BRONDI AMICO COLOR Manuale utente
AMICO COLOR
Instruction manual- English
1
1. INTRODUCTIONS
1.1 INFORMATIONS :
Thanks for choosing AMICO COLOR digital mobile phone.
With this user manual, you can understand the operation of
the mobile phone and enjoy its perfect function and simple
operation.
AMICO COLOR mobile phone is designed for GSM/GPRS
network. This AMICO COLOR mobile phone accords with
GSM/GPRS technical specification and is approved by
domestic and international authoritative organizations.
2
Keys Location:
2. BEFORE USING
2.1 Keys description:
1 Charging
Interface
7 Left key 13 Up key
2 Earpiece 8 Down
key
14 End/
Power key
3 USB 9 Keypad 15 Right key
4 Side UP
button
10 MIC 16 SOS key
12
13
14
15
18
16
17
10 3
111
2
4
5
6
7
8
9
3
Numeric keys
5 Side DW
button
11 Flashlig
ht
17 Flashlight
button
6 Send key 12 LCD
screen
18 Battery
cover
Keys Description
Navigation
keys
UP navigation: press the Up navigation
key to move up.
DOWN navigation: press the Down
navigation key to move down
Right key
Carry out the function indicated by the
directing symbol at
the bottom right corner
of the screen.
Left
key
Carry out the function indicated by the
directing symbol at the bottom left corner
of the screen.
Dial key Make and answer calls; order out call log
in idle screen.
END/Power
key
End or refuse a call. Power on/off. Return
to standby mode from other modes.
4
Number key
Enter numbers and characters. 1-9
number keys can be set as one-
touch dial
keys.
*key
Enter specific symbols, Chinese
punctuation, symbol *, P and W. It usual
as volume key.
#key
Press ＃
＃＃
＃key to switch input methods.
Hold this key long time to switch between
mute mode and normal mode. It usual as
volume key to match with star key.
Side key
Press side key to move up/down, some
special screen use
them to move left/right.
For example in phone setting date and
time screen.
SOS key
Long press the SOS key to use
emergency function.(some phones have
this function).
2.2 Battery
The battery in original state has about 50% electricity
quantity and you can use it after unpacking. It performs best
after full charge/discharge for the first three times.
2.3 Removing & Installing the Battery
Remove: Press and push at the head side of the
5
handset to open the battery cover, then lift up the
battery to remove.
Install: Insert the battery, push the battery cover until
you hear “click”
2.4 Charging the battery
Connect the power supply of charger.
Plug the charger connector into the charge port at the top
side of the phone.
Charge indicator displays on the screen and flickers
during the charging process. If the battery is charged in
power-off condition, the screen will display charging
indicator to tell the phone is charging. If the phone is
over-used in shortage of battery, the screen may not
display the charge indicator immediately but after a while.
When the battery level indicator changes from charging
symbol to full level indicator and stops flickering, it means
charge has been finished. If the battery is charged in
power off condition, a charging-stop animation indicates
the charge has been finished. Generally the whole
charge process needs 3~4 hours. During the charge
process, your phone and charger may become hot, and
this is a normal phenomenon.
2.5 Usage of USB
Insert the USB cable in power on mode:
6
Plug in the USB cable in power on mode and the menu will
be popped out.
Mass Storage: it can still be in power on status and be
used as a U-disk, while it has the function of USB
charging.
Insert the USB cable in power off mode:
To use it as a U-disk, while it has the function of USB
charging.
COM Port: it can be used as a modem or USB
charging function.
2.6 Connecting to the network
2.6.1 SIM card
Please insert a valid SIM card (user Identification card) into
the phone before using it. SIM card is the key for you to
enter digital GSM network. Inside the battery compartment
you can see SIM card slot then insert your SIM card.
2.6.2 Inserting/removing SIM card
The SIM card is usually stored in a card and you need to
take it out carefully before installing.
Turn off the mobile phone, remove battery and external
power supply. Insert the SIM card into the slot or pull out
the SIM card from the slot.
7
2.6.3 Switching on/off your phone
Press and hold the END/Power key to switch on/off the
mobile phone.
2.6.4 Unlocking the SIM card
By setting PIN 1 (personal Identification number) code of
SIM card and handset lock code, you can protect your SIM
card and phone from illegal use. When this function is put in
use, you have to enter PIN1 code each time you power on
your phone. To unlock the SIM card before you dial or
receive calls. You may cancel the SIM card protection, in
this case the SIM card will be unable to prevent illegal use.
Press the END/Power key to power on the phone.
Enter PIN1code use Right key to clear the incorrect input.
If you enter a wrong PIN1 code for three times in a row,
your SIM card will be locked by the network and the
phone will ask for PUK 1 code. If you don’t know the
PUK1 code, do not enter any code and send your SIM
card to the operator.
2.6.5 Connecting to network
The mobile phone will search for network automatically after
the SIM card is decrypted successfully (display “Searching
for network” on the screen). The name of network operator
will appear in the standby state of the phone once get
8
connected.
2.6.6 Making calls
When the operator symbol of the network appears in the
screen, you can make or answer calls. The manifestation in
the top left hand corner of the screen shows the signal
strength of the network.
2.6.7 Making DDD (Direct Distance Dialing)
To dial: Area Code + Phone number + Send key
2.6.8 Making IDD
To dial: (+)Country Code + Complete phone number +
Send key
2.6.9 Dial the number in the Phonebook list
Your mobile phone listed all the numbers so that you can
view all the call logs. When the list is full, old numbers will be
deleted automatically. You can check the list by the following
operations:
Press Dial key to view the “Call history”, and then you
can press the Send key to view “options”.
All the numbers in the history list can be dialed
directly by pressing the Dial key.
9
2.6.10 Emergency call
If you are within the network coverage area (It can be
checked by the network signal strength displayed in the
upper left corner of the screen), you are entitled to make
emergency calls. If your network provider doesn’t supply
roaming service in the area, the screen will display
“EMERGENCY”, which means only emergency calls are
available. If you are within the network covering area,
emergency calls can be made even without SIM card.
2.6.11 Answering calls
if any key answer is set On, you can press any key to
answer a call in call-in mode, otherwise you need to press
Send key to select “Answer” to answer a call.
2.6.12 Call history
Your mobile phone can store the latest call record and the
total talk time since the phone is used (see Chapter “Call
history”).
3. MENU INSTRUCTION
3.1 Using Menu instruction
The following context lists out the brief explanations to each
function that this phone offers.
3.2 Phonebook
This function allows you to browse the telephone records in
