STANLEY FASTENING SYSTEMS L.P.

600, 700 & 800 SERIES

PNEUMATIC STAPLER

ENGRAPADORA NEUMÁTICA

AGRAFEUSE PNEUMATIQUE

-2-

INTRODUCTION

The Bostitch 600,700 & 800 series staplers are precision-built tools, designed for high speed, high volume

stapling. These tools will deliver efficient, dependable service when used correctly and with care. As with any

fine power tool, for best performance the manufacturer’s instructions must be followed. Please study this

manual before operating the tool and understand the safety warnings and cautions. The instructions on

installation, operation and maintenance should be read carefully, and the manuals kept for reference. NOTE:

Additional safety measures may be required because of your particular application of the tool. Contact your

Bostitch representative or distributor with any questions concerning the tool and its use. Bostitch, Inc., East

Greenwich, Rhode Island 02818.

INDEX

Safety Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Tool Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Air Supply: Fittings, Hoses, Filters, Air Consumption, Regulators,

Operating Pressure, Setting Correct Pressure . . . . . . . . . . . . . . . . . . . . . . . . . 4 & 5

Lubrication . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Loading the Tool . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Dial-A-Depth™ Fastener Control Adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Tool Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 & 8

Maintaining the Pneumatic Tool . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Trouble Shooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Directional Exhaust . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Quick Release Door. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

NOTE:

Bostitch tools have been engineered to provide excellent customer satisfaction and are designed to achieve

maximum performance when used with precision Bostitch fasteners engineered to the same exacting

standards. Bostitch cannot assume responsibility for product performance if our tools are used with

fasteners or accessories not meeting the specific requirements established for genuine Bostitch nails,

staples and accessories.

LIMITED WARRANTY — U.S. and Canada Only

Effective December 1, 2005 Bostitch, L.P. warrants to the original retail purchaser that the product purchased is free

from defects in material and workmanship, and agrees to repair or replace, at Bostitch’s option, any defective Bostitch

branded pneumatic stapler or nailer for a period of seven (7) years from date of purchase (one (1) year from the date

of purchase for compressors and tools used in production applications). Warranty is not transferable. Proof of

purchase date required. This warranty covers only damage resulting from defects in material or workmanship; it does

not cover conditions or malfunctions resulting from normal wear, neglect, abuse, accident or repairs attempted or

made by other than our national repair center or authorized warranty service centers. Driver blades, bumpers, o-rings,

pistons and piston rings are considered normally wearing parts. For optimal performance of your Bostitch tool always

use genuine Bostitch fasteners and replacement parts.

THIS WARRANTY IS IN LIEU OF ALL OTHER WARRANTIES, EXPRESS OR IMPLIED, INCLUDING BUT NOT

LIMITED TO THE IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR

PURPOSE. BOSTITCH SHALL NOT BE LIABLE FOR ANY INCIDENTAL OR CONSEQUENTIAL DAMAGES.

Some states and countries do not allow limitations on how long an implied warranty lasts, or the exclusion or limitation

of incidental or consequential damages, so the above limitations or exclusions may not apply to you. This warranty

gives you specific legal rights, and you may also have other rights which vary from state to state and country to country.

To obtain warranty service in the U.S. return the product, together with proof of purchase, to the U.S. Bostitch National

or Regional Independent Authorized Warranty Service Center. In the U.S. you may call us at 1-800-556-6696 or visit

www.BOSTITCH.com for the location most convenient for you. In Canada please call us at 800-567-7705 or visit

www.BOSTITCH.com

-3-

SAFETY INSTRUCTIONS

EYE PROTECTION which conforms to ANSI specifications and provides protection against

flying particles both from the FRONT and SIDE should ALWAYS be worn by the operator and

others in the work area when connecting to air supply, loading, operating or servicing this

tool. Eye protection is required to guard against flying fasteners and debris, which could

cause severe eye injury.

The employer and/or user must ensure that proper eye protection is worn. Eye protection

equipment must conform to the requirements of the American National Standards Institute,

ANSI Z87.1 and provide both frontal and side protection. NOTE: Non-side shielded

spectacles and face shields alone do not provide adequate protection.

CAUTION: Additional Safety Protection will be required in some environments. For

example, the working area may include exposure to noise level which can lead to hearing

damage. The employer and user must ensure that any necessary hearing protection is

provided and used by the operator and others in the work area. Some environments will

require the use of head protection equipment. When required, the employer and user must

ensure that head protection conforming to ANSI Z89.1 is used.

AIR SUPPLY AND CONNECTIONS

Do not use oxygen, combustible gases, or bottled gases as a power source for this tool as

tool may explode, possibly causing injury.

Do not use supply sources which can potentially exceed 200 P.S.I.G. as tool may burst,

possibly causing injury.

The connector on the tool must not hold pressure when air supply is disconnected. If a

wrong fitting is used, the tool can remain charged with air after disconnecting and thus will

be able to drive a fastener even after the air line is disconnected possibly causing injury.

Do not pull trigger or depress contact arm while connected to the air supply as the tool may

cycle, possibly causing injury.

Always disconnect air supply: 1.) Before making adjustments; 2.) When servicing the tool;

3.) When clearing a jam; 4.) When tool is not in use; 5.) When moving to a different work

area, as accidental actuation may occur, possibly causing injury.

LOADING TOOL

When loading tool: 1.) Never place a hand or any part of body in fastener discharge area of

tool; 2.) Never point tool at anyone; 3.) Do not pull the trigger or depress the trip as

accidental actuation may occur, possibly causing injury.

OPERATION

Always handle the tool with care: 1.) Never engage in horseplay; 2.) Never pull the trigger

unless nose is directed toward the work; 3.) Keep others a safe distance from the tool while

tool is in operation as accidental actuation may occur, possibly causing injury.

The operator must not hold the trigger pulled on contact arm tools except during fastening

operation as serious injury could result if the trip accidentally contacted someone or

something, causing the tool to cycle.

Keep hands and body away from the discharge area of the tool. A contact arm tool may

bounce from the recoil of driving a fastener and an unwanted second fastener may be

driven possibly causing injury.

Check operation of the contact arm mechanism frequently. Do not use the tool if the arm

is not working correctly as accidental driving of a fastener may result. Do not interfere with

the proper operation of the contact arm mechanism.

Do not drive fasteners on top of other fasteners or with the tool at an overly steep angle as

this may cause deflection of fasteners which could cause injury.

Do not drive fasteners close to the edge of the work piece as the wood may split, allowing

the fastener to be deflected possibly causing injury.

This nailer produces SPARKS during operation. NEVER use the nailer near flammable

substances, gases or vapors including lacquer, paint, benzine, thinner, gasoline, adhesives,

mastics, glues or any other material that is -- or the vapors, fumes or byproducts of which are --

flammable, combustible or explosive. Using the nailer in any such environment could cause an

EXPLOSION resulting in personal injury or death to user and bystanders.

MAINTAINING THE TOOL

When working on air tools note the warnings in this manual and use extra care when

evaluating problem tools.

-4-

600, 700 & 800 SERIES TOOL SPECIFICATIONS

TOOL AIR FITTING:

This tool uses a free-flow connector plug, 1/4” N.P.T. The minimum inside diameter should be .200” (5mm).

The fitting must be capable of discharging tool air pressure when disconnected from the air supply.

OPERATING PRESSURE:

The operating pressure of the 600, 700 & 800 tools is 70 to 120 p.s.i. (4.9 to 8.4 kg/cm2). Select the operating

pressure within this range for best fastener performance. DO NOT EXCEED THIS RECOMMENDED

OPERATING PRESSURE.

AIR CONSUMPTION:

Series 600 requires 2.3 cubic feet per minute (.065 cubic meters per minute) of free air to operate at the rate

of 100 fasteners per minute, at 80 p.s.i. (5.6kg/cm2).

Series 700 requires 3.9 cubic feet per minute. (.110 cubic meters per minute) of free air to operate at a rate of

100 fasteners per minute, at 80 p.s.i. (5.6 kg/cm2).

Series 800 requires 4.8 cubic feet per minute. (.136 cubic meters per minute) of free air to operate at a rate of

100 fasteners per minute, at 80 p.s.i. (5.6 kg/cm2).

For Series 600, 700 & 800 tools, take the actual rate at which the tool will be run to determine the amount of

air required. For instance, if your fastener usage averages 50 fasteners per minute, you need 50% of the c.f.m.

listed above which is required to operate the tool at 100 fasteners per minute.

OPERATION

BOSTITCH OFFERS THREE TYPES OF OPERATION FOR THIS SERIES TOOL.

CONTACT TRIP:

The common operating procedure on “Contact Trip” tools is for the operator to contact the work to actuate the

trip mechanism while keeping the trigger pulled, thus driving a fastener each time the work is contacted. This

will allow rapid fastener placement on many jobs, such as sheathing, decking and pallet assembly. All

pneumatic tools are subject to recoil when driving fasteners. The tool may bounce, releasing the trip, and if

unintentionally allowed to recontact the work surface with the trigger still actuated (finger still holding trigger

pulled) an unwanted second fastener will be driven.

SEQUENTIAL TRIP:

The Sequential Trip requires the operator to hold the tool against the work before pulling the trigger. This

makes accurate fastener placement easier, for instance on framing, toe nailing and crating applications.The

Sequential Trip allows exact fastener location without the possibility of driving a second fastener on recoil, as

described under “Contact Trip”. The Sequential Trip Tool has a positive safety advantage because it will not

accidentally drive a fastener if the tool is contacted against the work – or anything else – while the operator is

holding the trigger pulled.

TRIGGER OPERATED:

The Trigger Operated model is cycled by actuation of the trigger only. This model does not have a Contact

Arm and is intended for use only where a Contact Arm CANNOT be used to satisfy the requirements of the

application. The Trigger Operated tool will cycle each time the trigger is actuated.

MODEL IDENTIFICATION:

Refer to Operation Instructions on page 7 before proceeding to use this tool.

MODEL LENGTH HEIGHT WIDTH WEIGHT

650S4 14.31” (363mm) 10.69” (272mm) 3.31” (84mm) 4.5 lb.

650S5 14.31” (363mm) 10.69” (272mm) 3.31” (84mm) 4.5 lb.

750S4 14.62” (371mm) 11.19” (284mm) 3.87” (98mm) 5.3 lb.

750S5 14.62” (371mm) 11.19” (284mm) 3.87” (98mm) 5.3 lb.

850S4 14.62” (371mm) 12.44” (316mm) 3.87” (98mm) 5.7 lb.

863S4 14.62” (371mm) 12.44” (316mm) 3.87” (98mm) 5.8 lb.

MODEL STAPLE SERIES CROWN WIDTH WIRE SIZE MAXIMUM LEG LENGTH

650S4 16S4 1/2” (12.7mm) .061”x.056” (1.55mmx1.42mm) 2” (50mm)

650S5 17S5 7/16” (11.1mm) .057”x.051” (1.45mmx1.30mm) 2” (50mm)

750S4 16S4 1/2” (12.7mm) .061”x.056” (1.55mmx1.42mm) 2” (50mm)

750S5 17S5 7/16” (11.1mm) .057”x.051” (1.45mmx1.30mm) 2” (50mm)

850S4 16S4 1/2” (12.7mm) .061”x.056” (1.55mmx1.42mm) 2” (50mm)

863S4 15.5S4 1/2” (12.7mm) .068”x.061” (1.73mmx1.55mm) 2-1/2” (63mm)

863S4 15S4 1/2” (12.7mm) .072”x.064” (1.83mmx1.63mm) 2-1/2” (63mm)

CONTACT TRIP SEQUENTIAL TRIP TRIGGER OPERATED

Identified by: Identified by: Identified by:

BLACK TRIGGER GRAY TRIGGER BLACK TRIGGER

All screws and nuts are metric.

FASTENER SPECIFICATIONS:

-5-

AIR SUPPLY AND CONNECTIONS

Do not use oxygen, combustible gases, or bottled gases as a power source for this tool as

tool may explode, possibly causing injury.

FITTINGS:

Install a male plug on the tool which is free flowing and which will release air pressure from the tool when

disconnected from the supply source.

HOSES:

Air hoses should have a minimum of 150 p.s.i. (10.6 kg/cm2) working pressure rating or 150 percent of the

maximum pressure that could be produced in the air system. The supply hose should contain a fitting that will

provide “quick disconnecting” from the male plug on the tool.

SUPPLY SOURCE:

Use only clean regulated compressed air as a power source for this tool. NEVER USE OXYGEN, COMBUSTIBLE

GASES, OR BOTTLED GASES, AS A POWER SOURCE FOR THIS TOOLAS TOOL MAY EXPLODE.

REGULATOR:

Apressure regulator with an operating pressure of 0 - 125 p.s.i. (0 - 8.79 kg/cm2) is required to control the

operatiing pressure for safe operation of this tool. Do not connect this tool to air pressure which can potentially

exceed 200 p.s.i. (14 kg/cm2) as tool may fracture or burst, possibly causing injury.

OPERATING PRESSURE:

Do not exceed recommended maximum operating pressure as tool wear will be greatly increased. The air

supply must be capable of maintaining the operating pressure at the tool. Pressure drops in the air supply can

reduce the tool’s driving power. Refer to “TOOL SPECIFICATIONS” for setting the correct operating pressure

for the tool.

FILTER:

Dirt and water in the air supply are major causes of wear in pneumatic tools. A filter will help to get the best

performance and minimum wear from the tool. The filter must have adequate flow capacity for the specific

installation. The filter has to be kept clean to be effective in providing clean compressed air to the tool. Consult

the manufacturer’s instructions on proper maintenance of your filter. A dirty and clogged filter will cause a

pressure drop which will reduce the tool’s performance.

LUBRICATION

Frequent, but not excessive, lubrication is required for best performance. Oil added through the air line

connection will lubricate the internal parts. Use BOSTITCHAir Tool Lubricant, Mobil Velocite #10, or equivalent.

Do not use detergent oil or additives as these lubricants will cause accelerated wear to the seals and bumpers

in the tool, resulting in poor tool performance and frequent tool maintenance.

If no airline lubricator is used, add oil during use into the air fitting on the tool once or twice a day. Only a few

drops of oil at a time is necessary. Too much oil will only collect inside the tool and will be noticeable in the

exhaust cycle.

COLD WEATHER OPERATION:

For cold weather operation, near and below freezing, the moisture in the air line may freeze and prevent tool

operation. We recommend the use of BOSTITCH WINTER FORMULA air tool lubricant or permanent

antifreeze (ethylene glycol) as a cold weather lubricant.

CAUTION: Do not store tools in a cold weather environment to prevent frost or ice formation on the

tools operating valves and mechanisms that could cause tool failure.

NOTE:Some commercial air line drying liquids are harmful to “O”-rings and seals – do not use these

low temperature air dryers without checking compatibility.

-6-

1. Move pusher to rear until

latched. Cover will open.

Pusher front will drop into

notch on top of magazine

assembly.

2. Drop staple stick over magazine and

slide forward. Repeat until magazine

is loaded, allowing enough space for

pusher to disengage the magazine

and the cover to close.

Approximately 1/2" (13mm)

3. Pull and hold top part of

knob (A) and depress

bottom part of knob (B) in

a clockwise direction to

release pusher.

COVER

CONTACT

ARM

ADJUSTING

NUT

ADAPTER

COVER

MOUNTING

NUTS

NOTE: Use only staples recommended by Bostitch for the 600,700 & 800 Series staplers or staples

which meet Bostitch specifications.

LOADING THE 600,700 & 800

EYE PROTECTION which conforms to ANSI specifications and provides protection against

flying particles both from the FRONT and SIDE should ALWAYS be worn by the operator and

others in the work area when connecting to air supply, loading, operating or servicing this

tool. Eye protection is required to guard against flying fasteners and debris, which could

cause severe eye injury.

The employer and/or user must ensure that proper eye protection is worn. Eye protection

equipment must conform to the requirements of the American National Standards Institute,

ANSI Z87.1 and provide both frontal and side protection. NOTE: Non-side shielded

spectacles and face shields alone do not provide adequate protection.

TO PREVENT ACCIDENTAL INJURIES:

•Never place a hand or any other part of the body in nail discharge area of tool while

the air supply is connected.

•Never point the tool at anyone else.

•Never engage in horseplay.

•Never pull the trigger unless nose is directed at the work.

•Always handle the tool with care.

•Do not pull the trigger or depress the trip mechanism while loading the tool.

Always disconnect air supply: 1. Before making adjustments; 2. When servicing the tool;

3. When clearing a jam; 4. When tool is not in use; 5. When moving to a different work area,

as accidental actuation may occur, possibly causing injury.

“DIAL-A-DEPTH™” FASTENER CONTROL ADJUSTMENT

The DIAL-A-DEPTH™ Fastener Control adjustment feature provides close control of the fastener drive depth;

from flush with the work surface to shallow or deep countersink. First, set the air pressure for consistent drive

in the specific work as described on page 5, then use the DIAL-A-DEPTH™ Fastener Control adjustment to

give the desired depth of drive.

TO ADJUST DIAL-A DEPTH™FASTENER CONTROL ADJUSTMENT:

1. With air pressure set (refer to Setting the Correct Pressure on (Page 5), drive a few fasteners into a

representative material sample to determine if adjustment is necessary.

2. If adjustment is required, disconnect air supply.

3. Refer to label on outside of door for direction to turn adjusting nut. (See illustration)

4. Remove cover mounting nuts, cover and adapter. Observe the orientation of the flats on the adjusting

nut. Rotate the adjusting nut to the left to increase fastener drive depth, or to the right to decrease it.

Reorientate the flats to be same as before. Reinstall adapter, cover and mounting nuts.

5. Before reconnecting air supply, check that trip mechanism parts operate freely with no binding or sticking.

6. Reconnect air supply.

-7-

TOOL OPERATION

EYE PROTECTION which conforms to ANSI specifications and provides protection against

flying particles both from the FRONT and SIDE should ALWAYS be worn by the operator and

others in the work area when connecting to air supply, loading, operating or servicing this

tool. Eye protection is required to guard against flying fasteners and debris, which could

cause severe eye injury.

The employer and/or user must ensure that proper eye protection is worn. Eye protection

equipment must conform to the requirements of the American National Standards Institute,

ANSI Z87.1 and provide both frontal and side protection. NOTE: Non-side shielded

spectacles and face shields alone do not provide adequate protection.

BEFORE HANDLING OR OPERATING THIS TOOL:

I. READ AND UNDERSTAND THE WARNINGS CONTAINED IN THIS MANUAL.

II. REFER TO “TOOL SPECIFICATIONS” IN THIS MANUAL TO IDENTIFY THE

OPERATING SYSTEM ON YOUR TOOL.

There are three available systems on BOSTITCH pneumatic tools. They are:

1. TRIGGER OPERATION 2. CONTACT TRIP OPERATION 3. SEQUENTIAL TRIP OPERATION

OPERATION

1. TRIGGER OPERATION:

ATRIGGER OPERATED tool requires a single action to drive a fastener. Each time the trigger is pulled

the tool will drive a fastener. The trigger operated model is intended for use only when a contact trip or

sequential trip cannot be used due to the requirements of the application.

2. CONTACT TRIP OPERATION:

The CONTACT TRIP MODEL tool contains a contact trip that operates in conjunction with the trigger to

drive a fastener. There are two methods of operation to drive fasteners with a contact trip tool.

A. SINGLE FASTENER PLACEMENT: To operate the tool in this manner, first position the contact trip

on the work surface, WITHOUT PULLING THE TRIGGER. Depress the contact trip until the nose

touches the work surface and then pull the trigger to drive a fastener. Do not press the tool against

the work with extra force. Instead, allow the tool to recoil off the work surface to avoid a second

unwanted fastener. Remove your finger from the trigger after each operation.

B. RAPID FASTENER OPERATION: To operate the tool in this manner, hold the tool with the contact

trip pointing towards but not touching the work surface. Pull the trigger and then tap the contact trip

against the work surface using a bouncing motion. Each depression of the contact trip will cause a

fastener to be driven.

The operator must not hold the trigger pulled on contact trip tools except during fastening

operation, as serious injury could result if the trip accidentally contacted someone or

something, causing the tool to cycle.

Keep hands and body away from the discharge area of the tool. A contact trip tool may

bounce from the recoil of driving a fastener and an unwanted second fastener may be

driven, possibly causing injury.

3. SEQUENTIAL TRIP OPERATION:

The SEQUENTIAL TRIP MODEL contains a contact trip that operates in conjunction with the trigger to

drive a fastener. To operate a sequential trip tool, first position the contact trip on the work surface

WITHOUT PULLING THE TRIGGER. Depress the contact trip and then pull the trigger to drive a

fastener. As long as the contact trip is contacting the work and is held depressed, the tool will drive a

fastener each time the trigger is depressed. If the contact trip is allowed to leave the work surface, the

sequence described above must be repeated to drive another fastener.

-8-

TOOL OPERATION CHECK:

CAUTION: Remove all fasteners from tool before performing tool operation check.

1. TRIGGER OPERATED TOOL:

A. With finger off the trigger, hold the tool with a firm grip on the handle.

B. Place the nose of the tool against the work surface.

C. Pull the trigger to drive. Release the trigger and cycle is complete.

CAUTION: THE TOOL WILL CYCLE EACH TIME THE TRIGGER IS PULLED!

2. CONTACT TRIP OPERATION:

A. With finger off the trigger, press the contact trip against the work surface.

THE TOOL MUST NOT CYCLE.

B. Hold the tool off the work surface, and pull the trigger.

THE TOOL MUST NOT CYCLE.

C. With the tool off the work surface, pull the trigger. Press the contact trip against the work surface.

THE TOOL MUST CYCLE.

D. Without touching the trigger, press the contact trip against the work surface,

then pull the trigger.

THE TOOL MUST CYCLE.

3. SEQUENTIAL TRIP OPERATION:

A. Press the contact trip against the work surface, without touching the trigger.

THE TOOL MUST NOT CYCLE.

B. Hold the tool off the work surface and pull the trigger.

THE TOOL MUST NOT CYCLE.

Release the trigger. The trigger must return to the trigger stop on the frame.

C. Pull the trigger and press the contact trip against the work surface.

THE TOOL MUST NOT CYCLE.

D. With finger off the trigger, press the contact trip against the work surface. Pull the trigger.

THE TOOL MUST CYCLE.

IN ADDITION TO THE OTHER WARNINGS CONTAINED IN THIS MANUAL

OBSERVE THE FOLLOWING FOR SAFE OPERATION

•Use the BOSTITCH pneumatic tool only for the purpose for which it was designed.

•Never use this tool in a manner that could cause a fastener to be directed toward the user

or others in the work area.

•Do not use the tool as a hammer.

•Always carry the tool by the handle. Never carry the tool by the air hose.

•Do not alter or modify this tool from the original design or function without approval from

BOSTITCH, INC.

•Always be aware that misuse and improper handling of this tool can cause injury to

yourself and others.

•Never clamp or tape the trigger or contact trip in an actuated position.

•Never leave a tool unattended with the air hose attached.

•Do not operate this tool if it does not contain a legible WARNING LABEL.

•Do not continue to use a tool that leaks air or does not function properly. Notify your

nearest BOSTITCH representative if your tool continues to experience functional problems.

-9-

MAINTAINING THE PNEUMATIC TOOL

When working on air tools, note the warnings in this manual and use extra care evaluating

problem tools.

CAUTION: Pusher spring (constant force spring). Caution must be used when working with the spring

assembly. The spring is wrapped around, but not attached to, a roller. If the spring is extended beyond

its length, the end will come off the roller and the spring will roll up with a snap, with a chance of

pinching your hand. Also the edges of the spring are very thin and could cut. Care must also be taken

to insure no permanent kinks are put in the spring as this will reduce the springs force.

REPLACEMENT PARTS:

BOSTITCH replacement parts are recommended. Do not use modified parts or parts which will not give

equivalent performance to the original equipment.

ASSEMBLY PROCEDURE FOR SEALS:

When repairing a tool, make sure the internal parts are clean and lubricated. Use Parker “O”-LUBE or

equivalent on all “O”-rings. Coat each “O”-ring with “O”-LUBE before assembling. Use a small amount of oil on

all moving surfaces and pivots. After reassembly add a few drops of BOSTITCH Air Tool Lubricant through the

air line fitting before testing.

AIR SUPPLY-PRESSURE AND VOLUME:

Air volume is as important as air pressure. The air volume supplied to the tool may be inadequate because of

undersize fittings and hoses, or from the effects of dirt and water in the system. Restricted air flow will prevent

the tool from receiving an adequate volume of air, even though the pressure reading is high. The results will

be slow operation, misfeeds or reduced driving power. Before evaluating tool problems for these symptoms,

trace the air supply from the tool to the supply source for restrictive connectors, swivel fittings, low points

containing water and anything else that would prevent full volume flow of air to the tool.

-10-

TROUBLE SHOOTING

PROBLEM CAUSE CORRECTION

Trigger valve housing leaks air O-ring cut or cracked . . . . . . . . . . . . . . . . . . . .Replace O-ring

Trigger valve stem leaks air O-ring/seals cut or cracked . . . . . . . . . . . . . . . .Replace trigger valve assembly

Frame/nose leaks air Loose nose screws . . . . . . . . . . . . . . . . . . . . . .Tighten and recheck

O-ring or Gasket is cut or cracked . . . . . . . . . .Replace O-ring or gasket

Bumper cracked/worn . . . . . . . . . . . . . . . . . . . .Replace bumper

Frame/cap leaks air Damaged gasket or seal . . . . . . . . . . . . . . . . . .Replace gasket or seal

Cracked/worn head valve bumper . . . . . . . . . . .Replace bumper

Loose cap screws . . . . . . . . . . . . . . . . . . . . . .Tighten and recheck

Failure to cycle Air supply restriction . . . . . . . . . . . . . . . . . . . . .Check air supply equipment

Tool dry, lack of lubrication . . . . . . . . . . . . . . . .Use BOSTITCH Air Tool Lubricant

Worn head valve O-rings . . . . . . . . . . . . . . . . .Replace O-rings

Broken cylinder cap spring . . . . . . . . . . . . . . . .Replace cylinder cap spring

Head valve stuck in cap . . . . . . . . . . . . . . . . . .Disassemble/Check/Lubricate

Lack of power; slow to cycle Tool dry, lacks lubrication . . . . . . . . . . . . . . . . .Use BOSTITCH Air Tool Lubricant

Broken cylinder cap spring . . . . . . . . . . . . . . . .Replace cap spring

O-rings/seals cut or cracked . . . . . . . . . . . . . . .Replace O-rings/seals

Exhaust blocked . . . . . . . . . . . . . . . . . . . . . . .Check bumper, head valve spring, muffler

Trigger assembly worn/leaks . . . . . . . . . . . . . .Replace trigger assembly

Dirt/tar build up on driver . . . . . . . . . . . . . . . . .Disassemble nose/driver to clean

Cylinder sleeve not seated correctly

on bottom bumper . . . . . . . . . . . . . . . . . . . . . .Disassemble to correct

Head valve dry . . . . . . . . . . . . . . . . . . . . . . . . .Disassemble/lubricate

Air pressure too low . . . . . . . . . . . . . . . . . . . . .Check air supply equipment

Skipping fasteners; intermittent feed Worn bumper . . . . . . . . . . . . . . . . . . . . . . . . . .Replace bumper

Tar/dirt in driver channel . . . . . . . . . . . . . . . . . .Disassemble and clean nose and driver

Air restriction/inadequate air flow through

quick disconnect socket and plug . . . . . . . . . . .Replace quick disconnect fittings

Worn piston O-ring . . . . . . . . . . . . . . . . . . . . . .Replace O-ring, check driver

Tool dry, lacks lubrication . . . . . . . . . . . . . . . . .Use BOSTITCH Air Tool Lubricant

Damaged pusher spring . . . . . . . . . . . . . . . . . .Replace spring

Low air pressure . . . . . . . . . . . . . . . . . . . . . . . .Check air supply system to tool

Loose magazine nose screws . . . . . . . . . . . . . .Tighten all screws

Fasteners too short for tool . . . . . . . . . . . . . . . .Use only recommended fasteners

Bent fasteners . . . . . . . . . . . . . . . . . . . . . . . . .Discontinue using these fasteners

Wrong size fasteners . . . . . . . . . . . . . . . . . . . .Use only recommended fasteners

Leaking head cap gasket . . . . . . . . . . . . . . . . .Tighten screws/replace gasket

Trigger valve O-ring cut/worn . . . . . . . . . . . . . .Replace O-ring

Broken/chipped driver . . . . . . . . . . . . . . . . . . . .Replace driver (check piston O-ring)

Dry/dirty magazine . . . . . . . . . . . . . . . . . . . . . .Clean/lubricate use BOSTITCH Air Tool Lubricant

Worn magazine . . . . . . . . . . . . . . . . . . . . . . . .Replace magazine

Fasteners jam in tool Driver channel worn . . . . . . . . . . . . . . . . . . . . .Replace nose/check door

Wrong size fasteners . . . . . . . . . . . . . . . . . . . .Use only recommended fasteners

Bent fasteners . . . . . . . . . . . . . . . . . . . . . . . . .Discontinue using these fasteners

Loose magazine/nose screws . . . . . . . . . . . . . .Tighten all screws

Broken/chipped driver . . . . . . . . . . . . . . . . . . . .Replace driver

Questo manuale è adatto per i seguenti modelli

Indice

Lingue:

Altri manuali Bostitch Pistola sparachiodi

Bostitch

Bostitch 400 series Manuale utente

Manuali Pistola sparachiodi popolari di altre marche

DUO-FAST

DUO-FAST CNP 40 M Manuale utente

King Canada

King Canada 8260FSN Guida alla risoluzione dei problemi

Novus

Novus J-155 A Manuale utente

Silverline

Silverline 101315 Manuale utente

Campbell Hausfeld

Campbell Hausfeld CHN103 Manuale utente

Senco

Senco PW 150 Manuale utente

Westfalia

Westfalia 802945 Manuale utente

Grizzly

Grizzly H0580 Manuale utente

Campbell Hausfeld

Campbell Hausfeld HDN23200 Manuale utente

Stanley

Stanley TR35 Manuale utente

Clarke

Clarke CSG10 Manuale utente

FASTEN-PRO

FASTEN-PRO 96755 Istruzioni per il montaggio

Paslode

Paslode 900078 Manuale utente

Senco

Senco M4 Guida all'applicazione

Senco

Senco SPS Manuale utente

Arrow

Arrow T2025 Manuale utente

Senco

Senco SNS40 Manuale utente

Sealey

Sealey SA789.V2 Manuale utente
