Start Here

Quick Setup Guide

USA/CAN Version 0

DCP-J152W

Thank you for choosing Brother, your support is important to us and we value your business. Your Brother product

is engineered and manufactured to the highest standards to deliver reliable performance, day-in and day-out.

Please read the Product Safety Guide first before you set up your machine. Then, please read this Quick Setup

Guide for the correct setup and installation.

Manuals in Spanish for this model are available on the enclosed CD-ROM.

Manuales en Español para este modelo están disponibles en el CD-ROM incluido.

Unpack the machine and check the components

The components included in the box may differ depending on your country.

* If your computer does not have a CD-ROM drive, the supplied CD-ROM does not contain drivers for your

operating system, or you want to download manuals and utilities, visit your model page at

http://solutions.brother.com/.

WARNING

Plastic bags are used in the packing of your machine. Plastic bags are not toys. To avoid the danger

of suffocation, keep these bags away from babies and children and dispose of them correctly.

WARNING WARNING indicates a potentially hazardous situation which, if not avoided, could result in death

or serious injuries.

CAUTION CAUTION indicates a potentially hazardous situation which, if not avoided, may result in minor

or moderate injuries.

IMPORTANT IMPORTANT indicates a potentially hazardous situation which, if not avoided, may result in

damage to property or loss of product functionality.

NOTE Notes tell you how to respond to a situation that may arise or give tips about how the operation

works with other features.

Starter Ink

Cartridges

Black

Yellow

Cyan

Magenta

Quick Setup Guide

Basic User’s Guide Product Safety Guide CD-ROM*

NOTE

Save all packing materials and the box in case for any reason you must ship your machine.

USB cable

You need to purchase the correct USB cable.

We recommend using a USB 2.0 cable (Type A/B) that is no more than six feet (two meters) long.

aRemove the protective tape and film covering

the machine, and also from the LCD.

Remove

the plastic bag acontaining the ink

cartridges from on top of the paper tray.

cMake sure you have all the components.

Connect the power cord

aConnect the power cord.

Install the ink cartridges

CAUTION

If ink gets in your eyes, wash it out with water at

once and call a doctor if you are concerned.

aMake sure that the power is turned on.

The LCD will show No Ink Cartridge.

bOpen the ink cartridge cover a.

cRemove the orange protective part a.

NOTE

DO NOT connect the USB cable yet (if you are

using a USB cable).

NOTE

• The Warning LED on the control panel will stay

on until you have installed the ink cartridges.

• To prolong the life of the print head, provide the

best ink cartridge economy and maintain print

quality, we do not recommend unplugging the

machine frequently and/or leaving the machine

unplugged for extended periods of time. Each

time you plug the machine in, it automatically

cleans the print head, which uses some of your

ink.

We recommend using to power down the

machine. Using allows minimal power to

the machine, resulting in periodic, but less

frequent, cleaning of the print head.

NOTE

Make sure you install the Starter Ink Cartridges

included with your machine first.

NOTE

Do not throw away the orange protective part.

You will need it if you transport the machine.

dUnpack the ink cartridge.

Turn the green release lever on the orange

protective packing acounterclockwise until it

clicks to release the vacuum seal. Then

remove the orange protective packing aas

shown.

eTake care to match the sticker color awith the

cartridge color bas shown in the diagram

below.

Install each ink cartridge in the direction of the

arrow on the label.

fGently push the back of the ink cartridge

marked “PUSH” until it latches. After all the ink

cartridges are installed, close the ink cartridge

cover.

IMPORTANT

• DO NOT shake the ink cartridges. If ink stains

your skin or clothing, wash with soap or

detergent at once.

• DO NOT touch the cartridge in the area

indicated b, as this can cause the machine not

to function with the cartridge.

NOTE

The machine will prepare the ink tube system for

printing. This process will take approximately four

minutes. Do not turn off the machine. We

recommend you perform the next step while

waiting.

Load plain Letter/A4

paper

aPull the paper tray acompletely out of the

machine.

bOpen the output paper tray cover a.

IMPORTANT

• DO NOT take out ink cartridges if you do not

need to replace them. If you do so, it may

reduce the ink quantity and the machine will not

know the quantity of ink left in the cartridge.

• DO NOT repeatedly insert and remove the

cartridges. If you do so, ink may seep out of the

cartridge.

• Once you open an ink cartridge, install it in the

machine and use it up within six months of

installation. Use unopened ink cartridges by

the expiration date written on the cartridge

package.

• DO NOT dismantle or tamper with the ink

cartridge, this can cause the ink to leak out of

the cartridge.

• Brother strongly recommends that you do not

refill the ink cartridges provided with your

machine. We also strongly recommend that

you continue to use only Genuine Brother

Brand replacement ink cartridges. Use or

attempted use of potentially incompatible ink

and/or cartridges in the Brother machine may

cause damage to the machine and/or may

result in unsatisfactory print quality. Our

warranty coverage does not apply to any

problem that is caused by the use of

unauthorized third party ink and/or cartridges.

To protect your investment and obtain premium

performance from the Brother machine, we

strongly recommend the use of Genuine

Brother Supplies.

NOTE

Make sure the first printed page is Letter/A4 size.

cGently press and slide the paper width

guides aand then the paper length guide bto

fit the paper size.

Make sure that the triangular marks con the

paper width guides aand paper length

guide bline up with the mark for the paper size

you are using.

dFan the stack of paper well to avoid paper jams

and misfeeds.

eGently put the paper into the paper tray print

side down and top edge first. Check that the

paper is flat in the tray.

NOTE

Always make sure that the paper is not curled or

wrinkled.

IMPORTANT

Be careful that you do not push the paper in too

far; it may lift at the back of the tray and cause

paper feed problems.

NOTE

When you use Legal size paper, press and hold

the universal guide release button aas you slide

out the front of the paper tray.

fGently adjust the paper width guides to the

paper with both hands. Make sure that the

paper width guides touch the edges of the

paper.

gClose the output paper tray cover.

hSlowly push the paper tray completely into the

machine.

iWhile holding the paper tray in place, pull out

the paper support auntil it clicks, and then

unfold the paper support flap b.

Check the print quality

aWhen the preparation process has finished, the

LCD shows Load Paper and Press Color

Start.

Press Color Start.

bCheck the quality of the four color blocks on the

sheet. (black/yellow/cyan/magenta)

cIf all lines are clear and visible, press +(Yes) to

finish the quality check and go to the next step.

If lines are missing, press -(No) and follow the

steps on the LCD.

Poor

Set the date and time

The LCD displays the date and time. In addition,

setting the date and time allows the machine to clean

the print head regularly and maintain optimum print

quality.

aTo enter the last two digits of the year, press a,

b, dor cto select the first number, and then

press OK. Repeat for the second number.

To save the two-digit year, press a, b, dor cto

select , and then press OK.

bEnter the two-digit month. Select and

press OK to save.

cEnter the two-digit day. Select and press

OK to save.

dPress aor bto choose 12h Clock or 24h

Clock, and then press OK.

eEnter the time. Select and press OK to

save.

fFor 12h Clock only:

Press aor bto choose AM or PM, and then

press OK.

Wireless setup

(if needed)

When the Wi-Fi setup will start. message

appears on the LCD, read the message, and then

press OK to continue.

For wireless setup using a mobile device, go to a.

For Windows®and Macintosh users, go to b.

aPress aor bto choose Yes.

Press OK.

Go to step 10 on page 15 to continue with the

wireless setup.

bPress aor bto choose No.

Press OK.

Wireless setup instructions for Windows®and

Macintosh users will be covered later, starting

on page 15.

(e.g. Enter 13for 2013.)

123

456

789

Year:2013

NOTE

You can change date, time, or clock type (12h or

24h) at any time. For more information, see

Setting the date and time in the Basic User’s

Guide.

NOTE

If a prompt message appears on the LCD, read it

and press OK to continue.

Choose your language

(if needed)

aPress Menu.

bPress aor bto choose Initial Setup.

Press OK.

cPress aor bto choose Local Language.

Press OK.

dPress aor bto choose your language.

Press OK.

ePress Stop/Exit.

Windows®Macintosh

USB Wireless Network

Choose your connection type

These installation instructions are for Windows®XP Home, XP Professional, XP Professional x64 Edition,

Windows Vista®, Windows®7, Windows®8, and Mac OS X v10.6.8, 10.7.x, 10.8.x.

NOTE

If your computer does not have a CD-ROM drive, the supplied CD-ROM does not contain drivers for your

operating system, or you want to download manuals and utilities, visit your model page at

http://solutions.brother.com/. Some software applications included on the CD-ROM may not be available as a

download.

For USB interface cable

Windows

, go to page 10

Macintosh, go to page 13

For Wireless Network

Windows

and Macintosh,

go to page 15

Windows®

USB

For Windows

USB interface users

(Windows®XP Home/XP Professional/Windows Vista®/Windows®7/Windows®8)

Before you install

Make sure that your computer is ON and you are

logged on with Administrator rights.

Install MFL-Pro Suite

aPut the CD-ROM into your CD-ROM drive. If

the model name screen appears, choose your

machine. If the language screen appears,

choose your language.

bClick Install MFL-Pro Suite and click Yes if

you accept the license agreements.

cChoose Local Connection (USB), and then

click Next.

dFollow the on-screen instructions until the Plug

in the USB cable screen appears.

NOTE

• DO NOT connect the USB cable yet.

• If there are any programs running, close them.

• The screens may differ depending on your

operating system.

• If the Windows Security screen appears, click

the check box and click Install to complete the

installation correctly.

NOTE

• If the Brother screen does not appear

automatically, go to Computer (My

Computer).

(For Windows®8: click the (File Explorer)

icon on the taskbar, and then go to Computer.)

Double-click the CD-ROM icon, and then

double-click start.exe.

• If the User Account Control screen appears,

click Allow or Yes.

Altri manuali per DCP-J152W

Indice

Altri manuali Brother Stampante tutto in uno

Brother

Brother MFC 5490CN - Color Inkjet - All-in-One Manuale utente

Brother

Brother MFC-9440CN Manuale utente

Brother

Brother DCP-8110DN Manuale operativo e di manutenzione

Brother

Brother MFC 255CW - Color Inkjet - All-in-One Guida rapida

Brother

Brother MFC 640CW - Color Inkjet - All-in-One Manuale utente

Brother

Brother DCP-7060D Manuale utente

Brother

Brother DCP-585CW Manuale utente

Brother

Brother MFC-J815DW Manuale tecnico

Brother

Brother MFC-J4410DW Guida utente

Brother

Brother DCP 330C - Color Inkjet - All-in-One Manuale utente

Brother

Brother MFC-9460CDN Guida di sicurezza

Brother

Brother MFC-J4310DW Manuale utente

Brother

Brother DCP-9270CDN Manuale utente

Brother

Brother MFC-9460CDN Manuale utente

Brother

Brother MFC-9340CDW Manuale

Brother

Brother MFC-8670DN Manuale utente

Brother

Brother MFC-8510DN Istruzioni per il montaggio

Brother

Brother MFC-J220 Manuale operativo e di manutenzione

Brother

Brother MFC-8510DN Manuale operativo e di manutenzione

Brother

Brother DCP-J172W Istruzioni per il montaggio

Brother

Brother MFC-J615 Manuale utente

Brother

Brother MFC-L8650CDW Manuale operativo e di manutenzione

Brother

Brother MFC-J6520DW Manuale operativo e di manutenzione

Brother

Brother DCP-L8400CDN Manuale operativo e di manutenzione

Manuali Stampante tutto in uno popolari di altre marche

Triumph Adler

Triumph Adler DC 2016 Manuale

Epson

Epson WorkForce WF-2510 Guida utente

Epson

Epson Stylus Scan 2000 Manuale di installazione e funzionamento

Epson

Epson PictureMate Snap PM 240 Manuale di istruzioni

Konica Minolta

Konica Minolta bizhub C35 Manuale utente

Konica Minolta

Konica Minolta BIZHUB 558 Manuale utente

Lexmark

Lexmark MX710 Series Manuale

Lexmark

Lexmark XC8155 Manuale utente

Lexmark

Lexmark X642E Manuale utente

Sharp

Sharp MX-2310U Guida

Aficio

Aficio 200 Manuale utente

Canon

Canon ImageCLASS 2300 Manuale

Ricoh

Ricoh Pro C900 Manuale utente

Lexmark

Lexmark X925 Manuale utente

Epson

Epson Stylus CX8400 Series Manuale utente

Oce

Oce VarioLink 5022 Manuale utente

Copystar

Copystar CS 4551ci Manuale utente

Konica Minolta

Konica Minolta Magicolor 4650EN Manuale utente
