Breville JE16 Manuale utente
Professional Juicer
JE16
Instructions
JE16_New.pmd 3/24/2006, 4:17 PM1
2
FEATURES OF YOUR JUICE EXTRACTOR
2
3
4
5
1
6
7
8
9
10
11
12
JE16_New.pmd 3/24/2006, 4:17 PM2
3
3
1Suction Feet
To keep the appliance from slipping/moving.
2Large Pulp Collector
(dishwasher safe)
3Juicer Cover
(dishwasher safe)
4Extra Wide Feed Chute
fits whole apples,carrots, tomatoes and peeled oranges. Makes juicing fruit and
vegetables fast and easy.
5Food Pusher
for pushing whole fruit and vegetables down the wide Feed Chute.
6Safety Locking Arm
Juicer will not operate without Juicer Cover in place and safety locking arm in place
in the vertical operating position.
7Extractor Filter
(dishwasher safe)
8Extractor Filter Holder
(dishwasher safe)
9Juice Collector Jug with Slide-In Froth Separator (3 parts)
(dishwasher safe)
- 1 Litre dishwasher safe juice jug.
- Juice Jug Lid allows juicer to operate with the lid on, therefore eliminating any
splatter during operation. Place lid onto juice jug to store juice in refrigerator.
- Slide-in Froth separator ensures juice froth is separated from juice when poured
into a glass (if preferred).
10 Juice Outlet
The juice will be extracted in the Extractor Filter Holder and flow out the juice
outlet.
11 Motor Base
12 Operating Switch (3 Position)
With two speeds ( I / II) and Off. Low (I) speed for juicing soft fruits with high water
content such as watermelon. High (II) speed for juicing hard fruit and vegetables.
FEATURES OF YOUR JUICE EXTRACTOR
JE16_New.pmd 3/24/2006, 4:17 PM3
4
PARTS IDENTIFICATION
Extractor Filter
Extractor Filter Holder
Food Pusher
Large Pulp
Collector
Juicer Cover with
Feed Chute
Juice Collector Jug
Motor Base with Safety
Locking Arm
JE16_New.pmd 3/24/2006, 4:17 PM4
5
5
GETTING STARTED
Your Professional Juicer is designed to make juices. Although your Professional Juicer
is simple to use and maintain, please read all instructions and warnings in this book
before use.
Remove your Professional Juicer carefully from the box. Remove all packaging and
any labels. You may wish to store the packaging for future use.
IN THE BOX
•Motor Base with Safety Locking Arm
•Extractor Filter Holder
•Extractor Filter
•Juicer Cover with Feed Chute
•Food Pusher
•Large Pulp Collector
•Juice Collector Jug with Slide-in Froth Separator
•Instruction Book
CLEANING
Before using your Professional Juicer for the first time, wash the Extractor Filter,
Extractor Filter Holder, Lid with feed chute, Pusher, Pulp Collector and the Juice
Collector with hot, soapy water. Rinse and dry thoroughly. Using a damp cloth, wipe
the exterior of the Motor-ead and dry thoroughly.
WARNING! Take great care when handling the Extractor Filter, as the blades on
its surface are very sharp
WARNING! Always make sure the Professional Juicer is turned off and unplugged
at the mains before cleaning.
JE16_New.pmd 3/24/2006, 4:17 PM5
6
USING YOUR PROFESSIONAL JUICER
ASSEMBLY
WARNING! Always make sure the Professional Juicer is turned off and unplugged
at the mains before assembly.
•Position the Motor Base on a dry
flat surface out the reach of
children and close to the mains
supply socket.
•Place the Extractor Filter holder
(1) over the centre of the Motor
Base, it will only fit one way
round.
•Align the arrows on the Extractor
Filter (2) with the arrows on the
motor drive coupling and push
down until it is seated securely
inside the Extractor Filter Holder
and onto the Motor base.
•Place Juicer Cover (3) onto the
Professional Juicer over the
Extractor Filter Holder,
positioning the Feed Chute over
the Extractor Filter.
•Push the Juicer Cover (4) down
with one hand whilst raising the
Safety Locking Arm up and
locate into the two gooves on
either side of the Juicer Cover.
The Safety Locking Arm should
now be in a vertical position and
locked into place on top of the
Juicer Cover.
1
2
3
4
6
JE16_New.pmd 3/24/2006, 4:17 PM6
7
7
NOTE: The juice extractor will not operate unless the Lid and the Safety Locking
Arm is fitted correctly.
• Slide the Food Pusher (5) down the Feed Chute by aligning the groove in the Food
Pusher with the small prtrusion on the inside of the top of the Feed Chute.
•Place the Pulp Collector (6) into position by tilting slightly, ensuring that the lug on
the bottom of the Pulp Collector fits into the slot at the rear of the Motor Base.
HINT: To minimize washing up we suggest you place a plastic freezer bag (or
plastic grocery bag) into the Pulp Collector to collect the pulp.
•Place the Juice Collector Jug (7) provided under the juice outlet spout.
(Before placing the Jucie Collector Jug, attach the Slide-in Froth Separator (a) and
attach the Lid (b))
Your Professional Juicer is now ready for use.
USING YOUR PROFESSIONAL JUICER
JE16_New.pmd 3/24/2006, 4:17 PM7
8
USING YOUR PROFESSIONAL JUICER
CHOOSING FRUITS AND VEGETABLES
The best results will be obtained if you juice really fresh produce, as foods which have
been stored for any length of time will have dried out.
FOOD PREPARATION
If you prepare the fruits and vegetables in advance and place the cut pieces in a dish,
it will speed the juicing process.
• As a general guideline, you do not need to peel any fruits and vegetables whose
skin you would normally eat. However, we do recommend washing all produce
before it is juiced, as the majority of commercially grown fruits and vegetables are
sprayed with fertilisers and insecticides.
Certified organic vegetables are guaranteed not to contain chemical residues, but
should still be washed, as they may have been handled prior to sale.
• Always trim off any blemishes.
• Scrub carrots etc. with a brush to remove any dirt.
• Remove skin from thick skinned fruits, such as melon and pineapple.
• Remove the stones from cherries, peaches, nectarines etc.
• Fruit containing small seeds, such as apples, need not be cored.
• Cut the produce into pieces that will fit easily into the feed tube. Never attempt to
force large items. Do not cut pieces smaller than necessary.
• Leafy herbs and vegetables should be rolled tightly.
NOTE: Ensure that the Juice Collecting Jug is placed beneath the juice outlet
before you start juicing.
OPERATING
Ensure the appliance is fully assembled and the power switch is set to the Off
position, insert the plug into a suitable mains socket.
Make sure the appliance is seated on a secure, level surface.
Placing the appliance on a smooth surface will ensure that the suction feet hold the
appliance securely when in use.
Make sure the Extractor Filter is thoroughlt cleaned before each use (refer to the ‘Care
and Cleaning’ section).
JE16_New.pmd 3/24/2006, 4:17 PM8
9
9
USING YOUR PROFESSIONAL JUICER
1 Switch on the appliance. Turn the power switch to ‘LOW’ (I) or ‘HIGH’ (II) speed,
depending on the type of fruit or vegetable being juiced. Use the speed selector
table below as a guide for juicing different fruits and vegetables.
2 Place food into the Feed Chute, using
the Food Pusher, gently guide food down
the Feed Chute. To extract the maximum
amount of juice, always push the Food
Pusher down slowly.
3 Juice will flow into the Collector Jug
through the Juice Outlet Spout and the
separated pulp will accumulate in the
Pulp Container.
NOTE: When juicing very soft fruits,
such as strawberries, peaches etc. You
may find that they are juiced as soon as
they hit the Extractor Filter.
HINT: As you juice your fruit and
vegetables, the pulp will be ejected into
the Pulp Collector. Always empty the
container before it gets too full. If you are
juicing carrots (for example), the pulp
can be used in carrot cake recipes.
Always watch the level of juice in the
Collecting Jug. Do not overfill, as juice will
continue to drip from the juice outlet after
you have stopped juicing. Switch off the
appliance and allow the dripping to stop
before removing the Juice Collector Jug.
IMPORTANT: If you are processing a
large quantity of food and use the
appliance for more than 3 minutes
continuously, allow the appliance to rest for 10 minutes before starting
again.
JE16_New.pmd 3/24/2006, 4:17 PM9
10
USING YOUR PROFESSIONAL JUICER
EMPTYING THE PULP COLLECTOR
Always check the level of juice in the Juice Collector Jug. Do not overfill, as juice will
continue to drip from the juice outlet after you have stopped juicing. Switch off the
appliance and allow the dripping to stop before removing the Juice Collector Jug.
When the Pulp Collector starts getting full, switch off the appliance, empty the Pulp
Collector.
Hold the Pulp Collector, tilt (1) the Pulp Collector a bit and move it away (2) from the
appliance, as shown below.
NOTE: Take care not to spill content in the Pulp Collector when tilting.
To refit, place back onto the rear of the Motor Base. Ensure that the lug on the bottom
of the Pulp Collector fits into the slot at the rear of the Motor Base.
JE16_New.pmd 3/24/2006, 4:17 PM10
