4

2001 model year changes

INSTRUMENT CLUSTER SIA RESET

Model: E38,E39,E46,E52,E53

Production Date: E46 from 9/99

E38,E39,E53 from 9/00

On 2001 vehicles without the diagnostic connector in the engine compartment, the use of

the SIA reset tool is not possible. The service indicator may be reset using the reset mode

in the instrument cluster.

Reset procedure for high and low clusters with SIA III using the Reset Mode:

• Ignition key must be “off”

• Press and hold the trip odometer reset button in the instrument cluster (left button), and

turn the ignition key to the first position.

• Keep the button pressed for approximately 5 seconds until one of the following words

appear in the display: “OIL SERVICE, or “INSPECTION”, with “RESET”.

The service due is shown with “reset” if the coded minimum consumption limit has been

reached and resetting is possible. If “reset” is not shown, the minimum limit has not been

reached and resetting is not possible.

• Press and hold the reset button again until the word “RESET” begins to flash.

½

P

1

20

40

60 80 100

120

140 0

2345

6

7

!ABS

20 DIGIT READOUT

123456 PR ND S

432

122 4 72 0F

miles

0

10

15

20

40

+

RESET SIA: -919 L

TURN THE KEY TO

POSITION 1 (KL R)

PRESS AND HOLD

LEFT BUTTON.

KEEP PRESSED FOR

5 SECONDS AFTER

KEY IS SWITCHED

ON.

TAP BUTTON TO

RESET DISPLAY.

12

Service interval reset: high cluster

5

2001 model year changes

• While the display is flashing, press the left button briefly to reset the service interval.

After the display has shown the new interval the following will appear: “END SIA”

The system can only be reset again after 10 liters (2.5gal) of fuel have been consumed.

Reset procedure for clusters with SIA IV using the Reset Mode. (possible from 9/99

for E46, MY2001 E52)

• Ignition key must be “off”

• Press and hold the trip odometer button in the instrument cluster (left button), and turn

the ignition key to the first position.

• Keep the button pressed for approximately 5 seconds until one of the following words

appear in the display: “OIL SERVICE, or “INSPECTION”, with “rESET”.

• Release the reset button and press and hold again until “rESET” begins to flash.

• While the display is flashing, press the left button briefly to reset the service interval.

After the display has shown the new interval, the following will appear: “END SIA”

The system can only be reset again after 10 liters (2.5gal) of fuel have been consumed.

OILSERVICE

15000 Miles

UNLEADED GASOLINE ONLY

0

12

20

km/h

MPH

1/min

x1000

40

60

80100120 140 160

180

200

220

240

1

0

2345

6

7

5030 20 15 12

20

40

60 80 100

120

140

11

Mmiles

ESET SIA END SIA

12

PRESS AND

HOLD LEFT

BUTTON TURN KEY TO POSITION 1

(KL R)

KEEP BUTTON

PRESSED FOR 5

SECONDS AFTER

KEY IS SWITCHED

ON.

TAP BUTTON TO

RESET DISPLAY

E46 service interval reset
