INSTRUCTION MANUAL
TABLE LANTERN HARLINGTON
5818921
BO-CAMP.COM NL-5126 RK 20
1/2
Main Lamp:
Rated power (W)
Rated voltage (V)
Dimming range (W)
Colour temp (K)
Colour Rendering Index (Ra)
Luminous flux (Lm)
USB output/charging input
Battery type
Battery capacity (mAh)
Charing time (H)
Endurance time (H)
Working temp (ºC)
Working humidity (%)
Whole light weight (g)
Light body materials
IP rating (IP)
3.2 W
10%-100% (0.3W-3.2W)
2200-6500K (CCT Adjustable)
Ra≥80
20-250lm
5V/1A
Lithium battery 18650*2pcs/AA*3
According to their own conditions
≥7hours (only support 18650 Li-on battery)
8-75 Hours (Li-on battery 5000mAh)
-20 ºC - 60 ºC
≤95%
Dry ventilated place
600 g
126*230mm
Plastic + Iron + Bamboo
Storage condition
IPX4
Dedicated for DC3V bulb
Handle
Dedicated
light source
Knob switch USB
Battery box
Size
Knob switch
A: Press the knob for 1s to turn on the lamp. The default lightning mode is warmlight (2200K), clockwise rotate for better light, counter for
lower light!
B: It takes 3-4 laps of rotating for the lamp to reach maximum brightness.
C: Quick press the knob for Color temperature adjustment. Clockwise rotate for warm white to Cool white (high CCT), counter rotate for cool
white to warm white (low CCT). CCT range: 2200K-6500K.
INSTRUCTION MANUAL
TABLE LANTERN HARLINGTON
5818921
BO-CAMP.COM NL-5126 RK 20
2/2
Attention
Long press the knob is for power ON/OFF.
Short press for Dimmable/CCT adjustment!
USB
As the below picture shown, open the rbber cover:
DC 5V adaptor (not included)
Do not use unmatched adapoter
The green indicator flickers say power charging, green light going on say full with
power. When the USB output interface is used for external equipment charging, the
red indicator going on and the indicator flicker means power off.
Notice: USB output interface is not available during charing.
Notes
1. Only for DC+5V adaptor.
2. Do not be directly exposed to rain water.
3. To prevent it from battery damage as overfall, please charge timely when power off.
4. Please charge once per three months if not use for quite some time.
5. To prevent it form water and dust contaminant, please cover the USB output interface with waterproof film when it is not in use.
6. In order to avoid accidents, please do not put it into fire.
