Bose SoundDock 10 Bluetooth Manuale utente

Owner’s Guide | Brugervejledning | Bedienungsanleitung | Guía de usuario | Omistajan opas

Notice d’utilisation | Felhasználói útmutató | Manuale di istruzioni | Gebruiksaanwijzing

Framingham, MA 01701-9168 USA

AM324759 Rev.01

SoundDock®

Bluetooth Dock

SOUNDDOCK®10 BLUETOOTH DOCK

BMX_BT_DockOG_324759_cover.fm Page 1 Thursday, July 16, 2009 10:59 AM

English

Safety information

Please read this owner’s guide

Please take the time to follow the instructions in this owner’s guide carefully. It will help you

set up and operate your system properly and enjoy its advanced features. Please save this

owner’s guide for future reference.

WARNINGS:

• To reduce the risk of fire or electrical shock, do not expose the product to rain or moisture.

• Do not expose this apparatus to dripping or splashing, and do not place objects filled with

liquids, such as vases, on or near the apparatus. As with any electronic products, use care

not to spill liquids into any part of the system. Liquids can cause a failure and/or a fire

hazard.

• Do not place any naked flame sources, such as lighted candles, on or near the apparatus.

• Contains small parts that may be a choking hazard. Not suitable for children under age 3.

Notes:

• This Class B digital apparatus meets all requirements of the Canadian Interference-Causing

Equipment Regulations (Canada only).

• The product must be used indoors. It is neither designed nor tested for use outdoors, in

recreation vehicles, or on boats.

Bose Corporation hereby declares that this product is in compliance with the

essential requirements and other relevant provisions of Directive 1995/5/CE

(R&TTE directive) and other applicable Directives. The detailed Declaration of

Conformity can be found on www.Bose.com/compliance.

Temperature range for use: 0°-45°C (32°-113°F)

BMX_BT_DockOG.fm Page 2 Thursday, July 16, 2009 11:01 AM

English

NOTICE

This equipment has been tested and found to comply with the limits for a Class B digital

device, pursuant to Part 15 of the FCC rules. These limits are designed to provide

reasonable protection against harmful interference in a residential installation. This

equipment generates, uses, and can radiate radio frequency energy and, if not installed

and used in accordance with the instructions, may cause harmful interference to radio

communications. However, this is no guarantee that interference will not occur in a

particular installation. If this equipment does cause harmful interference to radio or

television reception, which can be determined by turning the equipment off and on, you

are encouraged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment to an outlet on a different circuit than the one to which the

receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

This device complies with FCC and Industry Canada RF radiation exposure limits set forth

for general population. It must not be co-located or operating in conjunction with any other

antenna or transmitter.

This device complies with Part 15 of the FCC rules. Operation is subject to the following

two conditions: (1) This device may not cause harmful interference, and (2) this device

must accept any interference received, including interference that may cause undesired

operation.

Changes or modifications not expressly approved by the party responsible for

compliance could void the user’s authority to operate this equipment.

BMX_BT_DockOG.fm Page 3 Friday, August 7, 2009 2:07 PM

English

Overview

The Bose®SoundDock®10 Bluetooth®dock adds Bluetooth wireless

technology capability to your SoundDock 10 digital music system. After

installing this accessory, you can listen to your stereo Bluetooth music

phone with high-quality, room-filling sound. To experience the intended

performance, your stereo Bluetooth music phone must support the

Bluetooth Advanced Audio Distribution Profile (A2DP).

Installing the Bluetooth dock

1. Disconnect the SoundDock 10 system power cord from the AC outlet.

2. Lift up the back edge of the universal dock adapter (A) and remove it

from the dock. You may need to insert a thin non-metallic utensil into

the slot to provide the required leverage to lift the back edge.

3. Press the dock release button (B) on the right and lift up (C) the right

side of the dock to remove it. There is a small indent on the button if

you need to use a pen to press the button in far enough to fully release

the dock.

ABC

BMX_BT_DockOG.fm Page 4 Friday, June 5, 2009 10:19 AM

English

4. Slide the left end of the Bluetooth®dock into the dock opening (A).

5. Press down on the right side of the dock until it locks in place (B).

Making the first connection

1. Plug the power cord of the SoundDock®10 digital music system into

an AC outlet.

2. Wait until the Bluetooth light starts slowly flashing, meaning that the

Bluetooth dock is in discoverable mode.

NOTE: The dock stays in discoverable mode (up to 30 minutes with first-time use) until you

connect your stereo Bluetooth music phone to it.

Bluetooth light

(flashing = discoverable mode)

BMX_BT_DockOG.fm Page 5 Friday, June 5, 2009 10:19 AM

English

3. Bring your Bluetooth®music phone close to the SoundDock®10

system.

4. Turn on the Bluetooth feature in your music phone. For details on

using this feature, refer to the owner’s guide for your phone.

5. In the list of found Bluetooth devices, find “Bose SoundDock 10” and

select it.

6. If prompted, enter the Bose®SoundDock 10 system passkey: 0000.

7. When your music phone confirms it is connected, check that the

Bluetooth light stops flashing and remains on.

NOTE: You can use the SoundDock 10 remote to control the connected music phone.

If your stereo Bluetooth music phone becomes disconnected

because it is out of range, the dock automatically tries to reconnect with it

(the Bluetooth light flashes during reconnection). If the SoundDock 10

system cannot restore a connection within five minutes, it turns off.

To disconnect, press Off on the Bose SoundDock 10 remote, or use the

disconnect command in your phone.

To reconnect when your system is off, press any remote key except

Off or AUX to turn on the system. The SoundDock 10 system then auto-

matically tries to connect with the most recently connected phone.

BMX_BT_DockOG.fm Page 6 Friday, June 5, 2009 10:19 AM

English

Connecting with other stereo Bluetooth®music phones

After making an initial connection, you can change the connection to

another phone by activating the discoverable mode again. However, you

can connect to only one phone at a time.

1. Press and hold the Bluetooth button on the dock or the dock button

on the remote control until the Bluetooth light starts flashing.

2. Follow Steps 3-7 on the previous page.

For the purpose of automatic reconnection, the SoundDock®10 system

remembers the six most recently connected music phones.

Controlling the volume

Increase the volume of your stereo Bluetooth music phone to near

maximum. Then use the Bose®SoundDock 10 remote to control the

system volume.

Bluetooth

button

Dock

button

BMX_BT_DockOG.fm Page 7 Friday, June 5, 2009 10:19 AM

English

Data transfer light

Certain conditions may affect the capability of your phone to adequately

transfer data to the Bluetooth®dock. This may affect the quality of the

audio heard from your SoundDock®10 system.

The data transfer light on the dock tells you how well the Bluetooth dock is

receiving data from your phone.

NOTE: Some phones cannot transmit data fast enough to prevent the light from blinking.

If the audio quality is affected:

•Move your phone closer to the system or to a different location.

•Move your phone away from any household device that generates

electromagnetic radiation, such as a microwave oven, another Bluetooth

device, or a wireless computer network router.

•Reduce the number of applications running on your phone.

•Disconnect your phone and connect again.

Data transfer light:

• On............................. Audio quality not affected

• Slow blink .................

(On longer than off) Audio quality may be affected

• Fast blink ..................

(Equal on-off) Audio quality is likely to be

affected

BMX_BT_DockOG.fm Page 8 Friday, June 5, 2009 10:19 AM

English

Troubleshooting

If you experience difficulty with your Bluetooth®dock, use the following

table to try to solve the problem. If the problem persists, see “Contacting

customer service” on page 11.

Problem What to do

Cannot

connect

my phone

to the

dock

• Make sure your SoundDock®10 system is connected to AC power.

• Make sure the Bluetooth dock is in discoverable mode (Bluetooth

light is flashing). If not, press and hold the Bluetooth button on the

dock until the Bluetooth light starts flashing.

• Make sure the Bluetooth feature is turned on in your phone. For

details, refer to the owner’s guide for your phone.

• Move your phone closer to the SoundDock 10 system.

• Go to http://owners.Bose.com on the Internet and find information on

updating your SoundDock 10 system.

No sound • Make sure the SoundDock 10 system and your phone are turned on.

• Make sure you have a Bluetooth connection (Bluetooth light is on).

• Move your phone closer to the SoundDock 10 system.

• Turn up the phone volume as high as possible.

• Turn up the SoundDock 10 system volume.

Sound is

dropping

out or

breaking

• Move your phone or SoundDock 10 system away from any device

that generates electromagnetic radiation, such another Bluetooth

device, a microwave oven, or a wireless computer network router.

• Remove any physical obstruction lying between your phone and the

SoundDock 10 system.

• Change the location of your phone and/or the SoundDock 10 system.

BMX_BT_DockOG.fm Page 9 Friday, June 5, 2009 10:19 AM

English

Removing the Bluetooth dock

To remove the Bluetooth dock so you can put the universal dock back in

your system:

1. Slide the release latch (A) to the right.

2. Lift up the right side (B) of the Bluetooth dock to remove it.

Poor

sound

quality

• Move your phone closer to the system or to a different location.

• Move your phone away from any household device that generates

electromagnetic radiation, such as a microwave oven, another

Bluetooth®device, or a wireless computer network router.

• Reduce the number of applications running on your phone.

• Increase the volume on your phone.

Problem What to do

BMX_BT_DockOG.fm Page 10 Friday, June 5, 2009 10:19 AM

Altri manuali per SoundDock 10 Bluetooth

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali Bose Stazione di attracco

Bose

Bose SoundLink Wireless Music System Manuale utente

Bose

Bose SoundDock 10 Bluetooth Manuale utente

Bose

Bose Acoustic Wave music system II. Manuale utente

Bose

Bose SOUNDDOCK PORTABLE DIGITAL MUSIC SYSTEM Manuale utente

Bose

Bose SOUNDDOCK PORTABLE DIGITAL MUSIC SYSTEM Manuale utente

Bose

Bose SOUNDDOCK PORTABLE DIGITAL MUSIC SYSTEM Manuale utente

Bose

Bose SOUNDDOCK PORTABLE DIGITAL MUSIC SYSTEM Manuale utente

Bose

Bose WAVE CONNECT KIT Manuale utente

Bose

Bose SOUNDDOCK PORTABLE DIGITAL MUSIC SYSTEM Manuale utente

Bose

Bose SOUNDDOCK PORTABLE DIGITAL MUSIC SYSTEM Manuale utente

Bose

Bose SoundDock 10 Bluetooth Manuale utente

Bose

Bose SoundLink Wireless Music System Manuale utente

Bose

Bose SoundDock 10 Bluetooth Manuale utente

Bose

Bose SOUNDDOCK PORTABLE DIGITAL MUSIC SYSTEM Manuale utente

Bose

Bose SoundDock 10 Bluetooth Manuale utente

Bose

Bose SOUNDDOCK PORTABLE DIGITAL MUSIC SYSTEM Manuale utente

Bose

Bose SoundDock Series III Manuale utente

Bose

Bose SoundLink Wireless Music System Manuale utente

Bose

Bose SoundDock 10 Bluetooth Manuale utente

Bose

Bose Lifestyle 525 Series III Manuale utente

Manuali Stazione di attracco popolari di altre marche

Sony

Sony Dream Machine XDR-DS12iP Manuale utente

Acer

Acer USB Type-C Dock II Manuale utente

ATEN

ATEN UC-2000 Manuale utente

Xcellon

Xcellon HDD-202 Manuale utente

Dok

Dok CR09 Manuale utente

Philips

Philips BTM630/12 Manuale utente

IOGear

IOGear Travel Pro GUD3C09 Manuale utente

RKI

RKI SDM-E2 Manuale utente

iHome

iHome iP15 Manuale utente

VITURE ONE

VITURE ONE MOBILE DOCK Manuale utente

Lindy

Lindy 42984 Manuale utente

CipherLab

CipherLab 8001 Manuale utente

Pyle

Pyle PIPDSP2 Manuale utente

Avol

Avol AS2350 Manuale utente

Datalogic

Datalogic JoyaTouch Manuale utente

Philips

Philips DC190/79 Manuale utente

Targus

Targus DOCK315EUZ Manuale utente

Akasa

Akasa DuoDockX3 AK-DK08U3-BK Manuale utente
