Bubble Magus C3.5 Manuale utente



ProteinSkimmerUserManual(compiledbySeaSideAquatics)



Product’sName:InternalProteinSkimmerC3.5

ValidAquarium:80gal

Pumpmodel:ROCKSP1000



TheBubbleMagusC3.5isthesuccessorofNAC3.5.ThenewerC3.5offersthe

ROCKSP1000,replacingtheNAC3.5’sATMANPH1100.Pleasereadthemanualcarefully

beforeuse.Ifyouencounteranissue,whetheritisinthepackaging,duringyourinstallation,or

duringnormaloperationofyourproduct,contact[email protected]forfurther

support.Besuretoregisteryourproducttoactivateyourwarranty.



PackagingOverview:collectioncup,skimmerbody,basesupport,waterdrainingsystem,

venturiwithtubing,waterpump,andusermanual.



PartsList:

1.

Lid

10.

WaterTubeGasket

2.

CollectionCup

11.

WaterPump

3.

DrainTube/Outlet

12.

PumpOutlet

4.

SkimmerBody

13.

Venturi(airintake)

5.

RiserBracket

14.

AirIntakeTube

6.

BasePlates(2)

15.

ORing:CupOutlet

7.

NylonScrew(4)

16.

ORing:PumpOutlet

8.

WaterOutputAdjustmentTube

17.

ORing:WaterOutputTube

9.

TConnector



**Note:partsmaycomepreassembled.



Installation:

1. Connecttheventuritothewaterpump(sometimesthisunitisalreadypreassembled). 

2. Connectthewaterpumpoutlettotheskimmerbody.

3. Connecttheairintaketubetotheventuri.

4. Connectthecollectioncuptotheskimmerbody.Makesurethatthecupoutlet(atthe

bottom)hasarubberoringbeforeinsertingitintotheneckoftheskimmerbody.

5. Connectthedraintubetocup’soutlet.



6. Aftercompleteassembly,theunitisreadyforuse. 

a. Submergetheunitwithwater

b. Connectpowercordtoanelectricsocket(GFIcertifiedoutlet).

c. Makeyouradjustmentsusingtheadjustmenttube.



Maintenance:

1. Servicethecollectioncupandtheneckregularly.

2. Disassembleandcleantheventuriandpumpevery3to6months.

a. Disassemble,inspect,andcleantheimpellertomaximizelifeandperformance.

3. Acompleteskimmercleaningisrecommendedevery6to12months.

4. Avoidusingharshcleaningchemicalsandsoaps.A50/50vinegarbathis

recommended.



FurtherComments:

1. Donotrunthepumpdry.Makesurethatitissubmergedalreadybeforeoperation.

2. Aftersuccessfulinstallation,bubbleswillappearwhenthepumpisactive.Otherwise,

restartthesystem.IftheproblempersistthencontactSeaSideAquaticsforsupport.

3. Newskimmersmayrequireabreakinperiodofafewdaysormore.

4. Suggestedexternalwaterlevelis2025cm. 

5. Eachunithasbeenpretestedatthefactorytoensurethattheunitisinworkingorder.

Sometracesofwaterisnormal;theunitandallofitscomponentsarenew. 


