Britax Monarch Manuale utente

Monarch™

User Guide

PLEASE READ

INSTRUCTIONS

STORE UNDER

BASE

Safety Information

Warnings

Important Notes

Certification

Registration

Vehicle Safety

Vehicle Safety Belts

Vehicle Seating Positions

Features

Attaching the Backrest

Adjustments

Adjusting the Backrest

Adjusting Width of the Base

Adjusting Headrest Height

Using the Booster Seat

Installation

Securing the Child

Using the Retractable Cup Holders

Using the Booster without a Backrest

Care & Maintenance

Cover Removal

Care and Maintenance

Warranty Information

4-6

4-5

8-9

11-12

13-15

16-17

Contents

Use only with children whose height is between 38 and 60 inches (97 and

152 cm).

DO NOT use this booster seat without the backrest unless it is used in a

seating position with a vehicle headrest.

DO NOT use this booster seat as a backless booster unless proper vehicle-

belt placement can be achieved.

Use only the vehicle’s lap-and-shoulder-belt system when restraining a

child in this booster seat.

Follow all instructions on this child restraint and in the written instructions.

To ensure proper restraint use, keep and store this user guide under the

base of the seat.

Use restraint forward facing only!

This booster seat must not be used in the home, in boats, or other non-

certified applications.

Do not use any part of this booster seat with other seat cushions or back

rests.

Secure booster seat even when unoccupied. In a crash, an unsecured

booster seat may injure vehicle occupants.

This booster seat is not compatible with vehicle child-restraint anchorage

systems (LATCH).

Do not use this booster seat with two-point vehicle belts (lap-belt only or

shoulder-belt only). Your child would be seriously injured in the event of a

crash.

To prevent injury due to deterioration, hidden damage, lost instructions,

outdated technology, etc., discontinue use of a booster seat that is older

than six years or has been in a severe crash.

DEATH or SERIOUS INJURY can occur.

WARNING!

Based on crash statistics, the National Highway Traffic Safety

Administration recommends that parents select the rear seat as the safest

location for a properly installed booster seat. Please study the section on

Vehicle Safety Belts in this booklet to ensure the child’s safety. If in doubt

about installing this booster seat, consult the vehicle owner’s manual.

The primary protection for occupants of a vehicle in a collision is the

structure of the vehicle itself; a booster seat will not protect a child when

the vehicle is seriously impacted. However, correctly installed, a booster

seat will substantially improve the chances for survival in most crashes.

Make sure all users fully understand the correct ways to use this booster

seat in a vehicle.

Do not, except as described in this book, attempt to disassemble or modify

any part of the booster seat or vehicle belts.

Do not leave loose objects, e.g. books, bags, etc., in the back of a vehicle.

In the event of a sudden stop, loose objects will keep moving, potentially

causing serious injuries.

Do not leave folding vehicle seats unlatched. In the event of a sudden stop,

a loose seat back could prevent the booster seat from protecting the child

as well as it should.

Do not use anything to raise the booster seat off the vehicle seat.

Do not allow children to play with this booster seat.

Do not leave children alone in a vehicle, even for a short time.

WARNING!

DO NOT place a child restraint

in the front seat of a vehicle with

a passenger air bag. DEATH or

SERIOUS INJURY can occur. The

back seat is the safest place for

children under 12.

DEATH or SERIOUS INJURY can occur.

Safety Information

• Children who weigh 40 pounds (18 kg) or less are best protected in

a restraint with a five-point harness. Britax recommends that children

remain in a restraint with a five-point harness until reaching the

maximum weight or height allowed.

• Set a good example by always wearing your seat belt. Make it a firm

rule that the vehicle does not move until everyone is buckled up making

no exceptions.

• Cover the booster seat with a towel or blanket when the vehicle is

parked in direct sunlight. Parts of the booster seat could become hot

enough to burn the child.

• Store the booster seat in a safe place when not in use. Do not place

heavy objects on top of the booster seat while in storage.

Maximum Height

Child is too tall when top of ears are above

the top of a fully raised headrest.

Important Notes

This child restraint system conforms to all applicable Federal motor

vehicle safety standards. This restraint is not certified for use in aircraft.

Lap belts provided in aircraft cannot be used safely with this product.

Visit www.BritaxUSA.com to register your restraint online!

Child restraints could be recalled for safety reasons. You must register

this restraint to be reached in a recall. Send your name, address and

the restraint’s model number and manufacturing date to Britax Child

Safety, Inc., 13501 South Ridge Drive, Charlotte, NC, 28273 or call 1-

888-4BRITAX. For recall information, call the U.S. Government’s Auto

Safety Hotline at 1-888-327-4236 (TTY: 1-800-424-9153), or go to

www.NHTSA.gov.

Certification

Registration

Vehicle Safety Belts

IMPORTANT: Some vehicles have no seating positions compatible with this

or any other booster seat. If in doubt, contact the vehicle manufacturer for

assistance.

To protect your child in a crash, you must use this booster seat with vehicle

safety belts that are compatible. This booster seat can only be used with

three-point (shoulder-and-lap) safety belts that are not motorized or

anchored on the vehicle door.

The following types of vehicle belts are not compatible with this booster seat:

xTwo-point belts of any kind.

xFront vehicle belts with top or

bottom anchorage points in the door.

xMotor-driven, automatic vehicle belts.

xThree-point belts that have separate

retractors for the shoulder and lap sections.

The vehicle owner’s manual will have information on the types of seat

belts in the vehicle. If the belt type is listed above, select another seating

position.

Vehicle Safety

• Britax and the U.S. Department of Transportation warn that children

12 and under must ride in the rear seats, away from front air bags. The

only exception is if the air bag is turned off. When using in a vehicle with

air bags, refer to the vehicle owner’s manual for additional booster seat

installation instructions and precautions.

• Only use this booster seat in forward-facing vehicle seats. Side-facing or

rear-facing seats in vans, station wagons or trucks CANNOT be used.

WARNING!

Vehicle Seating Positions

1. Headrest

2. Backrest

3. Side wings

4. Armrest (one on each side)

5. Color-coded lap-belt guide (one on each side)

6. Base adjustment lever (one on each side)

7. Retractable cup holder (one on each side)

8. Base

Features

9. Headrest height-adjustment handle

10. Shoulder-belt guide (one on each side)

11. Recline flap

12. Backrest attachment axle

Attaching the Backrest

Fold the plastic tab on the backrest

upward, align the backrest

attachment axle with the axle guide

on the base and slide the backrest

attachment axle into position. (Fig. A)

Push the plastic tab under the seat

cushion so that it rests on the plastic

surface of the base. (Fig. B)

Swivel the backrest up until you

hear a “click.” Backrest is not fully

engaged until a click is heard. (Fig. C)

Tip: Always use caution and keep

fingers away from moving parts to

avoid potential injury.

To attach the backrest to the base, place the base on a flat surface and

align the back rest evenly with the base.
