Bristan Quadrant Riser Rail kit Manuale utente

AFTERCARE

INSTRUCTIONS

Your fitting has a high quality finish and should be treated with care to

preserve the visible surfaces.

All surface finishes will wear if not cleaned correctly, the only safe way to

clean your fitting is to wipe with a soft damp cloth. Stains can be

removed using washing up liquid. All bath cleaning powders and liquids

will damage the surface of your fitting even the non-scratch cleaners.

GUARANTEE

All products are manufactured to the highest standards and a 5 year

guarantee covers any defect in manufacture.

As gold and special effect finishes are softer than chromium plate,

special care must be taken when cleaning, a 3 year guarantee covers

these finishes.

NOTE: - the 5 year guarantee is invalidated if damaged by any

waterborne debris.

PRODUCT CODE: KIT1 C / ST

TELEPHONE HELP LINE! +44 (0) 870 4425553

Bristan Limited

Birch Coppice Business Park

Dordon

Tamworth

Staffordshire

B78 1SG

Web site: www.bristan.com

Telephone: +44 (0) 870 4425556

Facsimile: +44 (0) 870 4425554

Email: [email protected]

(FI KIT1 30/04/02 MZ)

Quadrant Riser Rail Kit

Fitting

Instructions

Before starting any installation project, consider

“safety” first. Look for the “safety note” sign and

read the safety advice.

Please keep these instructions for future reference

For latest prices and delivery to your door visit MyTub Ltd 0845 303 8383 www.mytub.co.uk

550 mm

33 mm

CONTENT

•Slider rail (x1)

•Slider (x1)

•Wall bracket assemblies (x2)

•Wall fixing kit (x2)

•Hose (x1)

•Handset (x1)

INSTALLATION

1. Identify all components and check for completeness, particularly

before arranging installation.

2. Pulling out the wall bracket securing plugs (1) from ends of riser tube

(3) and removing the wall bracket assemblies (2) will reveal the wall-

fixing holes.

3. Use the riser tube (3) loosely assembled with the wall brackets as a

template to establish the position for the slider rail and mark out the

fixing holes or use the diagram as a guide.

Prior to drilling into walls, check there are no hidden

electrical wires, cables or water supply pipes with

the aid of an electronic detector. If you use power

tools do not forget:

•Wear eye protection

•Unplug equipment after use

4. Drill holes to suit, and insert rawl plugs if required.

5. Screw wall brackets to wall using supplied fixing kit. Make sure the

holes in the wall bracket assemblies are horizontal, then position riser

tube onto brackets and secure with plugs (2).

6. Please ensure that the hose (5) will connect to your valve in the

extreme position with the handset (6) fitted in position, using small

sealing washers.

7. See over the page for aftercare instructions.
