Blue Technix Argos 3D-P320 Manuale utente

Argos 3D -

P320

Quick Start Guide

Version 1

Bluetechnix

Waidhausenstraße 3/19

A-1140 Vienna

AUSTRIA

[email protected]om

www.bluetechnix.com

Argos3D-P320 –Quick Start Guide

Document No.: 900-308 / A

Publication date: October 12, 2015

Subject to change without notice. Errors excepted.

transmitted for any purpose in any form or by any means, electronically or mechanically, without expressly

written permission by Bluetechnix GmbH.

Windows is a registered trademark of Microsoft.

Table of Contents

1Unboxing .......................................................................................................................................... 5

1.1 In the box .................................................................................................................................. 5

1.2 Opening your Argos3D–P320 ................................................................................................... 5

1.3 Connecting your Argos3D–P320 .............................................................................................. 6

1.4 Connector Overview ................................................................................................................. 6

1.4.1 Connecting the power supply............................................................................................ 7

1.4.2 Connecting the Ethernet Cable ......................................................................................... 7

2Downloading the Evaluation Software ............................................................................................. 8

2.1 Support website........................................................................................................................ 8

2.2 Start-up screen ......................................................................................................................... 9

2.3 Prepare your Network Interface Card (NIC) ............................................................................ 10

3Start using your Argos3D–P320 with ‘BltTofSuite’ ........................................................................ 11

4System Requirements & Support................................................................................................... 13

4.1 Bluetechnix ToF Suite ............................................................................................................. 13

4.2 Support ................................................................................................................................... 13

5Product History .............................................................................................................................. 14

5.1 Version Information ................................................................................................................. 14

5.1.1 Argos3D–P320 ................................................................................................................. 14

5.2 Anomalies................................................................................................................................ 14

5.3 Document Revision History .................................................................................................... 14

6Index............................................................................................................................................... 15

The information herein is given to describe certain components and shall not be considered as a guarantee

of characteristics.

Terms of delivery and rights of technical change reserved.

We hereby disclaim any warranties, including but not limited to warranties of non-infringement, regarding

circuits, descriptions and charts stated herein.

Bluetechnix makes and you receive no warranties or conditions, express, implied, statutory or in any

communication with you. Bluetechnix specifically disclaims any implied warranty of merchantability or fitness

for a particular purpose.

Bluetechnix takes no liability for any damages and errors causing of the usage of this board. The user of this

board is responsible by himself for the functionality of his application. He is allowed to use the board only if he

has the qualification. More information is found in the General Terms and Conditions (AGB).

Information

For further information on technology, delivery terms and conditions and prices please contact Bluetechnix

(http://www.bluetechnix.com).

Warning

Due to technical requirements components may contain dangerous substances.

Quick Start Guide - Argos 3D - P320 Last change: 12 October 2015

Version 0.1

1Unboxing

1.1 In the box

Argos3D–P320

CAT5/7 Ethernet Cable

Quick Start Guide

Power Supply *

* Note

The power supply’s operating temperature is specified from 0 to +40°C. This represents not

the effective working temperature of the Argos3D–P320 sensor!

1.2 Opening your Argos3D–P320

To access the connector compartment unscrew the two screws on the Argos3D-P320 front and take

off the connector compartment lid.

Figure 1-1: Argos3D–P320 connector compartment screw positions

Quick Start Guide - Argos 3D - P320 Last change: 12 October 2015

Version 0.1

1.3 Connecting your Argos3D–P320

1.4 Connector Overview

a. Power Connector

b. Ethernet

c. General purpose input 1 & 2

d. General purpose output 1 & 2

e. Modulation Light Interface

f. Trigger

g. RS232 / RS485

h. DIP-Switch

i. Reset-Button

j. Debug-UART

k. Status LED

Marks Pin #1

b a c f

ed g i

h j

Figure 1-2: Argos3D–P320 connectors and interfaces

Note

Please follow the next steps in the right order to get your ‘Argos3D-P320’ up and running

correctly.

Quick Start Guide - Argos 3D - P320 Last change: 12 October 2015

Version 0.1

1.4.1 Connecting the power supply

To ensure, that your Argos3D–P320 works correctly, connect the ‘Argos3D’to a 12-30V DC power supply

using connector (a) and wait for approximately 20 seconds until the camera boots up.

Pin assignment on the power connector (a): Pin #1: +12V to +30V, Pin#2: GND

Note

The power supply connector is protected against wrong polarity but the ‘Argos3D’ will not

work in case you don’t use the correct polarity! If the Argos3D–P320 doesn’t work please

check the power supply polarity first!

1.4.2 Connecting the Ethernet Cable

Plug in the Ethernet cable (b) and connect your Argos3D–P320 to your PC.

Figure 1-3: Argos3D–P320 with connected power supply and Ethernet cable

Quick Start Guide - Argos 3D - P320 Last change: 12 October 2015

Version 0.1

2Downloading the Evaluation Software

Please log in to our support website at https://support.bluetechnix.com/ and download the Argos-P320

customer software package. This package also includes the Bluetechnix ToF-Suite.

2.1 Support website

Select ‚free access‘

Figure 2-1: Download Evaluation Package

Quick Start Guide - Argos 3D - P320 Last change: 12 October 2015

Version 0.1

2.2 Start-up screen

Figure 2-2: Start-up screen

Please select your product: Argos 3D –P320

Please follow the instructions on the WEB-Site

Quick Start Guide - Argos 3D - P320 Last change: 12 October 2015

Version 0.1

2.3 Prepare your Network Interface Card (NIC)

Once you have connected your Argos3D–P320 to a Network Interface Card (NIC) of your PC give this NIC

the IP-Address 192.168.0.1 with a subnet mask of 255.255.255.0.

No driver must be installed on your PC!

The Argos3D–P320 uses IP-Address 192.168.0.10 with subnet mask 255.255.255.0.
