Bosch TAT5P42 Series Scheda tecnica
345
2
6
7
8
9
1
1
2 3
4 5
6 7
8 9
10 11
12 13
14 15
16
17
zh 安全性
6
安全性
¡请仔细阅读本说明书。
¡请妥善保管说明书及产品资料以备日后查阅或提供给下一位使用
者。
本电器仅限用于：
¡在监视下。
¡仅限私人家庭和室温下的居家环境室内区域。
¡最高在海拔 2000m 使用。
¡烤面包，加热或解冻切片面包、面包、小面包和其他适合用烤面包
机烹饪的食物。
必须在每次使用后、电器离开视线范围时、清洁前和在发生故障时将
本电器的电源断开。
凡年满 8 岁的孩童，身体、感官或智力有缺陷的人士以及缺乏相关经
验和知识的人士，应在负责安全使用机器人员的监督或指导下，了解
使用机器可能带来的危险后，方能使用本机器。
严禁孩童将本机器当成玩具玩耍。
八岁以上的孩童除非在监督下，否则不得进行清洁及用户维护的工
作。
请确保 8岁以下的孩童远离本机器及其电源线。
▶仅限按规格铭牌所提供之信息连接并运行本机器。
▶仅限通过按规定安装接地保护的插座将本机器连接到带有交流电的
电源。
▶楼房电路安装的接地系统必须按规定进行安装。
▶切勿通过定时器或遥控器等外部开关装置为本机器供电。
▶唯有合格的专业人员方可维修机器。
▶如果电源软线损坏，为了避免危险，必须由制造商、其维修部或类
似部门的专业人员更换。
▶请勿将本机器或电源线浸泡在水中，或放入洗碗机洗涤。
▶切勿在有水的浴缸、水槽或其他容器附近使用本机器。
▶请勿使用蒸汽清洁器或高压清洁器清洁本机器。
▶切勿使用烤箱清洁喷雾或烤架清洁喷雾来清洁电器。
▶切勿将手伸进吐司槽或插入餐具等物体。
▶请勿运行已损坏的机器。
▶切勿将电器放在高温表面或热源附近。
▶切勿在易燃材料 (例如窗帘) 附近或下方使用电器。
概览 zh
7
▶切勿盖住吐司槽或直接在吐司槽上加热食物。
▶必须在装有集屑盘的情况下直立运行本电器。
▶吐司升降杆仅针对规定用途向下按下，切勿将其卡住。
▶请随时在运行过程中关注本烤面包机。
▶切勿使用会在烘烤或回烤过程中可能滴落的食物。
▶切勿使用含有油脂、脂肪或糖的食物，如华夫饼或涂抹过的面包。
▶切勿触摸高温表面，仅可触摸控制元件。
▶请等电器冷却后再进行清洁或移动。
▶只允许合规使用本电器，以免造成伤害。
▶请让孩童远离包装材料。
▶切勿让孩童用包装材料玩耍。
▶请让孩童远离小型部件。
▶切勿让孩童玩耍小型部件。
概览
→
图
1
1
吐司槽
2
吐司升降推杆
3
带 LED 灯的按键 解冻（解冻）
4
烘烤程度挡位旋钮
5
带 LED 灯的按键 取消（结束）
6
内置式烘烤架
7
烘烤架推杆
8
集屑盘
9
电源线收纳仓
准备电器的初次使用
注：在没有面包的情况下，打开窗口，以最
高的烘烤程度设置加热烤面包机 3 次，然后
冷却。
→
图
2- 4
操作
一般注意事项
请遵守这些提示，以便您能够以最佳方式使
用本电器。
¡可以随时通过按下按键 取消 停止当前的烘
烤过程。
¡如果正在烘烤的食物卡住，本电器会自动
关闭。拔掉烤面包机的插头，让其冷却，
然后小心地取出卡住的烘烤食物。
¡第一次使用本电器时，请尝试不同的烘烤
程度设置，因为结果可能会因面包的类型
和水分含量而有所不同。
¡烘烤单片面包需要比 2 片面包更低的烘烤
程度。
¡丙烯酰胺对健康有害，在非常高的温度下
烹制谷物产品和土豆产品时会形成丙烯酰
胺。请将食物烤至金黄色为宜，色泽不要
太深，并去除任何烧焦残渣。
烘烤程度设置
根据食物和个人口味调整烘烤程度。
设置 用途
通过最低设置可重新加热面包
或预先烤过的食物，而无需热
烘
1-2 干面包的类型需要较低的烘烤
程度
3-4 湿面包类型需要中度的烘烤程
度
5-6 非常湿的面包类型或厚的面包
片需要较高的烘烤程度
解冻 启动后，额外按下按键 解
冻，可以使冷冻的食物被烤到
设置的烘烤程度
zh 清洁概述
8
烘烤、重新加热或解冻面包片
→
图
5- 9
回烤或解冻小面包
注：请勿在回烤小面包的同时将烘烤食物放
入吐司槽。
→
图
10 - 16
清洁概述
注：为防止本电器出现故障，请定期清洁集
屑盘。
→
图
17
执行标准
GB 4706.1 家用和类似用途电器
的安全 第1部分：通
用要求
技术数据
电气连接 220-240V∼
50/60Hz
功率 820-970W
尺寸（高 x 宽 x
深）
195x 174x 304mm
客户服务
有关您所在国家╱地区的保修期和保修条款
的详细信息，请向本公司的客户服务、经销
商或在本公司网站查询。
有关客户服务的联系信息，请查看本说明书
后面的客户服务索引或本公司的网站。
保修
本电器的保修条款由电器售出国的代表处确
定。有关这些条款的详细信息，请向购买电
器的零售商洽询。 当根据保修条款进行任何
索赔时，必须出具销售凭证或收据。
Safety en
9
Safety
¡Read this instruction manual carefully.
¡Keep the instruction manual and the product information safe for
future reference or for the next owner.
Only use this appliance:
¡under supervision.
¡in private households and in enclosed spaces in a domestic en-
vironment at room temperature.
¡up to an altitude of max. 2000m above sea level.
¡for toasting, warming or defrosting sliced toasting bread, bread,
rolls and other food intended for heating in the toaster.
It must always be disconnected from the mains after each use,
whenever the appliance is unsupervised, before cleaning and with
any faults.
This appliance may be used by children aged 8 or over and by
people who have reduced physical, sensory or mental abilities or
inadequate experience and/or knowledge, provided that they are
supervised or have been instructed on how to use the appliance
safely and have understood the resulting dangers.
Do not let children play with the appliance.
Children must not perform cleaning or user maintenance unless
they are at least 8 years old and are being supervised.
Keep children under the age of 8 years away from the appliance
and power cable.
▶Connect and operate the appliance only in accordance with the
specifications on the rating plate.
▶Connect the appliance to a power supply with alternating current
only via a properly installed socket with earthing.
▶The protective conductor system of the domestic electrical in-
stallation must be properly installed.
▶Never equip the appliance with an external switching device, e.g.
a timer or remote control.
▶Repairs to the appliance should only be carried out by trained
specialist staff.
▶If the power cord of this appliance is damaged, it must be re-
placed by the manufacturer, the manufacturer's Customer Ser-
vice or a similarly qualified person in order to prevent any risk.
en Overview
10
▶Never immerse the appliance or the power cord in water or clean
in the dishwasher.
▶Never use the appliance near water contained in a bath,
sink or other vessels.
▶Do not use steam- or high-pressure cleaners to clean the appli-
ance.
▶Do not use oven or grill sprays to clean the appliance.
▶Never reach into the toast slots or insert objects into them, e.g.
cutlery.
▶Never operate a damaged appliance.
▶Never place the appliance on or near hot surfaces.
▶Never operate the appliance near or underneath inflammable
materials such as curtains.
▶Never cover the toast slots or heat food directly over them.
▶Only operate the appliance in an upright position and with the
crumb tray inserted.
▶Always ensure proper use by pressing down the lever for the
toast lift and never block it.
▶Never leave the toaster unattended while in use!
▶Never use foods that could drip during toasting or crisping-up.
▶Never use greasy or fatty foods or foods containing a lot of
sugar, e.g. waffles or bread with spread on.
▶Never touch the hot surfaces, only the controls.
▶Allow the appliance to cool down before cleaning or transport-
ing.
▶To avoid injuries, only use the appliance for its intended purpose.
▶Keep packaging material away from children.
▶Do not let children play with packaging material.
▶Keep small parts away from children.
▶Do not let children play with small parts.
Overview
→Fig. 1
1
Toast slots
2
Lever for toast lift
3
解冻 button with LED (defrost)
4
Rotary selector for toasting degree
5
取消 button with LED (stop)
6
Integrated warming rack
7
Lever for warming rack
