BA4800

Powered Speaker System

4-Channel Surround Configuration

Description

The Boston Acoustics BA4800 is an analog 5-piece, 4-channel surround speaker system ideal for

computer gaming or any enhanced audio application at the desktop. The system includes 4

powered micro-satellites and a large, amplified, ported subwoofer for deep bass response. The

BA4800 performs best with PC sound cards offering 4-speaker output (e.g., 2 stereo outputs, front

and rear), but also sounds impressive as a 3-piece music system when connected to any head-

phone jack or line-level output (portable CD player, MiniDisc player, MP3 player, etc.). With added

features like MagnaGuard

magnetic shielding, stable rear tower stands, extra-long surround cable

connections and speaker-mounted controls, you not only get the renowned Boston Acoustics

sound but uncommon flexibility. For more information on Boston Acoustics or our line of home

theater and car products, visit us on the Web at www.bostonacoustics.com.

This Package Contains:

1 Amplified subwoofer

2 Front satellite speakers

(1 with mounted control pod and DIN cable)

2 Rear satellite speakers

(each with a 20-ft. RCA cord)

2 Input cables

(1 green-to-green, 1 purple-to-black)

4 Self-adhesive rubber feet for subwoofer

6 Self-adhesive rubber feet for front satellittes

2 Mini front satellite pedestal stands

2 Tower rear satellite stands

1 Transformer with power cord

Specifications

FREQUENCYRESPONSE(±3dB) 50Hz – 20,000Hz

MAXIMUMSOUND PRESSURE LEVEL (0.5m) 106dB

SUBWOOFER 6

/2" (165mm) polymer treated paper

SATELLITES 2

/2" (65mm) polymer treated paper

CROSSOVERFREQUENCY 180Hz

DIMENSIONS (H xW x D) Subwoofer

/4x 7 x 14

/8" (299 x 178 x 372mm)

Satellites

/4x 3

/2" (83 x 83 x 89mm)

WEIGHT Subwoofer

11.1 lbs. (5.0 kg)

Satellites

1.0 lbs. (0.5 kg) ea.

FINISH Computer gray

Additional Features:

Manual on/off control

(Turn "Volume" control far left)

Variable audio controls

(Volume, Surround & Subwoofer Levels)

Long rear speaker cords for

accurate positioning

Four-channel sound card compatibility

1. Front Speaker Assembly

) Connect the left front speaker's plug into the jack

on the rear of the right front speaker, (NOTE: satellite

speaker with audio controls should be on the right side

of your video monitor).

) Making sure speaker cables are free, slide on front

speaker pedestal stands.

) Attach rubber pads to bottom tips of each pedestal

stand. The rubber pads absorb vibrations between the

speakers and the desktop for a cleaner sound.

2. Input Panel Connections

) Connect the right front

satellite's control cable (blue) to the

"Control" jack (blue) on the back of

the subwoofer.

) Connect each of the audio

input cables (2 ea.) to your PC's

sound card. "Front Analog in"

(green) on the back of the sub-

woofer to the front analog output

on the sound card (usually labeled

"front", "1" or green). "Rear Analog

in" (purple) on subwoofer connects

to the sound card's rear analog

output (usually labeled "rear", "2"

or black).

3. Rear Speaker Assembly

) First, snap on the slide caps to

the top of each tower tube. Then feed

the connection cord from each

speaker down through the tube. Next,

slide each satellite speaker on to top of

tower tube, making sure the cords are

not being pinched. Finally, with the

cord passing through the bottom of

the tower tube, slide on each of the

three stability legs. The cord should

pass freely through the intersection of

the three stability legs.

) With each of the two tower speaker

cords passing down through the tubes,

connect each plug to the respective

right and left "Rear Speaker" jacks on

the back of the subwoofer (red to red

and white to white).

) Plug in power cable/transformer into

back of subwoofer and available AC outlet.

SCALE 0.500

Tower tube

Connection cords

Stability legs

Back of subwoofer

SCALE 0.500

Right front speaker

with control pod

Back of subwoofer Back of computer

Apply subwoofer's rubber pads to each corner

Control cable

Limited Warranty

For one year from the date of purchase, Boston Acoustics will repair for the original owner any defect in

materials or workmanship that occurs in normal use of the speaker system, without charge for parts and labor.

Your responsibilities are to use the system according to the instructions supplied, to provide safe and

secure transportation to an authorized Boston Acoustics service representative and to present proof of

purchase in the form of your sales slip when requesting service.

Excluded from this warranty is damage that may result from abuse, misuse, accidents, shipping, or repairs

or modifications by anyone other than an authorized Boston Acoustics service representative.

This warranty is void if the serial number has been removed or defaced.

This warranty gives you specific legal rights, and you may also have other rights, which may vary from state to state.

If Service Seems Necessary

Please contact the retailer from whom you purchased the system. If that is not possible, write to:

Boston Acoustics, Inc., 300 Jubilee Drive, Peabody, MA 01960, or call 1-(978)-538-5000.

We will promptly advise you of what action to take. If it is necessary to return your speaker to the factory,

please ship it prepaid. After it has been repaired, we will return it freight prepaid in the U.S. and Canada.

reserved. BA4800 is a trademark and MagnaGuard,

Boston, and Boston Acoustics are registered

trademarks of Boston Acoustics, Inc.

Specifications subject to change without notice.

Part# 042-001133-0

300 Jubilee Drive

Peabody, MA 01960

(978) 538-5000

Notice of FCC Compliance

This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:(1)This

device may not cause harmful interference, and (2) this device must accept any interference received, including

interference that may cause undesired operation.

Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part

15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a

residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed

and used in accordance with the instructions, may cause harmful interference to radio communications. However,

there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful

interference to radio or television reception, which can be determined by turning the equipment off and on, the user is

encouraged to try to correct the interference by one or more of the following measures:

-- Reorient or relocate the receiving antenna

-- Increase the separation between the equipment and receiver

-- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected

-- Consult the dealer or an experienced radio/TV technician for help
