Boss Audio Systems CER122 Manuale utente

Technical Support

If you need technical support with your Boss Audio product or have

questions about its use, please contact us:

805.751.4853

www.BossAudio.com

5

Due to ongoing product development, specifications are subject to change without notice.

1

Congratulations on your purchase of the Boss Audio “CER” Series

Subwoofer. BossAudio takes great pridein producingproducts that

look great, sound great,and stand upto the daily rigorsapplied by

audio enthusiasts around the world.

CER122 12” (30cm) Subwoofer

x Single 4 ΩVoice Coil

x 1600 W Peak Power Handling

x Treated Paper Cone

x Large Foam Surround

2 4

Enclosures

The CER122 is designed to work in a mediumsized sealed or ported

enclosure . Since the wooferhas pole-vent, it needs a minimum

clearance from the rear wall of the enclosure of 0.75” (19 mm). Be-

low you will find the dimensions to make the enclosure to suit the

subwoofers needs, it has been designed for maximum output while

retaining great sound quality.

The dimensions havealready accounted for the volume displacement

of the subwoofer, and using 3/4” (19mm) MDF. All dimensions are

external.

Sealed Dimensions:

Length (L) : 15” (381 mm)

Width (W) : 12” (304.8 mm)

Height (H) : 13” (330.2 mm)

Cutout Diameter: 11” (279 mm)

Ported Dimensions:

Length (L) : 20” (508 mm)

Width (W) : 12” (304.8 mm)

Height (H) : 14” (355.6 mm)

Port Diameter : 4” (101.6mm)

Port Length : 12” (304.8 mm)

Port Freq : 34 Hz

Cutout Diameter: 11” (279 mm)

Enclosure Dimensions

4 Ω

4

Wiring your Subwoofer

Multiple Subwoofers

Series

8 Ω

Parallel

2 Ω

3

Product Specifications

Impedance 4 Ω

ResonantFrequency 35Hz

Qts 0.61

Qms 9.52

Qes 0.66

Vas 3.083cuft.(87.3liters)

Xmax 10 mm

Sensitivity (1 W/ 1 m) 87 dB

Peak Power Handling 1600 W

MountingDepth 5-3/16” (157.2 mm)

Cutout Diameter 11” (279 mm)
