INTEGRAL ICE CUBERS
MANUAL OF INSTRUCTIONS FOR USE AND
INSTALLATION
Integral Icemakers
ICY20 ICY33
Instructions for Installation & Use
Congratulations and Thank You for purchasing this Blizzard Icemaker.
The experience of our engineers and design teams have meant that we
are able to bring this high specification product to you and by following
these instructions we hope and expect it to bring you problem free and
efficient usage in the future.
Please read this manual thoroughly and acquaint yourself with the correct
installation and operation methods. Adhering to these instructions will
minimise the risk of damage or injury to the user or the machine.
All repairs should be carried out by a suitably qualified person. if you are
in any doubt please contact the retailer in the first instance to report any
problems and use ONLY genuine Blizzard parts.
Upon Receipt of Your Icemaker –
•Ensure that the packaging shows no sign of damage incurred during
transit
•Ensure that the machine supplied matches the item requested on
the purchase order
•Check that the machine is not damaged externally and no parts are
missing
•Check that no internal damage has occurred during transit.
In the case of severe damage noted or parts missing please report
immediately to the delivery driver and retailer from which you have
purchased.
The illustrations in this manual are generic and may differ slightly from
the machine supplied.
Any illustration schematic or document supplied with the machine
remain the property of the manufacturer who retain copyright and
distribution rights.
The manufacturer has a commitment to continuous improvement and so
reserves the right to change the specification at any time without notice.
Description
The units described in this manual are self contained icemakers namely
with an integral storage bin. One half of their daily ice production capacity
can be stored in the self contained bin in which a thermostat controls the
ice level. This thermostat ceases ice production when stored ice come into
contact and resumes when ice is removed.
The system is hermetically sealed.
SAFE Y INS RUC IONS
•To correctly operate this machine the instructions MUST be
followed strictly. The manufacturer accepts no responsibility for
injury or damage caused by non observance of these instructions.
•In the instance of the power cable being damaged it must be
replaced ONLY by a suitably qualified engineer.
•Disconnect the electrical power before commencing any
maintenance or cleaning of the unit and ensure that hands are dry.
•The mains supply control switch must be within arms reach of the
installed machine.
•Do NOT remove any service panel secured with screws.
•The water shut off valve must also be within arms length of the
installed machine.
•If the unit is to be moved it is recommended that it be lifted and
NEVER dragged or pushed as this may cause damage to the legs.
•The icemaker should be connected to a sanitary drinkable water
supply.
•The icemaker bin is solely for the purpose of storing ice under no
circumstances should it be used to store/chill cans or bottles.
The manufacturer cannot be held responsible for improper use of the
machine as specified in this user manual
UNPACKING
As protection during transit the icemaker is packed on a pallet
surrounded by a heavy cardboard crate.
For moving the packed unit to site use a fork lift truck with forks no
thicker than 40mm
When unpacking carefully cut the retaining straps and lift the cardboard
crate up and away from the unit
Ensure the ice scoop is located inside the ice storage bin.
LOCA ING
Position the icemaker in it’s final location and make sure everything need
for installation is present such as:
•Power supply and disconnect switch
•Water supply and disconnect switch
•Waste water drain connection.
To prevent any intestinal infection to consumers of ice please ensure that
the water available is drinkable. If in doubt consult your supplier about
the possible installation of a water filter or conditioner.
O ENSURE OP IMAL PERFORMANCE FROM YOUR ICEMAKER, HE
FOLLOWING IS RECOMMENDED –
•Ensure that the minimum water temperature is not lower than
+5°C or higher than +40°C
•Minimum water pressure is not below 0.1MPa and maximum does
not exceed 0.5MPa
•The electrical supply available corresponds to the voltage and
ampacity of the machine specifications as indicated on the rating
plate
•The electrical cut off switch with fuse protection must be a 2 pole
type with minimum clearance of 3mm between open contacts
•The minimum ambient temperature should not be lower than
+10°C or the maximum higher than +40°C
•Ensure there is a minimum space around the cabinet vents of
150mm to allow air circulation.
•Ensure there are no heat sources (kitchen stoves cookers radiators
etc) near the machine and the environment isn’t too humid.
INS ALLA ION
•Check the machine is level and connect the plug to the electrical
cord in compliance with local regulations
•Replace any old/used water hoses with new ones and connect to the
water supply
•Ensure the drain is connected and set up properly using a spiralled
hose. It should have a minimum fall of 3cm per metre
•Open water shut off valve
•Insert plug into mains socket and set the main switch to the ON
position.
S AR UP
•Before starting the machine check the interior of the bin and
ensure it is clean and ready to receive ice using an appropriate mild
cleaning solution.
•Ensure the main switch is set to ON
•The first batch of ice should drop into the storage bin approximately
30 minutes from startup
•A EN ION – If the temperature of the room in which the
machine is placed is below 15°C the freezing cycle length will be
shorter (17 – 20mins). Alternatively if the ambient temperature is
30°C or above the cycle length will be longer (25 – 30mins)
•To stop the icemaker always use the specific hand disconnect
switch or the main unit ON-OFF switch.
DAILY PRECAU IONS
To prevent the build up of bacteria or other contaminants please observe
the following advice:
•Do not store anything in the ice bin
•Do not store explosive substances such as aerosol cans with
flammable propellant in this appliance
•Keep ice scoop clean and disinfected
•Keep the bin door closed when not in use
•Whilst cleaning floors around the machine ensure that dust does
not get sucked in by the fan motor.
O AVOID DAMAGE O HE UNI
•Never shut off the water supply whilst in operation
•Take care when opening and closing the door never slam or kick it
closed
•Do not place on or around the icemaker any objects that may limit
proper ventilation and jeopardize hygienic conditions
CLEANING AND MAIN ENANCE
Ensure the ice machine is well cleaned at least once a month or when the
ice cubes are improperly shaped
•Remove the spray platen from the interior of the evaporator case
•Thoroughly clean the spray platform by immersing in a solution of
lukewarm water and a descaling solution then rinse thoroughly with
clean water
•Wipe clean the ice storage area using a mild detergent solution
•Rinse them thoroughly disinfect it’s surfaces with a neural
antibacterial cleanser
•Do not use any harsh abrasive cleaners or materials and always
clean the unit with a soft cloth.
CLEANING OF HE WA ER CIRCUI
Special attention must be observed to the importance of cleaning the
water system. To perform this cleaning contact an appropriately
qualified person at least twice a year if you are unsure contact your
supplier in the first instance who should be able to recommend one.
It is recommended that a propriety brand of ice machine cleaner is used
to remove any mineral sediment and scale build up.
DISPOSAL
To protect the environment observe all current local regulations. When
the machine has reached the end of it’s life the following procedure must
be followed
1. All refrigerant and coils from the cooling circuit must be removed
by an authorised refrigeration contractor
2. Dismantle the machine and dispose of individual components in
appropriate recycling banks.
ROUBLE SHOO ING
In the unlikely event of a fault with your machine please observe the
following faults and their solutions. If they fail to solve the problem do
not carry out any repairs yourself and contact a suitably qualified
engineer.
THE MACHINE DOES NOT WORK
•Is the machine switched on and connected to the mains?
•Check blown fuses at the fusebox
•Ensure the plug is fully inserted into the power socket
ICE MAKING CAPACITY REDUCED OR INEFFICIENT
•Is the water shut off valve open?
•Is water and ambient temperature too high?
•Are there heating sources close to machine or any obstruction to
the ventilation?
HE ICE CUBES ARE NO FORMING NORMALLY
•Is there a sufficient water supply?
•Is the water inlet strainer clogged up?
•Are the water spray nozzle or the spray platform partially clogged
up?
This user manual has been compiled by Blizzard Refrigeration exclusive
to Pentland Wholesale Ltd.
For further information images or specifications please visit our website
www.pentlandwholesale.co.uk
For spares or parts breakdowns please contact our spares department on
0845 2410322
Or visit the website
www.pentlandparts.co.uk
