Bosslan BOSST60 Manuale utente
BOSST60 User Manual
1/1
BOSST60 User Manual
BOSST60 User Manual
2/2
1. BOSST60 Features................................................................................................... 4
1.1 Appearance....................................................................................................................... 4
1.2 Interface............................................................................................................................. 4
1.3 Software............................................................................................................................. 4
1.4 Standard and Protocols................................................................................................... 5
1.5 Compliant Standard.......................................................................................................... 5
1.6 Operating requirement..................................................................................................... 5
1.7 Package............................................................................................................................. 6
1.8 Installation.......................................................................................................................... 7
2. Web Configuration .................................................................................................... 8
2.1 Access Web setting page................................................................................................ 8
2.2 Current state...................................................................................................................... 9
2.3 Network............................................................................................................................ 10
2.3.1 Wan Config.................................................................................................10
2.3.2 LAN Config .................................................................................................11
2.4 VoIP .................................................................................................................................. 12
2.4.1 SIP Config...................................................................................................12
2.5 Advance........................................................................................................................... 14
2.5.1 DHCP Server..............................................................................................14
2.5.2 NAT.............................................................................................................15
2.5.3 Net Service.................................................................................................16
2.5.4 Firewall settings..........................................................................................17
2.5.5 QoS settings...............................................................................................19
2.5.6 Advance SIP settings .................................................................................20
2.5.7 Digital Map..................................................................................................22
2.5.8 Call Service Settings ..................................................................................23
2.5.9 MMI Filter....................................................................................................25
2.5.10 Audio Settings.............................................................................................26
2.6 Dial-Peer Settings .......................................................................................................... 27
2.7 Config Manage................................................................................................................ 28
2.8 Update.............................................................................................................................. 29
2.9 System Manage.............................................................................................................. 31
2.9.1 Account Manage.........................................................................................31
2.9.2 Phone Book:...............................................................................................31
2.9.3 Syslog Config:.............................................................................................31
2.9.4 Time Set:.....................................................................................................31
2.9.5 Reboot: .......................................................................................................31
3Use keypad configure BOSST60 IP phone......................................................... 32
3.1 Keypad function.............................................................................................................. 32
3.2 Keypad Menu.................................................................................................................. 33
4Telnet Console......................................................................................................... 36
4.1 Introduce.......................................................................................................................... 36
BOSST60 User Manual
3/3
4.2 Global Command............................................................................................................ 37
4.3 Tree Structure ................................................................................................................. 38
4.4 Network Diagnosis ......................................................................................................... 47
4.5 Restore to factory default.............................................................................................. 47
5POST Mode(safe mode)........................................................................................ 48
6FAQ............................................................................................................................ 49
6.1 How many servers may BOSST60 register simultaneously?.................................. 49
6.2 Why the settings vanish after reboot?......................................................................... 49
6.3 How to use the dial rule?............................................................................................... 49
6.4 How to use speed dial function?.................................................................................. 50
6.5 How to configure digital map?...................................................................................... 50
6.6 How to use Call Forward, Call Transfer and 3-way Conference calls?.................. 50
6.7 How to use the record function?.................................................................................. 52
6.8 How to use set the IP type via keypad?...................................................................... 53
BOSST60 User Manual
4/4
1. BOSST60 Features
1.1 Appearance
1.2 Interface
Power: Output Power:12VDC,500mA.
WAN: RJ45 port.
LAN: RJ45 port.
1.3 Software
Support two sip accounts at the same time.
Redundancies server support.
NAT, Firewall.
DHCP client and server.
Support PPPoE, (used for ADSL, cable modem connecting).
Support major G7.xxx CODEC.
VAD,CNG.
BOSST60 User Manual
5/5
G.168 compliant 32ms echo cancellation
Tone generation and Local DTMF re-generation according with ITU-T
E.164 dial plan and customized dial rules
Hotline.
Speed Dial
Call Forward, Call Transfer, 3-way conference calls
Record
Caller ID display
DND(Do Not Disturb),Black List,Limit List
Upgrade firmware through FTP, TFTP or HTTP,.
Web management.
Telnet remote management.
adjustable user password and super password
1.4 Standard and Protocols
IEEE 802.3 /802.3 u 10 Base T / 100Base TX
PPPoE: PPP Protocol over Ethernet
DHCP Client and Server: Dynamic Host Configuration Protocol
G.711 u/a; G729, G7231 5.3/6.3 audio Codec
SIP RFC3261, RFC 2543
TCP/IP: Internet transfer and control protocol
RTP: Real-time Transport Protocol
RTCP: Real-time Control Protocol
VAD/CNG save bandwidth
Telnet: Internet's remote login protocol
DNS: Domain Name Server
TFTP: Trivial File Transfer Protocol
HTTP: Hyper Text Transfer protocol
FTP: File Transfer protocol
1.5 Compliant Standard
CE：EN55024,EN55022
FCC part15
RoHS
1.6 Operating requirement
●Operation temperature: 0 to 40° C (32° to 104° F)
●Storage temperature: -30° to 65° C (-22° to 149° F)
●Humidity: 10 to 90% no dew
BOSST60 User Manual
6/6
1.7 Package
Size: 338×220×85mm
Packing List
BOSST60 IP phone
Power adaptor (out put 12v ,500mA)
Manual CD
BOSST60 User Manual
7/7
1.8 Installation
Use ethernet cable to connect BOSST60’s LAN port and your computer. Set your
computer’s ip to the network 192.168.10.x or using dynamic obtain IP. Open your
web browser and key in 192.168.10.1. Then you will see the logon page of
BOSST60, the default username and password is admin/admin for administrator
and guest/guest for guest.
Set up page for VoIP use only:
BOSST60 User Manual
8/8
2. Web Configuration
2.1 Access Web setting page
Enter BOSST60 IP address in the web browser and press ENTER to go to the log
on page, and key in the username and password to access BOSST60 setting
page.
Default username and password is:
Administrator: Username: admin password: admin
User: Username: guest Username: guest
BOSST60 User Manual
9/9
2.2 Current state
This page shows BOSST60’s running state.
Network shows the WAN and LAN port connecting state and current settings.
VoIP part show the working state of VoIP, you can see whether BOSST60 has
registered the public sip server or H323 server.
Phone Number shows the H323, public sip and private sip phone numbers.
BOSST60 User Manual
10/10
2.3 Network
2.3.1 Wan Config
WAN port network setting page.
Support static IP, dynamic obtain IP and PPPoE.
Configure Static IP:
----Enable Static;
----Set BOSST60’s IP address in the IPAddress;
----Set netmask in the Netmask field;
----Set router IP address in the Gateway;
----DNS Domain:
----Set local DNS server in the Preferred DNS and the Alternate DNS
Configure to dynamic obtain IP
----Enable DHCP;
If there is DHCP server in your local network, BOSST60 will automatically obtain WAN
port network information from your DHCP server.
Configure PPPoE:
----Enable PPPoE
----PPPoE server: Enter “ANY” if no specified from your ITSP.
----Enter PPPoE username and pin in the username and password.
BOSST60 will automatically obtain WAN port network information from your ITSP if
PPPoE setting and the setup are correct.
Notice: If user accesses the IP phone through WAN port. He/She should use the new IP
address to access the IP phone when the WAN port address was changed.
