Indicates which visitor list is displayed.

Reserved or Pre-registered:

Visitors that have their

information entered prior to arrival (reservation made).

Signed in: Visitors that have already signed in.

Signed out: Visitors that are signed out.

Click to select a visitor list.

Displays the selected visitor list.

Sort the list by clicking a column title. Change

column width by dragging column borderline.

Search for information within the displayed visitor list.

Click or to search up or down the list.

Prints the Emergency Report.

Prints a visitor badge, signs a visitor in or signs a

visitor out.

Function depends on visitor list being viewed.

New: Enter information for a new visitor.

Delete: Delete the information for the selected visitor.

Reserve: Enter information for a new visitor and

store to the [Reserved] list.

Overwrite: Edit the information by typing over the

displayed visitor information.

Displays a photo of the visitor.

Click to take a photo of the visitor (requires

installation of camera).

Enter the visitor information.

* indicates information that MUST be filled in.

Enter the host information (The host is the person

the visitor is visiting).

* indicates information that MUST be filled in.

Click to search the host database to fill in the

host information.

Preview: View the visitor badge before printing.

Print Badge: Prints the visitor badge.

Print Parking Permit: Prints the parking permit.

When visitor arrives: Type the visitor information. If a reservation was previously entered for the visitor,

select the visitor from the [Reserved]/[Pre-registered] list. Click the button to sign the

visitor in and print the visitor badge.

To print badge prior to visitor's arrival, select the visitor from the [Reserved]/[Pre-registered] list and click the

button. When visitor arrives, select the visitor badge ID from the list and click the button (

When visitor leaves: To sign out visitors, select the visitor information from the [Signed in] list and click

the button (J).

Visitor Badge & Management

Quick Reference Guide

Click . Type your [User Name] and

[Password]. Click the

button.

Click the

button to display or print the

report.

Self Check-in mode

Reception mode

Emergency Reports

Replacing the DK Paper Roll (Re-order No. DK-N5224)

Remove the empty spool by

lifting up and out of the machine.

Press and hold the ON/OFF

button to turn off the machine.

Firmly hold the front of the

machine and lift open the DK

Roll compartment cover.

Put the new spool into the spool

guides of the DK Roll compartment.

Close the DK Roll Compartment cover and press the

ON/OFF button to turn the machine ON. Press the FEED

and CUT buttons (if necessary) to properly align paper.

Thread the end of the DK Paper

Roll all the way through the slot

as shown in the illustration.

In case of an emergency, click the button.

The list of visitors who have signed in can be printed or displayed.

Emergency reports are not printed on your Brother QL Label Printer. Emergency reports are printed

on the default printer which is assigned by the Administrator. We recommend assigning a default

printer that prints to letter size paper.

Printed in China LB8155001
