The newest addition to the G1 line, the G108. Like all other G1

subwoofers, the G108 is available in both single and dual 4-ohm

voice coil versions. Its slim chassis allows the G108 to fit in very small

places, only requiring 4 1⁄4”of depth and 0.3 Ft3for the sealed

enclosure or 0.8 Ft3for the ported.

Utilizing our patented RadialVent®cooling and a stout 2-inch voice

coil, the G108 subwoofers offer great power handling and reliability

compared to conventional designs. Reliability and convenience are

taken one step further with our unique SureSet™system that delivers

impedance selection as well as overdrive protection.

Performance Features:

• 1 1⁄2-inches of peak-to-peak excursion for accurate, deep bass output from small

sealed or ported enclosures.

•Patented RadialVent®cooling directs airflow around a 2-inch voice coil for

increased power handling and reliability.

•Available in single 4-ohm or dual 4-ohm voice-coil configurations; allowing the

wiring of single or multiple woofers to present a final system impedance of

2-ohms—delivering maximum power output from Boston GT amplifiers.

•SureSet™provides impedance selection as well as overdrive protection.

•Rugged input terminals accept bare 8-gauge wire or a pin connector.

Installation Features:

•G108 subwoofers excel in small sealed enclosures—only 0.3 Ft3including

displacement!

•G108 subwoofers are flexible, allowing them to be used in high output ported

enclosures.

•G108 subwoofers provide outstanding performance even in infinite baffle

applications.

•G108 subwoofers feature integral sealing gaskets simplifying both standard or

inverted mounting.

Model Size Impedance Mounting Depth Sealed Enc. Ported Enc.

G108-44 8" Dual 4-ohm (2/8-ohm) 4 1⁄4”(107mm) 0.3 Ft30.8 Ft3w/ 2” x 8” Port

G108-4 8" Single 4-ohm 4

1⁄4”(107mm) 0.3 Ft30.8 Ft3w/ 2” x 8” Port

G110-44 10" Dual 4-ohm (2/8-ohm) 4 3⁄4”(120mm) 0.5 Ft31.3 Ft3w/ 3” x 10” Port

G110-4 10" Single 4-ohm 4

3⁄4”(120mm) 0.5 Ft31.3 Ft3w/ 3” x 10” Port

G112-44 12" Dual 4-ohm (2/8-ohm) 5” (126mm) 1.0 Ft32.0 Ft3w/ 4” x 13” Port

G112-4 12” Single 4-ohm 5” (126mm) 1.0 Ft32.0 Ft3w/ 4” x 13” Port

©2007 Boston Acoustics, Inc. Covered by patents issued and pending. All Rights Reserved. SureSet is a trademark and Boston, Boston Acoustics, the Boston

Acoustics logo, and RadialVent are registered trademarks of Boston Acoustics, Inc. All specifications are subject to change.

Boston Acoustics, Inc. 300 Jubilee Drive, Peabody,MA 01960 Phone # 978-538-5000 Fax # 978-538-5100 Web : www.bostonacoustics.com
