructed to do so, or hospital staff ask for it.

Electrical medical devices

Your phone is a radio transmitter that can interfere with electronic

medical devices or implants such as hearing aids, pacemakers, insulin

pumps, and so on. operation. We recommend that you keep a

distance of at least 15 cm between the implant and the device, never

wear your phone in the breast pocket. Follow the instructions of the

manufacturer of the medical device. If you have a medical implant

and have any other questions about using mobile or wireless devices,

ask your doctor.

Use on the airplane

Your device supports flying mode, please use this feature on the

airplane. Follow the instructions on the airplane.

Explosion hazards and restricted areas

Turn off the device in explosion hazardous areas. Sparks in such

places may lead to an explosion or fire that may result in serious

injury or death. Turn off the devicce at gasoline or gas filling stations,

especially near the fuel pumps. Follow the instructions strictly in

locations such as fuel tanks, chemical plants, and explosive

substances.

Use environment

The device complies with the recommended emission values for

radio waves when kept at a minimum distance of 1.5 cm from the ear.

When carrying the phone in a case, belt clip or holder, make sure

that it does not contain metal and that the phone is slightly

distracted from the body. When using other accessories, it is not

possible to operate in accordance with radio frequency guidelines. If

you do not use a case and do not hold the phone on your ear, keep it

at least 2.5 cm away from your body, especially during data transfer.

Proper use

Please do not attempt to disassemble the device. If the product is

defective, contact your distributor.

Battery and other accessories

Only use parts and accessories approved by the manufacturer. Using

non-factory accessories and spare parts may result in warranty loss.

Please do not charge the device before inserting the battery. Do not

short-circuit the battery.

Charge the appliance in a well-ventilated and suitable temperature

environment away from flammable and explosive materials. Handle

the used battery according to local regulations and do not throw it

into household trash.

Water resistance

The appliance is not waterproof and dry. Precipitation, fog, and other

liquids can corrode electronic circuits. If moisture has reached the

phone, remove the battery and contact the dealer.

Backup

Make a backup of all the data stored on your device.

Connect to another device

Before connecting an external device, read the safety instructions in

this manual. Do not connect an incompatible device.

2. Technical Specifications

Basic Features

•AndroidTM 7.0 Nougat

•5” FWVGA display, 854x480 pixel

•2 MP front camera

•8 MP back camera

•1.3 GHz Quad Core processor

•1 GB RAM + 8 GB ROM memory

•microSD card up to 32 GB

•Dual SIM / Single SIM + SD card

•Multimedia functions

•Wi-fi

•Bluetooth

•2200 mAh battery

•GSM 900 / 1800 MHz

•WCDMA 900 / 2100 MHz

Android is a trademark of GoogleTM Inc.

Power Supply Features:

•Input: AC 100-240V~50/60Hz 0.25 A

•Output: DC 5.0V –1.0 A

SAR value:

•0,257 W/Kg (Head)

•0,761 W/Kg (Body)

3. Insert the memory card and SIM card

When subscribing to a service provider, they provides a SIM card to

use the network. Your SIM card has a phone number and various

services, but you can store data on it, for example. phone numbers.

The two SIM sockets allow you to connect to two types of network.

Remove the back cover and insert the SIM cards according to the

mark on the device, as shown in the illustration.

The label on the phone indicates the direction of insertion of the SD

card:

Then insert the battery and reconnect the back cover.

4. Switch the device on and off

Press and hold the Power button to turn on the power.

Press and hold the power button and select “Power off” from the

Options menu.

5. Using the Phone’s Buttons

Button

Description

Menu: Opens the related menu with

additional options and actions, depending on

the application. Press and hold to open a list

of recent applications.

Home: returns to Home screen.

Back: returns to the previous screen you were

working in

6. Manage calls

6.1 Make calls

•Tap the icon on main menu or the home screen to dial the

desired number.

•Touch the icon on main menu or the home screen to

make a call from contact, groups or favorites.

•To dial an international number, touch and hold the 0 key to

enter the Plus (+) symbol, and then enter the international

country prefix, followed by the phone number

•Touch the icon to call with SIM 1 or SIM 2.

•Press the Volume Up/ Down keys to adjust the call volume.

•You can access Call Logs, Contacts from the dialer screen.

•While during a call, touch the icon to end a call.

6.2 Disable Phone Calls (Airplane mode)

Some locations like airplanes may require you to turn off your mobile,

Wi-Fi, and Bluetooth wireless connections.

•Press and hold the Power button.

•Touch the Airplane mode.

6.3 Receive a call

In an incoming call, you can choose from the following options:

•Drag the phone icon to the right to receive the call.

•Drag the phone icon to the left to reject the call.

•Drag the phone icon upwards to reject with SMS.

6.4 Emergency calls

You can also make emergency calls without a SIM card. For more

information, contact your network service provider.

7. The Home screen

When you sign in, the home screen

opens.

The Home screen is your starting point

to access all the features on your phone.

Touch the main menu icon at the

bottom of the screen to view all

installed applications.

The status bar shows the time,

signal strength, battery

satus and notification

Touch and hold an empty

spot to change wallpaper.

7.1 Notification bar

The notification bar shows your device status and notifications.

Notification icons indicate new messages and events. When a new

notification arrives, its icon appears in the Notification Bar.

Notification Icons Status Icons

To see more information about notifications, open the notification

panel by swiping your finger over the top of the screen.

Status icons:

Icon

Description

Icon

Description

Signal strength

indicator

Alarm has

been set

New missed calls

Wi-Fi is

activated

USB is connected

Bluetooth is

The headphone is

being used

Battery

charging

symbol

New message from

SIM 1

Airplane mode

is activated

Close the notification bar:

Drag the bottom of the notification panel to the top of the screen or

simply press the back button. The notification panel will also close

when responding to a notification.

7.2 Application Launcher

Press the Launcher icon to enter the

Main Menu. From here you can access all

installed applications and widgets.

Touch the app to start.

To add an application shortcut to the

desktop screen, press and hold it until it

vibrates and enters Home screen. Place it

and release your finger.

Slide the Launcher left or right to bring

more icons into view.

As soon as you install a new application, it comes in this list.

To access widgets, press the menu button

on the Home screen, then tap the widget

icon at the bottom of the screen. Widgets

can not be started as an application.

Press and hold the selected widget until it

vibrates and the Home screen open. Place

and release your finger from the screen.

The app may request further action to

activate the widget.

You can configure the widget in the

submenu, for example, size. The options

displayed, depend on the given widget. If

there is not enough space on the Home

Altri manuali per SL 01

Indice

Lingue:

Altri manuali Blaupunkt Telefono cellulare

Blaupunkt

Blaupunkt FM 01 Slider Manuale di istruzioni

Blaupunkt

Blaupunkt SL 04 Manuale utente

Blaupunkt

Blaupunkt FM03i Manuale utente

Blaupunkt

Blaupunkt V18 Manuale utente

Blaupunkt

Blaupunkt TX60 Manuale di istruzioni

Blaupunkt

Blaupunkt FM 03 Manuale di istruzioni

Blaupunkt

Blaupunkt BS 06 Manuale utente

Blaupunkt

Blaupunkt BS 06 Manuale di istruzioni

Blaupunkt

Blaupunkt FM 01 Manuale di istruzioni

Blaupunkt

Blaupunkt BP Car Phone 3.0 C Manuale utente

Blaupunkt

Blaupunkt FS 01 Manuale utente

Blaupunkt

Blaupunkt FM 02 Manuale di istruzioni

Blaupunkt

Blaupunkt SL 04 Manuale di istruzioni

Blaupunkt

Blaupunkt SAND Manuale di istruzioni

Blaupunkt

Blaupunkt FM 03 Manuale utente

Blaupunkt

Blaupunkt FM 01 Manuale utente

Blaupunkt

Blaupunkt SM 02 2019 Manuale di istruzioni

Blaupunkt

Blaupunkt SL plus02 Manuale utente

Blaupunkt

Blaupunkt SL 05 Manuale utente

Blaupunkt

Blaupunkt FS 03 Manuale di istruzioni

Blaupunkt

Blaupunkt FS 03 Manuale di istruzioni

Blaupunkt

Blaupunkt SL 02 Manuale utente

Blaupunkt

Blaupunkt SM 02 Manuale di istruzioni

Blaupunkt

Blaupunkt BS 04 Manuale di istruzioni

Manuali Telefono cellulare popolari di altre marche

Zte

Zte BLADE A520 Manuale utente

Nokia

Nokia Lumia 620 Manuale utente

Blackbe;rry

Blackbe;rry KEYone Manuale utente

Bea-fon

Bea-fon X5 Premium Manuale utente

Blackbe;rry

Blackbe;rry 8707 Series Manuale utente

Blackbe;rry

Blackbe;rry Storm Istruzioni operative

LG LM-X420QN Manuale utente

LifeWatch

LifeWatch V Manuale utente

Bea-fon

Bea-fon SILVER LINE SL860 Manuale utente

IKI Mobile

IKI Mobile KF4.5i Manuale utente

Hitech

Hitech HT-850 Manuale utente

Yezz

Yezz Fashion F10 Manuale utente

Point Mobile

Point Mobile PM60 Manuale utente

Blackbe;rry

Blackbe;rry Q10 Manuale utente

Blackbe;rry

Blackbe;rry Bold 9900 Manuale utente

Blackbe;rry

Blackbe;rry STORM 9500 - VERSION 5.0 Manuale utente

LG LM-K420EMW Manuale utente

ISAFE MOBILE

ISAFE MOBILE IS655.2 Manuale utente
