LIMITED WARRANTY
WARRANTY COVERAGE:
This warranty covers “Bock” Water Heater models 72E, 73E, 190E, 241E, 361E and 541E. Bock Water
Heaters, a division of Bock Corporation – a Wisconsin corporation – at 110 S. Dickinson St., Madison, WI 53703, (“Company”), war-
rants to the owner that the tank of this water heater will not leak due to defective materials or workmanship for THREE (3) years from
the date of original installation. The company also warrants that no other part of this water heater will fail due to a defect in material or
workmanship for one (1) year. This warranty does not apply where the purchase is for resale.
COMPANY RESPONSIBILITY:
Bock Water Heater’s responsibility is to repair or replace, at our option with the prevailing comparable
model, any part of the equipment sold by the Company which proves to be defective in material or workmanship, including the tank,
during the warranty period when installed in accordance with applicable codes and ordinances and operated and maintained in accor-
dance with our instructions, subject to the conditions and exceptions indicated below.Our liability,in the vent of leakage or other mal-
function, is strictly limited to repair or replacement of the defective heater or part as provided herein. We are not responsible hereun-
der for incidental property damage or personal injury, consequential costs or damage.
OWNER RESPONSIBILITY:
At the company’s request, the owner is to return to the factory at Madison, WI any part, including the tank,
defective in material or workmanship and pay all transportation charges for such return parts and for replacement parts sent from the
factory to the owner. The owner will pay all labor charges for the removal and installation of such parts, including the tank.
EXCEPTIONS:
This warranty will not apply to tanks or parts subject to misuse, abuse, neglect, alteration, accident, excessive temper-
ature, excessive pressure, lime, silt or sediment accumulation, corrosive atmosphere, the removal of anode rods, installation outside
of the USA, or on which the serial numbers have been altered. The warranty also does not apply when the water heater is installed
without a new temperature and pressure relief valve and is not installed in accordance with local codes and ordinances.
TOTAL WARRANTY COMMITMENT:
Wewill not assume nor authorize any person to assume for us any other liability in connection
with the sale or operation of Bock Water Heaters. Any implied warranties, including merchantability or fitness for a particular applica-
tion imposed on the sale of this heater under laws of the state of sale are limited to one (1) year. Some states do not allow limitations
on how long an implied warranty lasts or for the exclusion of incidental or consequential damages, so the above limitations or exclu-
sions may not apply to the purchaser.This warranty gives specific legal rights – other rights may vary from state to state.
WARRANTY REGISTRATION:
The card should be returned within thirty (30) days of the date of installation; otherwise, the date of
manufacture will be recorded as the date of installation for the purpose of this warranty.
TO MAKE A CLAIM:
Contact your nearest Bock distributor or:
Bock Water Heaters, Inc. • 110 S. Dickinson St. • Madison, WI 53703
Phone: 608/257-2225 • Fax: 608/257-5304 • www.bockwaterheaters.com
Form 23400
Rev 4
2/2007
BURNER PARTS LIST
15 13
ITEM DESCRIPTION
1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Burner Housing
2. . . . . . . . . . . . . . . . . . . . . . . . . . . .Junction Box ASM
3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Motor
4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Blower Wheel
5. . . . . . . . . . . . . . . . . . . . . . . . . . . .Motor Cord Cover
6. . . . . . . . . . . . . . . . . . . . . . . . . . . .Transformer/Igniter
7. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Housing Cover
8. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Coupling
9A. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Fuel Unit
10. . . . . . . . . . . . . . . . . . . . . . . . . . . .Oil Line Assembly
11. . . . . . . . . . . . . . . . . . . . . . . . .Air Adjst. Band, Inner
12. . . . . . . . . . . . . . . . . . . . . . . . .Air Adjst. Band, Outer
13. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Air Tube
13. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Gun Assembly
14. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Gasket
15. . . . . . . . . . . . . . . . . . . . . . . . . . . . .Mounting Flange
17. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Oil Line Elbow
18. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Air Cone
19. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Nozzle Adapter
20. . . . . . . . . . . . . . . . . . . . . . . . . . . .Electrode Support
21. . . . . . . . . . . . . . . . . . . . . . . .Electrode Asmbly (RH)
22. . . . . . . . . . . . . . . . . . . . . . . .Electrode Asmbly (LH)
14 18
13
17
CAD CELL
9A
12
11
1
10
4
7
6
3
5
2
RELAY (where listed)
Please have burner make, model and serial number available when
ordering parts.
