MRC10

Installation Instructions

Marine Radio Cover

Thank you for purchasing a BOSS Audio Systems product. Please read through

these instructions carefully so you will know how to install this product properly.

Package Contents

• 1x Marine radio cover

• 4x Mounting screws and clip nuts

• Installation Instructions and warranty

Introduction and Features

• Mounting cut-out in the dash (W x H): 8.7” x 3.3” ( 220 x 83 mm)

• Fits single DIN head units (W x H): 7” x 2.0” (178 x 51 mm)

• Marine radio cover dimensions (W x H x D): 10” x 4.1 x 2.6” (249 x 105 x 67 mm)

• Push button activates auto-slide lens cover (spring activated door)

• UV-stabilized ABS plastic housing

• Impact-resistant ABS

• Sealed with an EVA gasket

Product Overview

Push-to-open button

Spring activated ip-up door

Tab to cover

screw holes

Tab to cover

screw holes

Installation

Step 1

Remove two plastic tabs on the front of the marine radio cover to access four mounting

screw holes. You need to fasten the radio cover to the dash through the screw holes.

Note: Use a plastic prying tool to remove the tabs. Exercise caution when prying the tabs

off to prevent damage on the radio cover.

Tab Mounting screw holes

Step 2

Attach your head unit to the radio cover through the opening of the radio cover. The

opening ts a 7” x 2.0” head unit (single DIN). Make sure the head unit is securely attached.

7.7”

2.7”

Step 3

Secure the radio cover in the dash through four screw holes (as described in Step 1) using

four supplied screws and clip nuts. The cut-out in the dash is 8.7” x 3.3” (W x H).

Note: The top of the radio cover needs extra clearance, so that the spring-activated door

can glide smoothly to the open position (top opening).

3.3”

8.7”

(Back view) 0722
