Modulations with the LFO.
Modulating the PWM with the LFO.
To modulate the PWM using the integrated LFO, set the switch (J) to its
"PWM" position (up), this routes the LFO signal to the "PWM" connector (B)
described in section "II.I Modulations", without the need of a patch cable.
From here, you can modulate the pulse width as described above, with the
only difference that, instead of using an external signal, we will use the
signal from the integrated LFO.
III.I
I
JKL
Frequency modulating with the LFO.
To perform a frequency modulation or "FM", place the switch (J) in the
"FREQ" position (down), this directs the LFO signal to the FM connector (D)
described in section "II.I Modulations", without the need of a patch cable.
From here, you can modulate the frequency as described above, with the
only difference that, instead of using an external signal, we will use the
signal from the built-in LFO.
