BOX DOCCIA NADIA Manuale utente
2.2
2.3
FIRST STAGE
SECOND STAGE
3.1
3.2
THIRD STAGE
Reversible enclosure
If you wish the left opening,
just slide the door in the rail
proles, with the handle facing
towards the inside.
FOURTH STAGE
Assembly instructions
Insert the upper and lower rail prole
in the angle brackets of the
previously assembled left side prole.
FIFTH STAGE SIXTH STAGE
2.1
Assembly instructions
Slide the folding door in both upper
and lower rail prole, as shown in
gure, making sure that all door
supports are inserted in the rail prole.
To make the operation easier cluster
the folding doors.
Assembly instructions
Insert the upper and lower rail prole
in the angle brackets of the previously
assembled right side prole.
Folding door“X” n. 2
Folding door“1”n. 2
n. 2
n. 1
Spare parts n. 3
n. 1
n. 2
n. 1
Magnetic plate n. 1
Level, pencil, awl, hammer, drill, drill bit 6 mm,
cross screwdriver, silicone caulking gun.
Assembly tools
Inner side shower compartment
Side to x
to wall
Outer side compartment
Assembly instructions
Tale the left-side prole and place it, as shown in the gure,
with the widest part facing outward. Place an angle bracket
marked by the number "1" in the upper part (Fig. 3.1) and an
angle bracket marked by an "X" in the lower part (Fig. 3.2).
IMPORTANT: The sides of the angle bracket marked by the "X"
and "1" should not be inserted within the prole, but must
remain outside, so that symbols remain visible.
Anchors and screws n.10+12
: Inner side shower compartment
Outer side compartment
Assemby instructions
Take the right-side prole, which has two small holes (in the
middle) for xing the magnetic plate (Fig. 2.1) and place it,
as shown in the gure, with the widest part facing outward.
Place an angle bracket marked by the number "1" in the
upper part (Fig. 2.2) and an angle bracket marked by an "X"
in the lower part (Fig. 2.3).
IMPORTANT: The sides of the angle bracket marked by the
"X" and "1" should not be inserted within the prole,
but must remain outside, so that symbols remain visible.
Reversible enclosure
The images and assembly
are related to the enclosure
with right opening.
If you wish the left opening,
simply invert the position
of the two side proles,
in order to have the prole
with the small holes for
xing the magnetic plate
(Fig. 2.1) on the left side.
NADIA
SIDE OPENING
ASSEMBLY INSTRUCTIONS
Folding door
Attachment door prole
Incoming prole for door Rail prole Side prole
Side prole section
Side to x
to wall
Side prole section
SEVENTH STAGE
TENTH STAGE
Istruzioni di montaggio
ELEVENTH STAGE TWELFTH STAGE
THIRTEENTH STAGE FOURTEENTH STAGE
7.2
7.1
8.1
8.2
6mm
EIGHTH STAGE
NINTH STAGE
Incoming prole
for door section
Incoming prole
for door section
x1
x2
x2
x1
x2
x2
x1
x2
x2
x1
x2
x2
n.1
n.2
n.2
n.1
n.2
n.2
Assembly instructions
Take the assembled enclosure and put it into the enclosure
compartment. Mark on the walls, with an awl, the ten holes on
the proles (Fig. 7.1).
IMPORTANT: The prole must be perfectly plumb (Fig. 7.2).
NOTICE: Ensure that in the wall there are no power or telephone
lines, water pipes or gas.
Move the enclosure away from the wall and with a drill pierce
the ten holes where the marks were drawn up (Fig. 8.1).
Insert anchors into the holes (Fig. 8.2).
NOTICE: Ensure that in the wall there are no power or
telephone lines, water pipes or gas.
10.1
10.2
Assembly instructions
Take the assembled shower enclosure
and add it in the shower compartment.
Secure the enclosure to the walls with
screws, being careful not to use
excessive force.
Assembly instructions.
From inside the shower compartment, insert, interlocking,
the attachment door prole (Fig. 10.2) in the left side prole
(Fig. 10.1). Exercise, top to bottom, the pressure needed to
hear the insert click. Proceed, then, for the entire length of the
side prole. NOTICE: Careful not to mistake the attachment
door prole (Fig. 10.2) with the incoming door prole (Fig. 10.3)
Reversible enclosure
Reversible enclosure
Assembly instructions
From inside the shower compartment, insert, interlocking,
the incoming prole for door in the right side prole.
Exercise, top to bottom, the pressure needed to hear the insert
click. Proceed, then, for the entire length of the side prole.
Istruzioni di montaggio
From inside the shower compartment insert,
interlocking, the last semitransparent
component of the folding doors in the
attachment door prole, previously installed.
Exercise, top to bottom, the pressure needed
to hear the insert click. Proceed, then, for the
entire length of the side prole.
Assembly instructions
Screw the magnetic plate to
incoming prole for door.
Assembly instructions.
Assembly instructions
Apply silicone on the outside of
the enclosure and let it dry for at
least 24 hours.
Lubricate the rail proles using
liquid soap or liquid cream,
to facilitate doors sliding.
Instructions
To prevent fraying,
if necessary, secure
the rail proles with
the screws,
as shown.
10.3
Proles Section
If you wish the opening to the left, just enter the
attachment door prole in the right side prole.
Proles Section Proles Section
If you wish the opening to the left, just enter the incoming
prole for door in the left side prole.
