BT PAPERJET 60 Manuale utente
PaperJet 60 user guide – Edition 3 – 29.8.00
PaperJet 60
Plain paper fax, copier, telephone and digital answering machine
User Guide
This product is intended for connection to analogue telephone networks in the nited Kingdom.
This product has not been designed for making emergency telephone calls when the power fails.
Alternative arrangements should be made for access to emergency services.
Please open this page for an ‘at a glance’
guide to your PaperJet 60.
Please open this page for a ‘further at
a glance’ guide to your PaperJet 60.
At a glance
PaperJet 60 user guide – Edition 3 – 29.8.00
2
Document outlet
Outlet for received faxes, copied
documents and originals.
Display screen
Control panel
Document feeder
width guides
Adjust to fit the width
of your document for A4,
Letter and Legal sizes.
Document feeder
Holds up to 5 sheets placed face
down for faxing or copying.
Paper feeder width guide
Adjust to fit the width of your
paper for A4, Letter and Legal
sizes.
Plain paper sheet feeder
Max. capacity 40 sheets of
80gsm paper.
Paper support
Handset
Mains power socket
Telephone line socket
Cover
Open the cover
for changing the
print cartridge
and clearing
document jams
Loudspeaker
Error
Delete
Memo
Messages
123
456
789
0
TD Play Half Tones
F
R
䊴䊳
I䊴䊴
䊳䊳I
䊳/II
PaperJet 60
Stop
Monitor
Start
Function
Recall
RX Mode Resolution Contrast
Speed Dial Last TX E ternal
Clear Pause
Volume
Copy
W
X
Y
Z
T
U
V
P
Q
R
M
N
O
J
K
L
G
H
I
D
E
F
A
B
C
&...
Error
Delete
Memo
Messages
123
456
789
0
TD Play Half Tones
F
R
䊴䊳
I䊴䊴
䊳䊳I
䊳/II
PaperJet 60
Stop
Monitor
Start
Function
Recall
RX Mode Resolution Contrast
Speed Dial Last TX E ternal
Clear Pause
Volume
Copy
W
X
Y
Z
T
U
V
P
Q
R
M
N
O
J
K
L
G
H
I
D
E
F
A
B
C
&...
PaperJet 60 user guide – Edition 3 – 29.8.00
3
Reduction/Enlargement button. Reduces and
enlarges copies to either 70% or 140%.
Resolution button. Allows you to choose text or
photo resolution for copies.
Contrast button. Adjusts the contrast of
documents to be copied.
Copy button. Press to start copying a document.
Error light. Indicates a problem when sending or
receiving a fax.
top button. Stops the current operation.
Returns the fax machine to standby.
Monitor button. Press to get dialling tone.
tart button. Press to send a fax. Confirms an
option chosen from the menu. During a call, press
to receive a fax.
Function button. Function button lets you select
options from the menus.
RX Mode/Hold button. Selects reception
methods for faxes. When on a phone call, press to
put a caller on hold. They hear a beep.
Resolution/Volume – button. Adjust the
resolution of documents to be faxed. Select next
option from a menu.
Decrease loudspeaker volume
Contrast/Volume + button. Adjust the contrast
of documents to be faxed. Select previous option
from a menu.
Increase loudspeaker volume
Recall button.
peed Dial/Clear button. Used to speed dial a
stored number. Deletes incorrect settings and
characters.
Last Number/Pause button. Press once to
display last number dialled. If you have a
document in the ADF it shows the last fax
number, if not it shows the last telephone number
called. Press again to dial the number
displayed.When dialling or storing a number,
press to enter a pause.
External button. Connects you to an outside line
when connected to a switchboard.
PaperJet 60 user guide – Edition 3 – 29.8.00
4
Print head holder
Optical scanner
PaperJet 60 user guide – Edition 3 – 29.8.00
5
Key features
Plain paper fax
Holds up to 40 sheets of A4 paper for ink
jet quality printing.
21 page memor
If you run out of ink or paper while
receiving a fax the document will be stored
in the memory and automatically printed out when
the new paper or ink has been added.
Copier with zoom
Make single or multiple copies of
documents. Enlarge copies to 140% or
reduce to 70%
One touch and speed dial memories
10 one touch memories and 31 speed dial
memories can each store a fax number,
phone number and name. Easy to display and scroll
through the memories.
PaperJet 60 user guide – Edition 3 – 29.8.00
6
In this guide
At a glance 2
Introduction 7
Safety information 8
Setting up 9
Using your PaperJet 60 15
Sending faxes 15
To broadcast a document 19
Using the one-touch memories 21
Using the speed-dia memories 22
Reports and ists 24
Making and receiving phone ca s 26
Copying documents 28
Using the answering machine 29
Recording capacity 33
Remote access 36
Additional features 38
Po ing 42
Ca er Disp ay 45
Ca Sign (Distinctive ringing) 46
Connecting to a switchboard 47
Help 49
Maintenance 54
Technical information 59
Inde 61
PaperJet 60 user guide – Edition 3 – 29.8.00
7
Introduction
Unpacking your PaperJet 60
When you unpack you should have:
PaperJet 60 with attached
mains power cable and
fitted 3-pin plug.
Telephone line cord
Starter print cartridge
Handset with cord
Paper support
Document holders for use
with torn, thin or small pages
For your records
Date of purchase:
Place of purchase:
Serial number (on base of unit):
Proof of purchase is required for warranty purposes,
so please keep your receipt.
Never put foreign bodies into the fax machine.
Their accidental contact with powered parts may
cause a fire or electric shocks.
Do not expose to direct sunlight.
Do not stand your fax machine on carpets or other
surfaces which generate fibres, or place it in
locations preventing free flow of air over its surfaces.
Do not submerge any part of your fax
machine in water and do not use it in damp
or humid conditions such as bathrooms.
Do not expose your fax machine to fire,
explosive or other hazardous conditions.
There is a slight chance that your fax
machine could be damaged by an electrical
storm. We recommend that you unplug the
power and telephone line cord for the duration of
the storm.
PaperJet 60 user guide – Edition 3 – 29.8.00
8
Safety information
