Boss Audio Systems Phantom series P156DVC Manuale utente

P156DVC

Box Volume : 2.0 Cu Ft

Port Frequency : 29 Hz

Port Diameter : 3 lnches

Port Length : 6 lnches

Box is given as internal air volume including driver displacement

Ported Enclosure

Frequency

P156DVC Amplitude Response(dB/Hz)

Box Volume : 2.0 Cu Ft

Box is given as internal air volume including driver displacement

Sealed Enclosure

Recommended Enclosures

Frequency

Please note : Our recommended box volumes are given for

internal air requirements.

P156DVC Amplitude Response(dB/Hz)

Sealed Enclosure

Ported Enclosure

0.646

2.989

0.824

7.519

0.315

1.8

1250W/2500W

1.035

3.161

1.538

7.386

0.315

3.6

1250W/2500W

0.588

3.092

0.726

7.4

0.315

7.2

1250W/2500W

2 4 8

15” (381mm) Subwoofer

(1250 Watts RMS Sealed Enclosure)

Not Use

2 ohms 4 ohms

8 ohms 4 ohms

Wiring

Please take every precaution to wire your DVC woofers

for the correct impedance

Not Used

+-+-

+-+-+-+

15” (381mm) BLACK METALLIC POLY INJECTION CONE

BUTYL RUBBER SURROUND

DUAL 2.5” (64mm) HIGH TEMPERATURE KAPTON

VOICE COIL

2500 WATTS PEAK/1250 WATTS RMS

FREQUENCY RESPONSE: 25Hz-1KHz

SENSITIVITY: 96dB (1 WATT/1 METER)

IMPEDANCE: DUAL 4 OHMS

MOUNTING DEPTH: 8” (203mm)

MOUNTING DIAMETER: 14” (356mm)
