AutoDome Pipe Mount
VG4-A-9543
en Installation Guide
AutoDome Pipe Mount Table of Contents | en 3
Bosch Security Systems, Inc. Installation Guide F.01U.251.410 | 1.0 | 2011.08
Table of Contents
1 Important safety instructions 5
2 Installing the Pipe Mount 7
2.1 Unpacking 7
2.1.1 Parts List 7
2.1.2 Optional Mounting Accessories 7
2.1.3 Optional Power Supplies 8
2.1.4 Description 8
2.1.5 Tools Required 8
2.2 Pre-installation Check List 9
2.3 Pressurized Environmental Mounting Option 11
2.4 Mount Power Supply Box 12
2.4.1 Attach Cover Door 14
2.5 Route Wires and Attach Connectors 15
2.5.1 Methods for Routing Wires 16
2.5.2 Wiring the Power Supply Box 18
2.5.3 Power Supply Box Connections 19
2.6 Installing the VG4-A-9543 Pipe Mount 21
2.7 Wire the Pipe Interface Board 23
2.7.1 Wiring for Multiple AutoDomes 25
2.7.2 Connecting Wires to the Pipe Interface Board 25
2.8 Attach Pendant to Pipe and Tighten 29
3 Cable and Wire Standards 31
3.1 Power 31
3.2 Wire Distance Guide 31
3.3 Video and Control Cables 32
3.3.1 Using Coaxial Cable to Transmit Video and Control 32
3.3.2 Using UTP to Transmit Video and Control 33
3.3.3 Using Ethernet to Transmit Video and Control 34
3.3.4 Using Multi-mode Fiber Optic to Transmit Video and Control 34
3.3.5 Using a Fiber Optic Ethernet Media Converter to Transmit Video
and Control 35
3.4 Control-only Cables 35
3.4.1 Controlling the AutoDome via Biphase 35
4en | Table of Contents AutoDome Pipe Mount
F.01U.251.410 | 1.0 | 2011.08 Installation Guide Bosch Security Systems, Inc.
3.4.2 Controlling the AutoDome via the RS232 Protocol 37
3.4.3 Controlling the AutoDome via the RS485 Protocol 39
3.5 Fiber Optic Module with an RS232/RS422 Controller 41
3.5.1 Connecting to an LTC 4629 Head End Data/Video Transceiver 41
3.5.2 Configuring the VG5 AutoDome 41
3.6 Audio Cables 43
4 Alarms and Relay Connections 45
4.1 Alarm Inputs 45
4.2 Configuring Supervised Alarms (inputs 1 and 2) 45
4.2.1 Configuring a Normally Open Supervised Alarm 46
4.2.2 Configuring a Normally Closed Supervised Alarm 46
4.3 Configuring Non-supervised Alarms (inputs 1 through 7) 47
4.3.1 Configuring a Normally Open Non-supervised Alarm 47
4.3.2 Configuring a Normally Closed Non-supervised Alarm 48
4.4 Alarm Outputs 48
4.4.1 Configuring a Dry Contact Relay 48
4.4.2 Configuring an Open Collector Output 49
AutoDome Pipe Mount Important safety instructions | en 5
Bosch Security Systems, Inc. Installation Guide F.01U.251.410 | 1.0 | 2011.08
1 Important safety instructions
Type numbers:
Read, follow, and retain all of the following safety instructions.
Heed all warnings on the unit and in the operating instructions
before operation.
1. Clean only with a dry cloth. Do not use liquid cleaners or
aerosol cleaners.
2. Do not install unit near any heat sources such as radiators,
heaters, stoves, or other equipment (including amplifiers)
that produce heat.
3. Do not block any ventilation openings.
4. Do not use the unit near water or expose to rain or
moisture. Never spill liquid of any kind on the unit.
5. Unplug the unit during lightning storms or when unused for
long periods. Take precautions to protect the unit from
power and lightning surges.
6. Adjust only those controls specified in the operating
instructions.
DANGER!
High risk: This symbol indicates an imminently hazardous
situation such as “Dangerous Voltage” inside the product.
If not avoided, this will result in an electrical shock, serious
bodily injury, or death.
WARNING!
Medium risk: Indicates a potentially hazardous situation.
If not avoided, this could result in minor or moderate bodily
injury.
CAUTION!
Low risk: Indicates a potentially hazardous situation.
if not avoided, this could result in property damage or risk of
damage to the unit.
6en | Important safety instructions AutoDome Pipe Mount
F.01U.251.410 | 1.0 | 2011.08 Installation Guide Bosch Security Systems, Inc.
7. Do not overload outlets and extension cords, as this can
cause fire or electrical shock.
8. Protect the plug and power cord from foot traffic or
pinching, at electrical outlets, and at its exit from the unit.
9. Operate the unit only from the type of power source
indicated on the label.
10. Unless qualified, do not attempt to service a damaged unit
yourself. Refer all servicing to qualified service personnel.
11. Use only replacement parts specified by the manufacturer.
12. Install in accordance with the manufacturer's instructions
in accordance with applicable local codes.
13. Use only attachments/accessories specified by the
manufacturer. Equipment change or modification could
void the user's guarantee or authorization agreement.
You can view and print the full version of this Installation
Manual with Adobe Acrobat Reader, both provided on the
enclosed CD-ROM. This user guide is the intellectual property
of Bosch Security Systems; protected by copyright. Contact:
www.boschsecurity.com
AutoDome Pipe Mount Installing the Pipe Mount | en 7
Bosch Security Systems, Inc. Installation Guide F.01U.251.410 | 1.0 | 2011.08
2 Installing the Pipe Mount
2.1 Unpacking
This equipment should be unpacked and handled with care. If
an item appears to have been damaged in shipment, notify the
shipper immediately.
Verify that all the parts listed in the product's Parts List below
are included. If any items are missing, notify your Bosch
Security Systems Sales or Customer Service Representative.
The original packing carton is the safest container in which to
transport the unit and must be used if returning the unit for
service. Save it for possible future use.
2.1.1 Parts List
The following table lists the parts included with this mounting
package.
2.1.2 Optional Mounting Accessories
The following table lists the optional parts you may need for
attaching a pendant to a pipe mount.
Part Numbers
Pipe Mount VG4-A-9543
Mounting Options Part Numbers
Pipe Mount for Pressurized
Environmental Housing
VG4-A-9543N
Roof Parapet Mount VGA-ROOF-MOUNT
Flat Roof Mount Adapter LTC 9230/01
8en | Installing the Pipe Mount AutoDome Pipe Mount
F.01U.251.410 | 1.0 | 2011.08 Installation Guide Bosch Security Systems, Inc.
2.1.3 Optional Power Supplies
The pipe mount does not come with an attached power supply.
The following table lists the optional power supplies that are
compatible with VG5 Series AutoDomes:
2.1.4 Description
This chapter details how to install an AutoDome pipe mount.
Any variations to the installation procedures are noted.
Note: You may need to purchase additional mounting
accessories for roof mount applications. Refer to
Section 2.1.2 Optional Mounting Accessories, page 7.
2.1.5 Tools Required
– 5 mm Allen wrench (supplied)
– Small straight blade screwdrivers ~ 2.5 mm (0.1 in.) – 3.1
mm (1/8 in.)
– Medium straight blade screwdriver
– No. 1 and No. 2 Phillips screwdrivers
– Socket wrench and 9/16 in. socket
– Pipe Wrench
Mounting Options Part Numbers
24 VAC (no transformer), NEMA-rated with
cover
VG4-A-PSU0
120 VAC transformer, NEMA-rated with cover VG4-A-PSU1
230 VAC transformer, NEMA-rated with cover VG4-A-PSU2
AutoDome Pipe Mount Installing the Pipe Mount | en 9
Bosch Security Systems, Inc. Installation Guide F.01U.251.410 | 1.0 | 2011.08
2.2 Pre-installation Check List
1. Determine the location and distance for the power supply
box based on its voltage and current consumption. Refer
to Section 3 Cable and Wire Standards, page 31 for wiring
information and distances.
2. Use only UL listed liquid tight strain reliefs for conduits to
the Power Supply Box to ensure that water cannot enter
the box. You must use water tight conduits and fittings to
meet NEMA 4 standards.
3. Install all rough wiring including: power, control, video
coax, alarms I/O, relay I/O, and fiber optic cabling. Refer to
Section 3 Cable and Wire Standards, page 31 for video and
control protocol methods.
4. Analog AutoDome: If you plan to use the RS232 or RS485
protocol to control the AutoDome, refer to
Section 3.4.2 Controlling the AutoDome via the RS232
Protocol, page 37, or Section 3.4.3 Controlling the
AutoDome via the RS485 Protocol, page 39, for instructions
on configuring the AutoDome to accept these protocols.
NOTICE!
Power and I/O cabling must be routed separately inside
different permanently earthed metal conduits.
WARNING!
External interconnecting cables are to be installed in
accordance to NEC, ANSI/NFPA70 (for US application) and
Canadian Electrical Code, Part I, CSA C22.1 (for CAN
application) and in accordance to local country codes for all
other countries.
Branch circuit protection incorporating a 20 A, 2-pole Listed
Circuit Breaker or Branch Rated Fuses are required as part of
the building installation. A readily accessible 2-pole disconnect
device with a contact separation of at least 3 mm must be
incorporated.
10 en | Installing the Pipe Mount AutoDome Pipe Mount
F.01U.251.410 | 1.0 | 2011.08 Installation Guide Bosch Security Systems, Inc.
5. Choose the appropriate VG5 AutoDome model (indoor or
outdoor) for the environment in which it will be used.
6. Purchase the appropriate mounting hardware to use,
depending on the location of the AutoDome and the
application.
CAUTION!
Select a rigid mounting location to prevent excessive vibration
to the AutoDome camera.
