Bona®FlexiSand
Power Drive™
Operating Manual
Bona®FlexiSand Power Drive™Manual
2
bona.com
800.872.5515
For a new manual contact:
Bona US
2550 S. Parker Rd.
Suite 600
Aurora, CO 80014-1622
Tel +1 303.371.1411
+1 800.872.5515
Fax +1 303.923.1461
www.bona.com
Foreword
3
Table of Contents
Foreword 2
Table of Contents 3
Technical Data 4
Material Specification 5
Drive Plates & Accessories 6
Safety Instructions 7
Maintenance, Service & Repairs 10
Maintenance 10
Service 11
Spare parts and exploded views 11
Warranty 11
Bona®FlexiSand Power Drive™in General 12
Normal use 12
Risks 13
Handling 13
Assembling the dust skirt 14
Assembling the FlexiSand Power Drive™ 14
Attaching dust containment 15
Using the FlexiSand Power Drive™ 15
The sanding process 17
Transport position 18
Additional Notes 19
4
bona.com
800.872.5515
Bona®FlexiSand Power Drive™Manual
Technical Data
Motor type: 1 phase
Voltage (± 5%): 220-230
Frequency: 60 Hz
Power: 1.9kW 2.6 HP
Rated current: 13A
Safety devices: 16A overload switch (manual reset),
thermal protection in motor (automatic reset)
Recommended fuses: 15A
Capacitors: 50+160µF
Motor insulation class: F
Protection class: IP44
Final drive speed (unloaded): 155 rpm
Total weight: 111 lbs (50.35 kg)
Diameter of disc: 16" (407mm)
Hour counter: <99,999 hours
Height/Width/Depth: 46"/19.5"/25.2" (1170mm/490mm/640mm)
We congratulate you on your purchase of the Bona®FlexiSand Power Drive™, a powerful and versatile
machine for sanding, cleaning, buffing, and oiling wooden floors! With the Bona®FlexiSand Power Drive™
attached, you are able to perform direction-free sanding to bare wood. Four counter-rotating discs provide a
high cut rate which can reach very close to the wall and as such reduces the need for edge sanding.
Carefully read through the entire user manual before you begin working with the machine. This machine is
intended for professional or commercial use.
5
Material Specification
Standard (included on delivery)
Key Article Article Number
ABona®FlexiSand Power Drive™AMO310002.2
B Bona®Pad Driver ASO312511
C Dust skirt ASO312102
D Dust tube ASO316650
E Extension cable 50 ft (15.2m) ASO904015
F Face mask, ear caps (compl.) ASO991232
G Box spanner (tool) ASO990640 - L Type Wrench 19mm
HBona®Power Drive™AS0312540
I User manual & instruction guide N/A
Bona®FlexiSand Power Drive™Manual
6
bona.com
800.872.5515
Drive Plates & Accessories
Article Application Recommended
Abrasives & Equipment
Bona®Pad Drive™, 16"
Included on delivery
Art. nr. ASO312511
Standard drive plate for a
wide variety of jobs. Equip
with a suitable pad for
cleaning, oiling, buffing and
fine sanding of untreated
and treated wood.
Bona®Abrasive Pads
Bona®Screen
Bona®Double Sided Sanding Discs
Bona®Cloths
Bona®FlexiSand Power Drive™
4 x 150mm
Art. nr. ASO312540
Geared drive plate for
high-power wood sanding.
Removes old lacquer
and paint coatings while
flattening the surface for a
perfectly smooth finish.
Bona®GREEN Ceramic Abrasives
Bona®BLUE Abrasives
Bona®SiC Abrasives
Bona®Diamond Abrasives
Internal Spur Gear
Art. nr. ASO312082
Spur gear for the
Bona®Power Drive™N/A
Bona®Multi Disc™
6 x 150mm
Art. nr. ASO312520
Fine sanding of wooden
floors. Suitable as a final
finish after belt sanding.
Bona®GREEN Ceramic Abrasives
Bona®BLUE Abrasives
Bona®SiC Abrasives
Bona®Diamond Abrasives
LED Lamp
Art. nr. ASO319070
FlexiSand™Working Lamp
220V/60 Hz
For better visibility while
sanding. The sanding result
becomes easier to see.
N/A
7
NOTE: The reading and understanding of the Owner’s Manual is imperative prior to operating this machine. If you or your operator(s)
cannot read English, have this manual explained fully before attempting to operate this machine. Children should be supervised to
ensure that they do not play with the appliance. This machine is not intended for use by persons (including children) with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge.
DANGER means: You or other staff can suffer a serious injury or death if the instructions marked
with DANGER on this machine or in these user instructions are ignored or not followed. Read the
entire user manual before you use the machine.
WARNING means: You or other staff can suffer an injury if the instructions marked with WARNING
on this machine or in this user manual are ignored or not followed. The machine or other property
may also be damaged if instructions marked with WARNING are ignored.
Under adverse conditions, a mixture of dust and air can be explosive. Sanding/polishing wooden
floors can create an environment that can be explosive. The safety routines below must be followed:
• Cigarette lighters, control lamps and all other sources of ignition can cause explosions if they
are active during sanding. All sources of ignition should be extinguished or, if possible, removed
completely from the work area.
• In work areas with poor ventilation, an explosive environment can occur if certain flammable
materials (solvents, thinners, alcohol, fuel, certain polishes, wood dust, etc) are in the
atmosphere. Floor grinders can cause slightly flammable materials and vapors to burn. Read the
manufacturer's label on all chemicals to be used so that you can determine the flammability.
Ensure that the work area always has good ventilation.
• Hitting a nail during sanding can produce sparks and cause an explosion or fire. Always use a
hammer to pound in any metal pieces before sanding the floor. Always keep a fire extinguisher
(ABC-class or water) available.
Use of a machine that is not complete or that is not fully mounted can result in personal injury
or damage to property. Never use these machines before they are fully mounted. Ensure that all
fastening devices are fixed. Make adjustments as defined in the machine specifications.
Read through the safety instructions carefully and inform your employees and users so no one comes to harm when using the machine.
Then, save the instructions. The manufacturer is not liable for personal injury or machine damage due to incorrect operation of the
machine. The machine may only be used by authorized persons that have been trained in its function.
Voltage: Make sure the voltage stated on the machine's rating plate corresponds to the voltage in the power outlet before you start
the machine.
Safety Instructions
Bona®FlexiSand Power Drive™Manual
8
bona.com
800.872.5515
Safety Instructions (Cont.)
Never remove or disable the ground in the electric cable.
Consult an electrician if the ground is missing or if you suspect that your circuit is not
properly grounded.
There is a risk of electric shock if the machine is used in a circuit that breaks repeatedly or is under-
sized. Allow an authorized electrician to control the fuse, breaker or power supply.
There is a risk of personal injury if the grinder runs over and damages the cord. Ensure that the cord
does not come into contact with the sanding disc. Always lift the cord over the machine and grind in
a direction away from the cord. Do not pull the machine by the cord.
Always use a ground that breaks the current immediately in the event of a fault in the electrical
system or in the extension cord.
In order to prevent unintentional start of the machine, the power cord must be
removed when the machine is not in use or during service.
Moving parts of the machine can cause serious personal injury and/or material damage. Keep hands,
feet and loosely fitting clothing away from all moving parts of the grinder.
Because dust from sanding (red lead, certain types of wood and metal) is hazardous to health, a face
mask of at least class P2 must be used.
There is a risk of damage to the eyes and/or body if protective clothing and/or protective
equipment is not used during sanding. Always use protective glasses, protective clothing, ear
protection and a face mask of at least class P2 during sanding.
Read the instructions
contained in this user
and maintenance
manual before using
the machine.
Hearing protection
during use is
recommended.
Protection of the
airways during use
is recommended.
Hazard due to
moving parts.
Hazard due
to electricity.
9
To minimize dust in the environment use a vacuum cleaner intended for wood dust. The air flow
on the vacuum cleaner should be at least 245m³/h. We strongly recommend the Bona®DCS™
for best results.
Store contained wood dust outdoors in a safe place due to the risk of fire. Never leave contained
wood dust unsupervised.
Always keep a fire extinguisher (ABC-class or water) available.
Take precautionary measures to ensure that the machine is not damaged during transport.
Be careful with cords. Use the correct power cord with the correct length (see accessories list).
Never carry the machine by the cord. Never pull power cords from the machine or wall socket
with strong movements. Protect the power cords against heat, oil and sharp edges. Power cords
longer than 50 ft (15.24m) should not be used.
Remove the power cord from the machine when it is not in use. Ensure that the machine does
not start unintentionally. Never carry a connected machine. Ensure that the breaker is not on once
the machine is connected to a power socket. Never use the machine if the start handle does not
function as it should.
Inspect the machine regularly. If you discover damaged parts, replace them at once. If necessary,
contact Bona or staff approved by Bona.
Because this construction is in many ways unique, use of other spare parts and accessories than
Bona®original spare parts can cause a risk of personal injury and/or damage to the machine.
Ensure that the machine is always in good condition. Keep the machine clean for better and safer
use. Follow the instructions concerning the replacement of accessories. Inspect the power cords
regularly. Repair or replace defective parts if they are damaged.
Store the machine in a dry and locked area when not in use.
Do not forget to put on the tool before you start the machine. Always check that the sanding
paper is correctly adjusted before you begin sanding.
Keep unauthorized persons away from the work site. Do not allow unauthorized persons to come
into contact with the machine or power cords.
Do not misuse the machine. The machine works better when it is used according to its capacity
and design. Allow the motor to "rest" during periods of heavier use. The motor will cool better,
thus increasing its lifespan.
Safety Instructions (Cont.)
Bona®FlexiSand Power Drive™Manual
10
bona.com
800.872.5515
Never use a machine for anything else or use accessories other than those
described in this manual.
Service or repairs performed by unauthorized persons can cause damage or accidents. If service
and repairs are performed by unauthorized persons, the warranty may become invalid. Service
and repairs must be performed by Bona or staff approved by Bona.
Be aware when you work. Use common sense. Do not use the machine if you are tired,
have consumed alcohol or have taken medication that can affect your judgment or your body
control. Due to the potential fire hazard involved with sanding dust, smoking is not permitted
while sanding.
Always use a grounded circuit breaker.
Safety Instructions (Cont.)
Maintenance, Service & Repairs
To keep the machine in a safe and functioning condition, perform maintenance on the machine regularly.
Always disconnect the power cable to the machine before it is cleaned, tools are changed, maintenance is
performed or when worn parts are replaced.
Daily maintenance
• Remove accessories when not in use
• Use compressed air and a vacuum cleaner to remove dust after each use
• Wipe the machine and cord off with a clean cloth
• Check start and stop function
• Check cord and plug
Every 250 work hours or at least once a year
• Wheels
• Cable stand
• Dust skirt
• Micro switches
• Motor and gearbox
• Handle shaft function including hydraulic system
Maintenance
