Blue Bamboo P200 Manuale utente
Battery
Packing List
Printer Paper
1A Power Adapter
(3A optional)
Front
Feed Button
USB Port
Menu Key
Power Jack MSR
Power
Button
Paper Cutter
Status LED
Cancel Key
Clear Key
Enter Key
Serial Port
Navigation
Key
Numeric Keypad
Battery
Cover
Back
Contact your distributor for replacement parts
Load Paper
Front
Printer
1. Open the lid.
2. Install paper roll with paper pointing up.
3. Pull out a small amount of paper, close lid.
Install Battery
1. Remove the battery cover.
2. Plug in the battery cable into the connector.
3. Install the battery into the slot and install the
battery cover.
Battery
Connector
Install SAM Card
1. Remove the battery cover and battery.
2. Open the card holder and insert the SAM card
with the electronic chip facing down and the
cut-out corner on top.
3. Close the card holder and lock it into
place.
4. Install the battery and the battery cover.
SAM Slot
Power & Charging
1. Insert the DC plug of power adapter* into
the power jack of printer.
2. Plug power adaptor into AC power outlet.
*Optional 3Amp power supply required when running without battery.
Power
Jack
For warranty period, repair and service
issues, please contact your distributor:
Europe-R&TTE Compliance Statement
Hereby, Blue Bamboo declares that this
equipment complies with the essential
requirement and other relevant provision
of Directive 1999/5/EC OF THE
EUROPEAN PARLIAMENTAND THE
COUNCIL of March 9,1999 on radio
equipment and telecommunication
terminal equipment and the mutual
recognition of their conformity(R&TTE).
CE NB Mark:
CE Statement
Smart Card
Position the smart card and insert it into the
smart card reader slot with the chip facing
down.
MSR
1. Position the card with the magnetic stripe
facing down and towards the printer.
2. Swipe it through the reader in either direction.
FCC Statement
FCC ID: UWJP200
This device complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference.
(2) This device must accept any interference received,
including interference that may cause undesired
operation.
PART 15.21 STATEMENT
(3) Changes or modifications not expressly approved
by the party responsible for compliance could void
the user's authority to operate the equipment.
(4) For receivers and Class B digital this product has
been tested and complies with the specifications for
a Class B digital device, pursuant to Part 15 of the
FCC Rules. These limits are designed to provide
reasonable protection against harmful interference
in a residential installation. This equipment
generates, uses, and can radiate radio frequency
energy and, if not installed and used according to
the instructions, may cause harmful interference to
radio communications. However, there is no
guarantee that interference will not occur in a
particular installation. If this equipment does cause
harmful interference to radio or television reception,
which is found by turning the equipment off and on,
the user is encouraged to try to correct the
interference by one or more of the following
measures:
· Reorient or relocate the receiving antenna
· Increase the separation between the equipment or
devices
· Connect the equipment to an outlet other than the
receiver's
· Consult a dealer or an experienced radio/TV
technician for assistance
Bluetooth
The P200 printer can communicate with
other Bluetooth SPP compatible devices,
such as peripheral equipment PDAs, mobile
phones, and computers. Confirm that your
host device supports the SPP (Serial Port
Profile) before using the P200 printer.
Bluetooth communication distance is up to
10m.
Default Device Name: P200
Default PIN Code: 1234
Environment
Operating Temperature:
0~40°C (+32° to 104°F)
Operating Humidity:
20~85%, no condensation
Storage Temperature:
-20~60°C (-4° to 140°F)
Storage Humidity:
10~90%, no condensation
WARNING:
• Do not disassemble the Printer, battery
or AC adapter. Only qualified technicians
may service the device.
• Do not use batteries, AC adapters or
Printer near water.
Caution
