DCFM Migration Guide

Supporting DCFM 10.4.X

2 of 38 DCFM Migration Guide

53-1001776-01

Brocade, the B-wing symbol, BigIron, DCX, Fabric OS, FastIron, IronPoint, IronShield, IronView, IronWare, JetCore, NetIron, SecureIron, ServerIron,

StorageX, and TurboIron are registered trademarks, and DCFM, Extraordinary Networks, and SAN Health are trademarks of Brocade

Communications Systems, Inc., in the United States and/or in other countries. All other brands, products, or service names are or may be

trademarks or service marks of, and are used to identify, products or services of their respective owners.

Notice: This document is for informational purposes only and does not set forth any warranty, expressed or implied, concerning any equipment,

equipment feature, or service offered or to be offered by Brocade. Brocade reserves the right to make changes to this document at any time,

without notice, and assumes no responsibility for its use. This informational document describes features that may not be currently available.

Contact a Brocade sales office for information on feature and product availability. Export of technical data contained in this document may

require an export license from the United States government.

The authors and Brocade Communications Systems, Inc. shall have no liability or responsibility to any person or entity with respect to any loss,

cost, liability, or damages arising from the information contained in this book or the computer programs that accompany it.

The product described by this document may contain “open source” software covered by the GNU General Public License or other open source

license agreements. To find out which open source software is included in Brocade products, view the licensing terms applicable to the open

source software, and obtain a copy of the programming source code, please visit http://www.brocade.com/support/oscd.

Brocade Communications Systems, Incorporated

Document History

Corporate and Latin American Headquarters

Brocade Communications Systems, Inc.

1745 Technology Drive

San Jose, CA 95110

Tel: 1-408-333-8000

Fax: 1-408-333-8101

E-mail: inf[email protected]

Asia-Pacific Headquarters

Brocade Communications Systems China HK, Ltd.

No. 1 Guanghua Road

Chao Yang District

Units 2718 and 2818

Beijing 100020, China

Tel: +8610 6588 8888

Fax: +8610 6588 9999

E-mail: [email protected]

European Headquarters

Brocade Communications Switzerland Sàrl

Centre Swissair

Tour B - 4ème étage

29, Route de l'Aéroport

Case Postale 105

CH-1215 Genève 15

Switzerland

Tel: +41 22 799 5640

Fax: +41 22 799 5641

E-mail: emea-i[email protected]

Asia-Pacific Headquarters

Brocade Communications Systems Co., Ltd. (Shenzhen WFOE)

Citic Plaza

No. 233 Tian He Road North

Unit 1308 – 13th Floor

Guangzhou, China

Tel: +8620 3891 2000

Fax: +8620 3891 2111

E-mail: [email protected]

Title Publication number Summary of changes Date

DCFM Migration Guide 53-1001776-01 New document. April 2010

DCFM Migration Guide 3 of 38

53-1001776-01

In this guide

•Professional, Professional Plus, and Enterprise edition feature support . . . . . . . . . . . . . . . . . . . . 3

•System requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

•Installing the application . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

•Professional edition migration. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

•Upgrading the application . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

•Professional Plus and Enterprise edition pre-migration requirements. . . . . . . . . . . . . . . . . . . . . 23

•Enterprise migration. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

•Syslog troubleshooting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

Professional, Professional Plus, and Enterprise edition feature support

Table 1 details whether the features are supported in the Professional, Professional Plus, or Enterprise edition, or

only through the Element Manager of the device.

TABLE 1 Features supported

Feature Description Professional

Edition

Professional

Plus Edition

Enterprise

Edition

Access Gateway Management Access Gateway topology display

Firmware download

SupportSave

Performance statistics

Configuration file management

Yes Yes Yes

Active Sessions Active sessions Yes Yes Yes

Call Home Support all Call centers

SupportSave for Fabric OS switches

Support last 100 events

No Yes Yes

Configuration Management Periodic configuration backup and persistence No Yes Yes

Manual backup

Save configuration

Yes Yes Yes

Configuration repository management No Yes Yes

Replicate switch configuration No Yes Yes

DCFM Client

Authentication

Authorization

Auditing

DCFM user management No Yes Yes

Encryption Layer 2 FC support Yes Yes Yes

Encryption configuration and monitoring No Yes Yes

Access Gateway – Cisco interop support No Yes Yes

Device decommissioning No Yes Yes

4 of 38 DCFM Migration Guide

53-1001776-01

Professional, Professional Plus, and Enterprise edition feature support

Fabric Binding Fabric Binding No Yes Yes

Fabric Watch All Fabric Watch features Element

Manager

Element

Manager

Element

Manager

Fault Management Show switch events

Show fabric events

Syslog forwarding

SNMP trap registration and forwarding

Yes Yes Yes

FCIP Management FCIP configuration wizard

Troubleshooting

IP performance

IP ping

IP traceroute

Yes Yes Yes

FICON/CUP Cascaded FICON configuration wizard No No Yes

Cascaded FICON Fabric merge wizard No No Yes

PDCM Matrix Element

Manager

Element

Manager

Yes

Firmware Management and

SupportSave

Firmware download Yes Yes Yes

Capture SupportSave Yes Yes Yes

HBA Management Discovery Yes Yes Yes

Configuration Yes Yes Yes

HBA Server/Storage port mapping HBA Server/Storage port mapping Yes Yes Yes

High Integrity Fabric High Integrity Fabric No Yes Yes

IPv6 Server - Client support

Server - Server support

Server - Switch support

Yes Yes Yes

Client - Server support

NOTE: Raw IPv6 is not supported for Client -

Server communication (Northbound

address) due to a JBOSS version

limitation.

No No No

iSCSI Discovery Discovery Yes Yes Yes

License New License Key No Yes Yes

Limited M-EOS fabric support Features that support M-EOS switches

Mixed fabric support

Pure fabric support

No Yes Yes

Meta-SAN Routing configuration No Yes Yes

Domain ID configuration No Yes Yes

M-EOS Element Manager Switch configuration for M-EOS switches

through Element Manager

No Yes Yes

TABLE 1 Features supported (Continued)

Feature Description Professional

Edition

Professional

Plus Edition

Enterprise

Edition

DCFM Migration Guide 5 of 38

53-1001776-01

Professional, Professional Plus, and Enterprise edition feature support

Migration Migration from legacy EFCM and Fabric

Manager

No No No

Name Server Collection and Views Yes Yes Yes

Open Trunking Support Display trunks on the topology Yes Yes Yes

Display trunks properties Yes Yes Yes

Display marching ants Yes Yes Yes

Display connections properties Yes Yes Yes

Performance management Real Time Performance

Collection

Display

Reports

(5-second intervals on selected ports)

Yes Yes Yes

Historical Performance

Collection

Display

Reports

(5-minute intervals on selected ports)

No Yes Yes

Thresholds No Yes Yes

Top talkers No Yes Yes

Marching ants No Yes Yes

Performance aging No Yes Yes

End-to-End monitors No Yes Yes

Port Administration All Port Administration features Element

Manager

Element

Manager

Element

Manager

Port Fencing Port Fencing policy configuration for M-EOS

switches

No Yes Yes

RBAC User management No Yes Yes

Reports Generate Yes Yes Yes

View Yes Yes Yes

Scalability Up to 1000 port support Yes Yes Yes

Up to 2560 port support No Yes Yes

Up to 9000 port support No No Yes

Security management Replicate switch policy configuration No Yes Yes

SNMP configuration Yes Yes Yes

TABLE 1 Features supported (Continued)

Feature Description Professional

Edition

Professional

Plus Edition

Enterprise

Edition

6 of 38 DCFM Migration Guide

53-1001776-01

Professional, Professional Plus, and Enterprise edition feature support

SMI Agent Server Profile

Fabric Profile

Indications

Zone Control

Enhanced Zoning

Enhanced Zoning Control

FDMI (Fabric Device Management Interface)

Profile

Virtual Fabrics Sub Profile

Topology View Sub Profile

FC HBA (Fibre Channel Host Bus Adapter) Sub

Profile

Fan, Power Supply, and Sensor

FC Routing (FCR)

Trunking

CP Blade

XISL (Extended ISL) Redundancy Set

CEE (Converged Enhanced Ethernet)

Launch In Context

No Yes Yes

Switch configuration management Basic configurations through Element Manager Element

Manager

Yes Yes

Switch port enable/disable Switch port enable/disable through right-click

Yes Yes Yes

Telnet Telnet

NOTE: Telnet through the server is only

supported on Windows systems.

Yes Yes Yes

Tool launcher Tool launcher (Setup tools) No Yes Yes

Troubleshooting and Diagnostics Device connectivity troubleshooting wizard Yes Yes Yes

Trace Route

Ping

Yes Yes Yes

Fabric device sharing No Yes Yes

Virtual Fabrics Discovery Yes Yes Yes

Configuration No Yes Yes

VM Plugin Support VM Plugin No Yes Yes

Zoning Member selection Yes Yes Yes

Zone editing Yes Yes Yes

Live fabric library scope Yes Yes Yes

QoS support Yes Yes Yes

Zone alias support Yes Yes Yes

Delete Zone database No Yes Yes

Impact analysis Yes Yes Yes

Remove offline devices No Yes Yes

TABLE 1 Features supported (Continued)

Feature Description Professional

Edition

Professional

Plus Edition

Enterprise

Edition

DCFM Migration Guide 7 of 38

53-1001776-01

System requirements

Use the following to determine if you have met the requirements for this application.

Operating system requirements

Table 2 summarizes the minimum recommended host requirements for running DCFM.

NOTE

The SMI Agent only edition uses the same requirements as the Enterprise edition.

TI Zones Yes Yes Yes

Device to Zone / zoneset participation analysis Yes Yes Yes

LSAN Zones No Yes Yes

Rolling back to an activated zone database No Yes Yes

Import or export a zone database No Yes Yes

TABLE 2 System requirements

Professional Professional

Plus

Enterprise

Operating

System

Version Installation

Type

Small Medium Large

Windows®2003 Server

2008 Server

Vista

7 Professional

Server plus

1 local

client

Intel Core2

duo 2 GHz or

equivalent

Intel Core2

duo 2 GHz or

equivalent

Intel Core2

duo 2 GHz or

equivalent

Intel Dual CPU

Core2 duo 2.4

GHz or

equivalent

Intel Dual CPU

Core2 duo 2.4

GHz or

equivalent

Remote

client only

N/A Intel Core2

duo 2 GHz or

equivalent

Intel Core2

duo 2 GHz or

equivalent

Intel Core2

duo 2 GHz or

equivalent

Intel Core2

duo 2 GHz or

equivalent

Linux®RedHat AS4

RedHat ES4

RedHat 5

RedHat 5 Advanced

Platform

SuSE ES10

Server plus

1 local

client

Intel Core2

duo 2 GHz or

equivalent

Intel Core2

duo 2 GHz or

equivalent

Intel Core2

duo 2 GHz or

equivalent

Intel Dual CPU

Core2 duo 2.4

GHz or

equivalent

Intel Dual CPU

Core2 duo 2.4

GHz or

equivalent

Remote

client only

N/A Intel Core2

duo 2 GHz or

equivalent

Intel Core2

duo 2 GHz or

equivalent

Intel Core2

duo 2 GHz or

equivalent

Intel Core2

duo 2 GHz or

equivalent

TABLE 1 Features supported (Continued)

Feature Description Professional

Edition

Professional

Plus Edition

Enterprise

Edition

8 of 38 DCFM Migration Guide

53-1001776-01

System requirements

Solaris Solaris 10 Server plus

1 local

client

Sun Fire/Sun

SPARC

Enterprise

T1000/T2000

Processor: 4

Core 1.0 GHz

UltraSPARC T1

or equivalent

Sun SPARC

Enterprise

T5xxx (T5120,

T5140, T5220,

T5240,

T5440)

Processor: 4

Core 1.2 GHz

UltraSPARC T2

or T2 Plus or

equivalent

Sun SPARC

Enterprise

T5xxx (T5120,

T5140, T5220,

T5240,

T5440)

Processor: 4

Core 1.2 GHz

UltraSPARC T2

or T2 Plus or

equivalent

Sun SPARC

Enterprise

T5xxx (T5120,

T5140, T5220,

T5240,

T5440)

Processor:

4/6/8 Core

1.4 GHz

UltraSPARC T2

or T2 Plus or

equivalent

Sun SPARC

Enterprise

T5xxx (T5120,

T5140, T5220,

T5240,

T5440)

Processor:

4/6/8 Core

1.4 GHz

UltraSPARC T2

or T2 Plus or

equivalent

Remote

client only

N/A Sun Fire/Sun

SPARC

Enterprise

T1000/T2000

Processor: 4

Core 1.0 GHz

UltraSPARC T1

or equivalent

Sun Fire/Sun

SPARC

Enterprise

T1000/T2000

Processor: 4

Core 1.0 GHz

UltraSPARC T1

or equivalent

Sun Fire/Sun

SPARC

Enterprise

T1000/T2000

Processor: 4

Core 1.0 GHz

UltraSPARC T1

or equivalent

Sun Fire/Sun

SPARC

Enterprise

T1000/T2000

Processor: 4

Core 1.0 GHz

UltraSPARC T1

or equivalent

VMware®ESX Server 3.5

vSphere 4.0

Guest OSs

supported:

•Windows

2003 Server

2008 Server

Vista

7 Professional

•Linux

RedHat AS5

RedHat ES4

SuSE ES10

Server /

Client

Requirements

for the

supported

guest OSs

(listed in the

Version

column) are

the same as

detailed

above.

Requirements

for the

supported

guest OSs

(listed in the

Version

column) are

the same as

detailed

above.

Requirements

for the

supported

guest OSs

(listed in the

Version

column) are

the same as

detailed

above.

Requirements

for the

supported

guest OSs

(listed in the

Version

column) are

the same as

detailed

above.

Requirements

for the

supported

guest OSs

(listed in the

Version

column) are

the same as

detailed

above.

TABLE 2 System requirements (Continued)

Professional Professional

Plus

Enterprise

Operating

System

Version Installation

Type

Small Medium Large

DCFM Migration Guide 9 of 38

53-1001776-01

System requirements

Memory requirements

Table 3 summarizes the minimum recommended system memory requirements for running DCFM plus SMI Agent

on Windows, Linux, and Solaris systems. Table 4 summarizes the minimum recommended system memory

requirements for running SMI Agent only on Windows, Linux, and Solaris systems.

NOTE

These requirements are only applicable when no other applications are running on DCFM.

NOTE

Paging space should be equal to or exceed the physical memory size.

Disc space requirements

Table 5 summarizes the minimum recommended disk space requirements for running DCFM on Windows, Linux,

and Solaris systems.

NOTE

The SMI Agent only edition uses the same requirements as the Enterprise edition.

NOTE

If you enable periodic supportSave or configure the DCFM server as the Upload Failure Data Capture location for

monitored switches, then additional disk space will be required. Each switch supportSave file is approximately 5 MB

and each Upload Failure Data Capture file is approximately 500 KB. To determine the disk space requirements,

multiply the frequency of scheduled supportSave files by 5 MB and the expected Upload Failure Data Capture files by

500 KB before the planned periodic purge activity.

TABLE 3 DCFM plus SMI Agent Memory requirements

Server/Client Professional Professional Plus Enterprise

Small Medium Large

Server plus 1 local client 2 GB 3 GB 3 GB 4 GB 4 GB

Remote client only N/A 1 GB 1 GB 2 GB 2 GB

TABLE 4 SMI Agent only Memory requirements

Server/Client Enterprise

Small Medium Large

Server plus 1 local client 3 GB 4 GB 4 GB

TABLE 5 Disk space requirements

Server/Client Professional Professional Plus Enterprise

Small Medium Large

Server plus 1 local client 2.5 GB 5 GB 7 GB 7 GB 40 GB

Remote client only N/A 500 MB 500 MB 1 GB 2 GB

10 of 38 DCFM Migration Guide

53-1001776-01

System requirements

Browser requirements

The launch of DCFM and the launch of Element Manager (Web Tools) from the application are supported from the

following browsers with a Java plug-in:

•Browsers

-Windows Internet Explorer under Windows

-Firefox under Windows, Solaris, or Linux

•Java Plug-ins

-1.6.0_16 for DCFM

-1.5.0_06 (S) and 1.6.0_16 (FT) for WebTools

Client and Server system requirements

DCFM has the following client and server system requirements:

•Professional Edition — A single server supports a single client (local client only).

•Professional Plus Trial — A single server supports a maximum of 9 clients (local or remote).

•Professional Plus Edition — A single server supports a maximum of 9 clients (local or remote).

•Enterprise Trial — A single server supports a maximum of 9 clients (local or remote).

•Enterprise Edition — A single server supports a maximum of 9 clients (local or remote).

Scalability requirements

Table 6 through Table 9 summarize the scalability limits for support with DCFM.

TABLE 6 Enterprise-supported limits by SAN size for pure Fabric OS fabrics

Small Medium Large

Number of Fabrics 81624

Number of Domains 20 60 120

Number of Switch Ports 2000 5000 9000

Number of Device Ports 5000 10000 20000

Number of Access Gateways 20 30 40

Performance Monitoring Polling 5 minutes 5 minutes 5 minutes

Altri manuali per 1606

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali Brocade Communications Systems Magazzinaggio
