COMMERCIAL

SERIES

OWNER’S MANUAL AND USER GUIDE

TABLE OF CONTENTS

SECTION 1 - IMPORTANT SAFEGUARDS��1

SECTION 2 - UNPACKING��3

SECTION 3 - GETTING TO KNOW YOUR BLENDER��3

SECTION 4 - INSTALLATION & OPERATIONAL OVERVIEW��4

4.1 - STEALTH 875™��4

4.2 - CONNOISSEUR 825™ ��16

4.3 - CHEF 775™ ��18

4.4 - EZ 600™��20

SECTION 5 - CARE AND CLEANING��22

SECTION 6 - TROUBLESHOOTING��22

SECTION 7 - WARRANTY ��26

SECTION 1: IMPORTANT SAFEGUARDS

IMPORTANT INFORMATION

Read all instructions carefully before using your Commercial series blender�

Following these instructions will help prevent injuries and damage to the machine

and will ensure that you have the best possible experience with your Blendtec®

Commercial series blender�

1.1 SAFETY CERTIFICATION

The Commercial series blenders are certiﬁed to required safety standards�

This certiﬁcation ensures that your Commercial series blender has been tested

for electrical and mechanical safety� The safety standards have been developed

over many years to prevent injury, ﬁre and damage� Part of the certiﬁcation process

includes quarterly audits to ensure that Blendtec is producing equipment to these

stringent criteria�

1.2 AVOID CONTACT WITH MOVING PARTS

• ALWAYS keep ﬁngers, hands, hair and clothing away from all moving parts�

• ALWAYS keep all utensils away from the drive socket and blender jar blades

during operation as utensils may damage blades or the blender jar�

• NEVER put hands into the blender jar or add substances by hand when the

blender jar is on the motor base�

• NEVER touch the blade with your ﬁngers whether it is on or off the motor base�

• NEVER place jar into drive socket if blender motor is operating�

• DO NOT rock or remove the blender jar during operation�

These precautions will prevent personal injury and/or damage to the blender�

1.3 NEVER OPERATE THE BLENDER IF IT APPEARS DAMAGED

If the blender malfunctions, call your service agent ﬁrst� If it is dropped or damaged

in any way, return the blender to a Blendtec service agent immediately for

examination, repair, electrical or mechanical adjustment, or possible replacement�

1.4 NEVER OPERATE BLENDER IN LIQUID

To protect against the risk of electrical shock do not put the motor base in water or

other liquid� Do not use the blender outdoors where it is subject to precipitation�

1.5 NEVER PUT NON-FOOD ITEMS INTO JAR

Utensils, rocks, and glass are dangerous if placed in jar� Damage caused by such

foreign objects will void the warranty� Keep hands and utensils out of jar while

blending to reduce the risk of severe injury to persons or damage to the blender�

Utensils may only be used when the blender is not running�

1.6 NEVER OPERATE THE BLENDER WITHOUT THE LID IN PLACE

1.7 NEVER OPERATE THE BLENDER USING ATTACHMENTS NOT

SOLD BY BLENDTEC

The use of any unauthorized attachments may cause ﬁre, electric shock, and/or

injury and will void the warranty�

1.8 BLENDER JAR MUST BE PROPERLY IN PLACE WHILE

APPLIANCE IS OPERATING

1.9 USE CAUTION WHEN BLENDING HOT LIQUIDS

Your Commercial series blender may have a vented lid that acts as a pressure

relief to allow steam to escape� Be careful not to come in contact with any steam�

1.10 POWER CORD PRECAUTIONS

• NEVER operate with a damaged cord or plug� If the supply cord is damaged it

must be replaced by the manufacturer or authorized service agent to avoid

a hazard�

• DO NOT permit the cord to hang over the edge of the work surface�

• NEVER use an extension cord with the unit�

• Unplug the blender motor when not in use, before changing blender locations,

or cleaning�

EACH POWER UNIT MUST BE PROTECTED BY A SEPARATE CIRCUIT BREAKER

OR FUSE, SEE MODEL FOR SPECIFICATIONS

1.11 NEVER ATTEMPT TO REPAIR THE POWER UNIT

Never remove the blender motor cover� The blender motor does not contain self-

adjustable or serviceable parts� A qualiﬁed service agent must make all service

adjustments� Removing the cover or attempting to service the blender will void

the warranty�

1.12 TURN THE BLENDER OFF WHEN NOT IN USE

1.13 AVOID TOUCHING THE BLENDER DRIVE SOCKET OR JAR

SHAFT AFTER USE!

The blender drive socket and jar shaft may become very hot after blend cycles�

1.14 SAFETY

This appliance is not intended for use by persons (including children) with lack of

experience and knowledge, unless they have been given supervision or instruction

concerning use of the appliance by a person responsible for their safety� Children

should be supervised to ensure that they do not play with the appliance�

1.15 NEVER OPERATE THE BLENDER WITH MORE THAN THE

MARKED CAPACITY OF THE JAR

SECTION 2: UNPACKING

SAVE ALL PACKAGING MATERIALS AND INSTRUCTIONS FOR FUTURE USE

2.1 UNPACKING YOUR BLENDER

You should have received the following items:

• Commercial series blender motor base

• One or more blender jars with lid and sound enclosure*

• Additional literature may be included depending on package conﬁguration�

Sound enclosure is available only on the Stealth 875™

and Connoisseur 825™ models�

1� Remove blender motor base, blender jar, lids and sound enclosure (if included

with model) from packaging�

2� Unwind the power cord�

3� Check for any packing material that may have blocked ventilation holes on the

underside of the blender motor base�

4� Inspect all items to ensure no damage occurred during shipment�

5� If any damage has occurred, contact your Blendtec service agent immediately�

2.2 RECORDING YOUR SERIAL NUMBER AND DATE OF PURCHASE

Record your blender motor serial number and date of purchase in the space

below� You will need these when contacting Blendtec for service or questions�

Motor Serial #(Found on bottom of motor base):_______________________

Date of Purchase: ____________________________________________

Purchased From: _____________________________________________

2.3 REGISTERING YOUR BLENDER

SECTION 3: GETTING TO KNOW YOUR BLENDER

3.1 BLENDER MOTOR BASE

• Smart Touch Interface: Varying models consist of preprogrammed cycles,

incremental speed cycles, timed cycles, a Stop button and a Pulse button�

• Hardened Metal Drive Socket: This is where the jar couples with the motor to turn

the blade assembly; made of hardened metal�

• Information Center: This displays the number of times a blend cycle button has

been pressed� It also indicates overload or over-temperature conditions�

• Power Unit: This unit is located within the blender motor base and contains the

computerized electronics that run the blender�

• Motor Base Cover: Houses the power unit in a durable, plastic material�

• Power Cord: The power cord is located at the back of the motor base cover�

3.2 BLENDER JAR ASSEMBLY

The blender jar assembly consists of the blender jar, blade assembly, and lid�

These components are integrated to ensure consistently blended drinks and

greater operator safety�

• Lid: The lid seals liquids within the jar during blending� Some models have a

vent that provides pressure relief when blending hot foods�

• Jar: Your jar is durable, BPA-free, and easy to clean�

• Blade Assembly: The uniquely designed stainless steel blade provides fast,

consistent blending�

NOTE: Never operate the blender with more than the marked capacity of the jar.

3.3 POWER SPECIFICATIONS

Your Commercial series blender is certiﬁed for use with a speciﬁc circuit voltage,

depending on model� Make sure to check your model’s power speciﬁcations

and use a protected circuit when operating your unit�

SECTION 4:

INSTALLATION & OPERATIONAL OVERVIEW

4.1 STEALTH 875™

4.1.1 Installation

Stealth 875 Above Counter Installation

• Select a location that is near an electrical outlet� Also consider proximity to

ingredients, and patrons as well as available counter space�

• Place the blender on the counter in a spot where the air intake vents on the

sides and exhaust on the back of the blender are unobstructed�

• Ensure there is enough room above and around the unit to allow for unhampered

movement of the sound enclosure (see Figure 1 for measurements)�

• Plug the unit into an outlet with appropriate electrical protection�

Stealth 875 In-Counter - Preparation for Installation

Note: You may locate your Blendtec Stealth 875 in the same space as your

previous Blendtec in-counter blender. Just remember to ensure proper spacing

for the sound enclosure (see Figure 1 for measurements).

• Identify the desired blender location� Consider proximity to ingredients, and

patrons as well as available counter space� Also ensure that an electrical outlet

is readily accessible�

• Ensure the location meets all dimensional requirements (see Figures 1 and 3)�

• The countertop can be no thicker than 3/4” (19 mm)� A thicker countertop will

obstruct motor ventilation�

COMMERCIAL LINE DRAWINGS >> WILDSIDE+ JAR

SOUND ENCLOSURE

Figure 1. Stealth 875 Dimensions

Figure 2. Stealth 875 Components

BLADE ASSEMBLY

HARDENED METAL

DRIVE SOCKET & MOTOR

PLUNGER-FREE

EASY-CLEAN JAR

STEALTH 875™

• If installing more than one blender, allow 14”–16” (356–506 mm) of center-to-center

blender spacing�

• If installing a sound enclosure, allow a clearance of at least 5 ½” (140 mm) from the

sound enclosure to the wall and 26” (660 mm) from the countertop to any over-the-

counter cabinetry�

• Ensure lower cabinetry allows adequate airﬂow�

• The blender draws ambient air into the vent holes located on the upper sides

of the motor and then evacuates hot air through the vents on the bottom of the

motor� For the motor to cool properly, a sufﬁcient amount of air must be able to

circulate around the motor�

• There should be at least 6 ½” (165 mm) of space from the countertop to the

next lower shelf of the cabinet, leaving a minimum space of 3” (76 mm) between

the bottom of the motor and the lower shelf� Cabinetry should not be closed; it

should allow air to ﬂow freely from the outside to the inside of the cabinet space�

Plastic bags, cups, and so forth, should not be stored closer than 3” (76 mm) from

the bottom of the motor�

• Cut a hole in the countertop 4 3/8“ (111 mm) wide and 5 7/8” (149 mm) long (see

the countertop hole template in the appendix)� Ensure that the 4 3/8” (111 mm) sides

are parallel with the machine operator�

Note: Double check to ensure that all space requirements and measurements

are correct BEFORE cutting.

In-Counter Installation

• Feed the electrical cord through the hole in the countertop�

• Gently place the blender unit into the hole�

• Ensure the gasket is seated correctly, lying ﬂat against the counter surface and

not pinched by the housing�

• Plug the unit into an outlet with appropriate electrical protection�

Countertop Hole Template:

Figure 3. Stealth 875 In-Counter Clearance

5 ⅞” (149�22 mm)

4 ⅜” (111�125 mm)

4.1.2 Quick Start Guide

1� Touch the power icon to turn on the blender�

2� Raise the sound enclosure lid�

3� Place the blender jar on the motor base, ensuring the jar is completely seated

and the jar lid is secured�

4� Close the sound enclosure lid�

5� On the control surface, touch the desired blend cycle number, pulse icon or

desired location on the slider control bar�

6� Touch the cancel/exit icon to stop a blend cycle or manual operation before the

programmed time elapses�

4.1.3 Automatic Cycle Operation

Your Stealth 875 blender is preprogrammed with multiple blender proﬁles to help

operators achieve consistent blends with a minimum of training, trial, and error�

You can select from the following proﬁles and blend cycles:

Multipurpose Proﬁle*

Button 1: Small Milkshake

Button 2: Granita/Medium Milkshake

Button 3: Small Margarita/Ice Cappuccino

Button 4: Medium Smoothie 4

Button 5: Large Smoothie 4

Button 6: 50 Seconds @ Speed 7

*When you turn the blender on for the ﬁrst time this will be the default proﬁle�

Smoothie Proﬁle

Button 1: Small Smoothie w/Fresh Fruit

Button 2: Medium Smoothie 4

Button 3: Granita/Medium Milkshake

Button 4: Medium Smoothie 3

Button 5: Large Smoothie 4

Button 6: 50 Seconds @ Speed 7

Coffee Proﬁle

Button 1: Small Margarita/Ice Cappuccino

Button 2: Large Ice Cappuccino

Button 3: Small Slushy/Milkshake

Button 4: Granita/Medium Milkshake

Button 5: Large Smoothie 2

Button 6: 50 Seconds @ Speed 7

Milkshake Proﬁle

Button 1: Small Milkshake

Button 2: Granita/Medium Milkshake

Button 3: Milkshake w/Frozen Fruit

Button 4: Large Milkshake 1

Button 5: Large Milkshake 2

Button 6: Large Milkshake 3

4.1.4 11-Speed Capacitive Touch Slider + Pulse

Touch the mode button to switch from automatic to manual operation mode and

the 11-speed capacitive touch slider� The capacitive touch slider provides seam-

less precision speed control; simply move your ﬁnger up and down the slider to

ﬁne tune your blender’s speed� The blender will run for 90-second intervals in

this mode� Select the Pulse function to add a burst of speed and power�

4.1.5 Advanced Programming and Diagnostics

Use the programming mode to:

• Select a proﬁle

• Change preprogrammed cycle numbers

• Check blend cycle counts

• Check the diagnostic error log

• Use a custom proﬁle designed via the Blend Wizard™ (Blendtec’s online

programming tool)

To enter programming mode:

1� Touch and hold cancel button for 3 seconds�

2� Use the scroll arrow and the select icon to scroll and select the desired function�

Note: To return to the main menu from any submenu area, tap the cancel

button until the main menu screen appears.

The options available from the main menu are listed on the next page (num-

bered as displayed in the blender):

Scroll (visible in programming mode)

Power Cancel/Exit

Mode

Slider Control Bar

Preprogrammed Cycle Buttons

Pulse

Select (visible in programming mode)

1110

1. PROFILES

1. Standard Proﬁles

1� Smoothie

2� Coffee

3� Multipurpose

4� Milkshake

2. Custom Proﬁles

2. BLEND CYCLES

1. Standard Blend Cycles

1� Salsa

2� Batter

3� Whole Juice

4� Soup

5� Ice Cream

6� Small Margarita / Ice Cappuccino

7� Large Ice Cappuccino

8� Ice Crush / Milkshake

9� Small Slushy / Milkshake

10� Small Milkshake

11� Granita / Medium Milkshake

12� Milkshake with Frozen Fruit

13� Large Milkshake 1

14� Large Milkshake 2

15� Large Milkshake 3

16� Small Smoothie with Fresh Fruit

17� Medium Smoothie 1

18� Medium Smoothie 2

19� Medium Smoothie 3

20� Medium Smoothie 4

21� Large Smoothie 1

22� Large Smoothie 2

23� Large Smoothie 3

24� Large Smoothie 4

25� Large Smoothie 5

26� Large Smoothie 6

4.16 Selecting the Desired Proﬁle

1� Press and hold the cancel button for 3 seconds�

2� Select Proﬁles from the menu by touching the select button�

3� Use the scroll and select buttons to select either the Standard Proﬁles or Cus-

tom Proﬁles category�

4� After selecting the Standard or Customer Proﬁle category, you can scroll through

the proﬁles in the category and select the desired proﬁle�

5� “Make this the active proﬁle?” will appear on the screen� Press the select button

to conﬁrm or the cancel button to return to the previous menu�

4.1.7 Changing Programmed Cycle Buttons

Temporarily Change Cycle Buttons

To temporarily change cycle buttons when working in a selected proﬁle, com-

plete the following steps:

1� Press and hold the cancel button for 3 seconds�

2� Use the scroll button and then select Blend Cycles from the menu by

touching the select button�

3� Use the select button to choose the Standard or Custom Blend cycles�

4� Use the scroll button to ﬁnd your desired cycle, then press select�

5� Enter the number you want to assign to the cycle, then press select�

Note: After you have customized a cycle to a number button, you will notice

that an asterisk appears after the proﬁle name when you return to operation

mode. Loading a new proﬁle on your blender will reset the proﬁles back to

default cycle buttons.

Permanently Change Cycle Buttons

To permanently change the cycle buttons in a proﬁle you can export the revised

proﬁle to a USB drive and then import the proﬁle on the blender� Or you can edit

the proﬁle using the Blend Wizard (my�blendtec�com), and then export the proﬁle

to the blender�

Temporarily Disable Cycle Buttons

To temporarily disable a number or cycle button when working in a selected

proﬁle, complete the following steps:

1� Press and hold the cancel button for 3 seconds�

2� Use the scroll button and then select Blend Cycles from the menu by

touching the select button�

3� Use the select button to choose the Standard Blend Cycles�

4� Use the scroll button to ﬁnd Disable Button, then press select�

5� Enter the number button you want to disable, then press select�

Note: After you have disabled a number button, you will notice that an aster-

isk appears after the proﬁle name when you return to operation mode. The

disabled button will also not appear on control panel.

Loading a new proﬁle on your blender will reset the proﬁles and enable all

the cycle buttons again.

27� Ultrathick Smoothie 1

28� Ultrathick Smoothie 2

29� Ultrathick Smoothie 3

30� Ultrathick Smoothie 4

31� 50 Seconds @ Speed 1

32� 50 Seconds @ Speed 2

33� 50 Seconds @ Speed 3

34� 50 Seconds @ Speed 5

35� 50 Seconds @ Speed 7

36� 50 Seconds @ Speed 9

37� Pulse @ Speed 1

38� Pulse @ Speed 2

39� Pulse @ Speed 3

40� Pulse @ Speed 5

41� Pulse @ Speed 7

42� Pulse @ Speed 9

43� Disable Button

2. Custom Blend Cycles

3. CYCLE COUNTS

4. DIAGNOSTIC COUNTS

5. USB FLASH DRIVE

1� Import Proﬁle

2� Export Active Proﬁle

3� Export Counts

6. SETTINGS

1� Enclosure Safety Mode

2� Screen Standby

3� Blend Cycle Pause

4� Slider Lockout

5� Language� There are three

language options:

1� English

2� French

3� Spanish

7. BLENDER INFO

1312

Permanently Disable Cycle Buttons

To permanently change the cycle buttons in a proﬁle you can export the revised

proﬁle to a USB drive, and then import the proﬁle on the blender� Or you can dis-

able any number using the Blend Wizard (my�blendtec�com), and then export the

revised proﬁle to the blender�

4.1.8 The Blend Wizard

In addition to using the proﬁles and cycles preprogrammed on your blender, you

can use the Blend Wizard to create custom proﬁles and cycles� For instructions

on using the Blend Wizard to easily develop custom proﬁles and cycles, visit

my�blendtec�com�

Importing Custom Proﬁles and Cycles

After you’ve created your custom proﬁles and cycles using Blend Wizard and

downloaded them to a USB ﬂash drive, use the follow steps to import the ﬁle to

your blender�

1� Use a Phillips screwdriver to remove the USB cover at the top of the right side of

the blender�

2� Plug the USB ﬂash drive into the blender’s USB port�

Note: If the blender is in manual or automatic operation mode, the USB

ﬂash drive menu will automatically load on the screen. If the blender is in

programming mode, go to the main menu and select USB Flash Drive.

3� Select Import Proﬁle from the USB ﬂash drive menu�

4� Scroll through the items on the ﬂash drive and locate the desired custom proﬁle

ﬁle (by default named stealth�bpf)�

Note: Items with a + sign next to them are folders; if the custom proﬁle ﬁle

is in a folder, press the select button to open the folder.

5� Select the desired ﬁle� You will then be asked whether you want to import the

selected ﬁle�

6� Press the select button again to start the import process� After the ﬁle has been

imported, the proﬁle in the ﬁle will be automatically loaded as the active proﬁle

on the blender�

7� Remove the USB drive from the blender, and secure the cover on the USB port

with a Phillips screwdriver�

Secure Blender Feature

When creating or modifying a proﬁle via the Blend Wizard, one of the options is

to secure the blender� If you select this option, once you have downloaded the

proﬁle to a USB drive and then imported the proﬁle to the blender, some of the

advanced programming functions will be disabled�

The secured proﬁle will be the active proﬁle on the blender, another proﬁle

cannot be made the active proﬁle and a new proﬁle cannot be imported to the

blender (unless it was created via your Blend Wizard account)� Additionally, the

blend cycles in the proﬁle cannot be changed on the blender, and the Enclo-

sure Safety Mode, Screen Standby Time, Blend Cycle Pause and Slider Lockout

settings cannot be modiﬁed�

To unlock these features, complete the following steps:

1� Log on to your Blend Wizard account at my�blendtec�com�

2� Edit the secured proﬁle, selecting the option to turn off the secure blender

mode, or create a new proﬁle with the secure blender mode turned off�

3� Import the proﬁle to a USB drive, and then follow the instructions to import the

ﬁle to the blender�

Exporting and Transferring Proﬁles

To export proﬁles and transfer them to the Blend Wizard, complete the

following steps:

1� Ensure the proﬁle you want to export is the active proﬁle on the blender�

2� Use a Phillips screwdriver to remove the USB cover at the top of the right side of

the blender�

3� Plug the USB ﬂash drive into the blender’s USB port�

Note: If the blender is in manual or automatic operation mode, the USB

ﬂash drive menu will automatically load on the screen. If the blender is in

programming mode, go to the main menu and select USB Flash Drive.

4� Use the scroll button to ﬁnd Export Active Proﬁle and press the select button�

Note: If the USB ﬂash drive the ﬁle is being exported to does not already

contain the sth-prof.bpf ﬁle, the LED screen will display the question, “Export

proﬁle to the sth-prof.bpf ﬁle?” Press the select button to start the export

process. Press the cancel button to return to the previous menu.

If the USB ﬂash drive the ﬁle is being exported to already contains the sth-

prof.bpf ﬁle, the LED screen will display the question, “Export proﬁle and

overwrite the sth-prof.bpf ﬁle?” If you want to overwrite the ﬁle on the USB

ﬂash drive, press the select button to start the export process. If you do not

want to overwrite the ﬁle on the USB ﬂash drive, press the cancel button to

cancel the export.

5� After the export is complete, remove the USB ﬂash drive and secure the cover

on the USB port with a Phillips screwdriver�

6� Insert the USB ﬂash drive into a computer, and log in to the Blend Wizard

(my�blendtec�com)� Follow the instructions on the site to transfer the proﬁle to

your account�

4.1.9 Blender Settings

You can change various blender settings for optimal blending performance and

function based on your needs�

Enclosure Safety Mode

The enclosure safety feature prompts you to ensure the sound enclosure lid

is closed during motor operation� It will also turn off the motor if you raise the

sound enclosure during blending�

To enable or disable the enclosure safety feature, complete the following steps:

1� Press and hold the cancel button for 3 seconds�

2� Use the scroll button and then select Settings from the menu by touching the

select button�

3� Use the select button to choose the Enclosure Safety Mode�

1514

4� Use the scroll button to toggle between disabling and enabling the enclosure

safety feature�

5� Press the cancel button to return to the previous menu�

Screen Standby Time

You can adjust the length of time before the blender switches to standby mode

(15 minutes, 1 hour, 6 hours or 12 hours)�

To select a new standby time, complete the following steps:

1� Press and hold the cancel button for 3 seconds�

2� Use the scroll button and then select Settings from the menu by touching the

select button�

3� Use the select button to choose the Screen Standby�

4� Use the scroll button to ﬁnd your desired standby time, then press select�

5� Press the cancel button to return to the previous menu�

Blend Cycle Pause

When in automatic mode, this setting allows you to pause and resume a blend

cycle at the same time and speed�

To enable or disable the Blend Cycle Pause feature, complete the following steps:

1� Press and hold the cancel button for 3 seconds�

2� Use the scroll button and then select Settings from the menu by touching the

select button�

3� Use the select button to choose the Blend Cycle Pause�

4� Use the scroll button to toggle between disabling and enabling, the blend cycle

pause�

Note: When the Blend Cycle Pause is disabled, a cycle cannot be paused. It

can only be stopped by pressing the cancel button.

5� Press the cancel button to return to the previous menu�

Slider Lockout

The Slider Lockout feature allows you to disable the slider bar on the control

surface� When this feature is enabled, only proﬁles on the blender can be used

to operate the blender�

To enable or disable this feature, complete the following steps:

1� Press and hold the cancel button for 3 seconds�

2� Use the scroll button and then select Settings from the menu by touching the

select button�

3� Use the select button to choose the Slider Lockout�

4� Use the scroll button to toggle between disabling and enabling, the slider lockout�

5� Press the cancel button to return to the previous menu�

6� Language� There are three language options:

• English

• French

• Spanish

4.1.10 Blender Statistics

Blend Cycle Counts

You can review the total number of cycles run, the number of cycles run for each

control surface number, the number of times the pulse button has been used

and the number of times the slider control bar has been used�

1� Press and hold the cancel button for 3 seconds�

2� Use the scroll button and then select Cycle Counts from the menu by touching

the select button�

3� Use the scroll button to see the number of cycles run in each category�

4� Press the cancel button to return to the previous menu�

Note: The pulse count refers to pulse sets. For example, touching the pulse

button 5 times in a row will register as 1 pulse count. Touching the pulse

button, then a cycle number and then the pulse button will register as 2

pulse counts.

Diagnostic Error Log

You can review the diagnostic errors that have been logged on the blender�

1� Press and hold the cancel button for 3 seconds�

2� Use the scroll button and then select Diagnostic Counts from the menu by

touching the select button�

3� Use the scroll button to see the how many errors have occurred in each category�

4� Press the cancel button to return to the previous menu�

Exporting Blender Statistics

Exporting blender statistics (cycle counts, errors, settings and ﬁrmware versions)

is a way to save diagnostic information, which Blendtec’s customer service and

repair experts will use if problems arise with your blender�

To export blender statistics to a USB drive, complete the following steps:

1� Use a Phillips screwdriver to remove the USB cover at the top of the right side of

the blender�

2� Plug the USB ﬂash drive into the blender’s USB port�

Note: If the blender is in manual or automatic operation mode, the USB

ﬂash drive menu will automatically load on the screen. If the blender is in

programming mode, go to the main menu and select USB Flash Drive.

3� Use the scroll button to ﬁnd Export Counts, then press the select button� You will

be asked if you want to export counts to the sth-cnts�csv ﬁle�

4� Press the select button again to start the export process�

5� After the export process is ﬁnished, remove the USB drive from the blender and

secure the cover on the USB port with a Phillips screwdriver�

1716

4.2 CONNOISSEUR 825™

Quick Start Guide

1� Turn on the blender by toggling the power switch on the front of the blender�

2� Raise the sound enclosure lid�

3� Place the blender jar on the motor base, ensuring the jar is completely seated

and the jar lid is secured�

4� Close the sound enclosure lid�

5� On the touchpad, press the desired blend cycle number or pulse icon�

6� Push any blend cycle button to stop a blend cycle before the programmed

time elapses�

Automatic Cycle Operation

Your Connoisseur blender is preprogrammed with multiple blender proﬁles, to help

operators achieve consistent blends with a minimum of training, trial and error�

You can select from the following proﬁles and blend cycles:

Multipurpose Proﬁle*

Button 1: Small Milkshake

Button 2: Granita/Medium Milkshake

Button 3: Small Margarita/Ice Cappuccino

Button 4: Medium Smoothie 4

Button 5: Large Smoothie 4

Button 6: Pulse

*When you turn the blender on for the ﬁrst time this will be the default proﬁle�

Preprogrammed Cycles

For a complete list of preprogrammed proﬁles or cycles and instructions on how

to program and change proﬁles or cycles, please visit blendtec�com

Pulse Function

The Pulse button is used for chopping, mincing, whipping or other momentary

tasks that do not require a long blend cycle� You can also use the Pulse button

to quickly stir a blend before serving�

The Pulse setting runs at speed 7 and will only run while the Pulse button is held

down� When the button is released, the motor shuts off�

COMMERCIAL LINE DRAWINGS >> WILDSIDE+ JAR

SOUND ENCLOSURE

BLADE ASSEMBLY

HARDENED METAL

DRIVE SOCKET & MOTOR

MOTOR BASE

PLUNGER-FREE

EASY-CLEAN JAR

CONNOISSEUR 825™

Preprogrammed Cycle Buttons Pulse

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali Blendtec Miscelatore

Blendtec

Blendtec Mix n Blend II Guida rapida

Blendtec

Blendtec DESIGNER SERIES Guida

Blendtec

Blendtec ez Blender Manuale utente

Blendtec

Blendtec Home Blender Guida

Blendtec

Blendtec DESIGNER 625 Manuale utente

Blendtec

Blendtec Tom Dickson Extreme Blender Manuale utente

Blendtec

Blendtec 625D Manuale utente

Blendtec

Blendtec NITRO Blending Systems 2.0 Manuale utente

Blendtec

Blendtec Xpress Blender Manuale utente

Blendtec

Blendtec Wildside Plus Designer Series Guida

Blendtec

Blendtec Total Blender Guida

Blendtec

Blendtec Mix n Blend II Guida rapida

Blendtec

Blendtec DESIGNER SERIES Guida

Blendtec

Blendtec Designer Series WildSide Manuale utente

Blendtec

Blendtec DESIGNER SERIES Guida

Blendtec

Blendtec Professional Series Guida

Blendtec

Blendtec Q-SERIES Manuale utente

Blendtec

Blendtec CHEF Manuale utente

Blendtec

Blendtec Stealth Manuale utente

Blendtec

Blendtec Signature Series Manuale utente

Blendtec

Blendtec CLASSIC SERIES Wildside+ Guida

Blendtec

Blendtec Total Blender Guida

Blendtec

Blendtec Xpress Manuale utente

Blendtec

Blendtec PROFESSIONAL 800 Guida

Manuali Miscelatore popolari di altre marche

ROTOR

ROTOR 1125.201 Manuale utente

Braun

Braun Multiquick 5 Vario series Manuale utente

ARENDO

ARENDO MIRA 305424 Manuale utente

CHEF-BUILT

CHEF-BUILT CCB-3500 Manuale utente

Viconte

Viconte VC-4406 Manuale utente

Oster

Oster BLSTAB-CB0 Manuale utente

HOFFEN

HOFFEN MC-3005 Manuale utente

Black & Decker

Black & Decker BLC18750DM Manuale utente

Sunbeam

Sunbeam 4182 Manuale utente

Bialetti

Bialetti FMX35 Manuale utente

Black & Decker

Black & Decker BL8000 Manuale utente

Duronic

Duronic BL530 Manuale utente

Exquisit

Exquisit MS 3002 wes Manuale utente

Lumme

Lumme LU-KP1891A Manuale utente

Binatone

Binatone HB-735 Manuale utente

Moulinex

Moulinex LM936E10 Manuale utente

Oster

Oster VERSA Manuale di installazione e funzionamento

Ninja

Ninja NN210Q Manuale utente
