Buffalo TeraStation Pro WSS Manuale utente

User Manual

www.buffaloamericas.com

TeraStation Pro WSS

English

35020058-04

2015.07

TeraStation Pro WSS User Manual 1

Contents

Chapter 1 Opening Windows Storage Server ...................................3

Opening Windows Storage Server.................................................................................3

Chapter 2 Windows Update................................................................4

Windows Update..................................................................................................................4

Chapter 3 Software..............................................................................5

RAID Builder............................................................................................................................5

Email Notication.................................................................................................................5

Backup & Replication ..........................................................................................................6

Display Settings.....................................................................................................................6

Bualo Dashboard ...............................................................................................................7

Chapter 4 Managing Your Storage ....................................................9

Volume Types ........................................................................................................................9

Deleting Volumes.................................................................................................................10

Formatting Volumes............................................................................................................11

Creating a RAID 5 Volume.................................................................................................12

Creating a Mirrored Volume (RAID 1)............................................................................13

Creating a Striped Volume (RAID 0)...............................................................................14

Creating a Spanned Volumes...........................................................................................15

Creating a Simple Volumes (JBOD)................................................................................16

Chapter 5 Backup ................................................................................18

Back Up from the TeraStation..........................................................................................19

Replication ..............................................................................................................................23

Back Up from your Windows PC .....................................................................................25

TeraStation Pro WSS User Manual 2

Chapter 6 Creating an iSCSI Target....................................................26

Creating an iSCSI Target.....................................................................................................26

Creating a Virtual Disk ........................................................................................................28

Chapter 7 Various Settings .................................................................30

Date and Time Setting........................................................................................................30

Changing the Server Name, Workgroup, and Domain Settings .........................31

Changing the Password.....................................................................................................32

Adding a User ........................................................................................................................34

Adding a Group.....................................................................................................................35

Creating a Shared Folder...................................................................................................37

Email Notication.................................................................................................................40

Changing the IP Address ...................................................................................................42

Chapter 8 NAS Navigator2..................................................................43

Menu Commands.................................................................................................................43

Chapter 9 Appendix ............................................................................46

Factory Defaults....................................................................................................................46

LCD Message List..................................................................................................................47

Troubleshooting...................................................................................................................49

Compliance Information....................................................................................................50

TeraStation Pro WSS User Manual 3

Chapter 1 Opening Windows Storage Server

Opening Windows Storage Server

To open Windows Storage Server, perform the following procedure.

Double-click the NAS Navigator2 icon on your desktop.

In Mac OS, click the Bualo NAS Navigator2 icon in the Dock.

Windows Storage Server now opens in remote desktop.

Note: Make sure that the same language is congured in “Display language”, “Welcome screen and system accounts”,

and system locale. Conguring dierent languages for these settings may cause unexpected behavior.

In NAS Navigator2, right-click (for a Mac, click while holding down

the Control key) the TeraStation icon and select Open Remote

Desktop.

Notes:

• When two or more LinkStations or TeraStations are connected

on the same network, multiple icons will be displayed. Select the

TeraStation that you want to open.

• If the message “The identity of the remote computer cannot be

veried. Do you want to connect anyway?” is displayed, click Yes

or Continue.

Enter the username and the password, then click OK.

By default, the username and password are as follows.

Username：Administrator

Password：password

After logging in for the rst time, change the password.

If using OS X 10.4 or later, download and install "Remote Desktop Connection Client for Mac 2" from www.microsoft.

com. For OS X 10.3.9, use version 1.0.3 instead.

Computer

TeraStation Pro WSS User Manual 4

Chapter 2 Windows Update

Windows Update

1In Windows Storage Server, navigate to Start - All Programs -

Windows Update.

This completes the Windows Update process.

Note: Installing antivirus software on the TeraStation is recommended. Connect a USB CD/DVD drive to the TeraStation's

USB port, load the antivirus software CD into the CD-ROM drive, then follow the directions to install.

2Click Check for updates.

3If any updates appear, Click Install updates.

The Internet Explorer plug-ins required for Windows Update are

installed.

Follow the on-screen instructions to perform the update.

For best results, Windows Storage Server should be updated regularly. Use Windows Update as described below.

Note: To update Windows, the TeraStation must be connected to the Internet.

Remote Desktop

TeraStation Pro WSS User Manual 5

Chapter 3 Software

Email Notication

You can congure the TeraStation to send you email notications when

settings are changed or if an error occurs. See the "Email Notication" section

in chapter 7 for more details.

Note: This software cannot be accessed by multiple users at the same time.

Before launching it, make sure that it is not being used by another user.

RAID Builder

RAID Builder is used to create RAID arrays. See the "Managing Your Storage"

section in chapter 4 for more details.

Note: This software cannot be accessed by multiple users at the same time.

Before launching it, make sure that it is not being used by another user.

Remote Desktop

TeraStation Pro WSS User Manual 6

Display Settings

This opens the settings for the LCD panel of the TeraStation.

The available settings are shown below.

Note: This software cannot be accessed by multiple users at the same time. Before launching it, make sure that it is not

being used by another user.

Show The LCD panel can be congured to display any or

all of the following items: IP Address 1, Drive Usage,

Date & Time, and IP Address 2.

Scroll Display The LCD display can be set to automatically switch

between selected items at xed intervals.

LCD Brightness The brightness of the LCD panel backlight can be

adjusted to one of ve levels.

Night Mode If checked, the LCD brightness will be set at level 2

(dark) from 6 pm to 8:59 am the next day.

Note: If the LCD brightness is already set to level 1

(darkest) or level 2 (dark), night mode will be grayed

out and cannot be selected.

Remote Desktop

Backup & Replication

These settings allow you to congure data backup and replication on the

TeraStation. See the "Back Up from the TeraStation" and "Replication" section in

chapter 5 for more details.

Note: This software cannot be accessed by multiple users at the same time.

Before launching it, make sure that it is not being used by another user.

Remote Desktop

TeraStation Pro WSS User Manual 7

Bualo Dashboard

Bualo Dashboard displays system information and dismounts

hard drives. To launch it, double-click the Bualo Dashboard

icon in the system tray.

Note: This software cannot be accessed by multiple users at the

same time. Before launching it, make sure that it is not being used

by another user.

System Information

Product Name: Displays the model name of the TeraStation.

Computer Name: Displays the hostname of the TeraStation.

Domain Name: Displays the type of Windows installed on the TeraStation.

OS: OS installed on TeraStation

OS Version: Displays the version of the OS.

Firmware: Displays the rmware version of the TeraStation.

• Check for updates: Enables or disables checking for new rmware

releases. When a new rmware version is available, you will be

notied here.

Manufacturer: Bualo Inc.

Temperature Displays the TeraStation’s system temperature.

Fan Displays the fan speed.

Backup Displays the status of backup.

Network Information Displays the TeraStation’s IP address, subnet masks, default gateways,

LAN port numbers, and status.

I’m here! Causes your TeraStation to beep.

Drive

Displays the status, drive numbers, names, capacity, and physical sector

sizes of each drive.

Refresh: Updates the displayed drive information.

Dismount Drive: Dismounts a drive for safe removal. Select the drive to

dismount and click OK.

Options:

• Shut down when the drive’s temperature becomes abnormally high: The

TeraStation will automatically shut down if the drive gets too hot.

• Turn o the drive if an error occurs - The hard drive will automatically

be turned o (dismounted) if a drive error occurs.

How To Dismounting Drives:

Click Dismount Drive, check the drive to dismount, then click OK. After the

drive is dismounted, unplug the hard drive from the TeraStation.

Remote Desktop

TeraStation Pro WSS User Manual 8

Note: The following functions are only available when logged in as administrator:

• Refresh

• Dismount drive

• Options

• Check for updates

TeraStation Pro WSS User Manual 9

Chapter 4 Managing Your Storage

RAID 5 Volume

The unallocated areas of three or more hard drives are used as a single array.

If one drive in a RAID 5 array fails, data on the array can be recovered after the failed drive is replaced. However, if two or

more drives fail, all data is lost.

Mirrored Volume (RAID 1)

The unallocated areas of two drives are combined into a single RAID 1 array. Because the same data is written to both

drives simultaneously, if one drive fails, data can be recovered from the other drive. If both drives in the array fail, data

cannot be recovered.

Striped Volume (RAID 0)

In a striped volume, the unallocated areas of two or more drives are combined into a single logical volume using RAID 0.

However, data cannot be recovered if even a single drive fails.

Spanned Volume

In a spanned volume, the unallocated areas in multiple hard drives are joined to create a single logical volume. This

allows odd sizes of space on various drives to be combined eciently. However, data cannot be recovered if even a

single hard drive failure occurs.

Simple Volume (JBOD)

The internal hard drives of the TeraStation are each used as individual drives. If a hard drive fails, the data on the failed

hard drive cannot be recovered.

The features of each volume type are explained below.

Notes:

• When a volume type is changed, all data stored in that volume is erased. Before executing these operations, back up

any important data.

• In this manual, “recovery” means reverting the TeraStation (including the data) to state prior to the drive failure. It

doesn’t refer to reading data from a failed hard drive.

Volume Types

Altri manuali per TeraStation Pro WSS

Indice

Altri manuali Buffalo Server di archiviazione di rete

Buffalo

Buffalo LS220D0802-EU Manuale utente

Buffalo

Buffalo LinkStation Live Manuale utente

Buffalo

Buffalo TeraStation WSS 5000 Manuale utente

Buffalo

Buffalo iSCSI Istruzioni per l’uso

Buffalo

Buffalo TeraStation Guida utente

Buffalo

Buffalo BS-GS2008P Manuale utente

Buffalo

Buffalo TeraStation WSS WSH5010N6 Manuale utente

Buffalo

Buffalo TeraStation 3010 Manuale utente

Buffalo

Buffalo LinkStation 200 Series Manuale utente

Buffalo

Buffalo HD-RQSSU2/R5 Manuale utente

Buffalo

Buffalo TeraStation TS3220DN Manuale utente

Buffalo

Buffalo TeraStation 5010 TS5210DN Manuale utente

Buffalo

Buffalo LS-WX1.0TL/R1 Manuale utente

Buffalo

Buffalo LinkStation LS210D0101 Manuale utente

Buffalo

Buffalo LS520D Series Manuale utente

Buffalo

Buffalo TS3210DN Manuale utente

Buffalo

Buffalo LinkStation HD-H series Manuale utente

Buffalo

Buffalo LINKSTATION HS-DGL Manuale utente

Buffalo

Buffalo TeraStation WSS HR WSH5000N2 Series Manuale utente

Buffalo

Buffalo LS-WVL Manuale utente

Buffalo

Buffalo LinkStation LS220D Series Manuale utente

Buffalo

Buffalo CloudStation CS-X Manuale utente

Buffalo

Buffalo LinkStation Live Manuale utente

Buffalo

Buffalo TeraStation 5200 Manuale utente

Manuali Server di archiviazione di rete popolari di altre marche

HP NetStorage 6000 Manuale utente

Seagate

Seagate U10 ST320423A Manuale utente

Synology

Synology RackStation RS816 Manuale

D-Link

D-Link ShareCenter Pro DNS-1200-05 Manuale utente

Avid Technology

Avid Technology VideoRAID ST Guida di sicurezza

Western Digital

Western Digital My Cloud Home Duo Manuale utente

PrimeArray

PrimeArray 4xxx Manuale utente

Planex

Planex MZK-NAS01SG Manuale utente

Intel

Intel SS4000-E - Entry Storage System NAS Server Manuale utente

Synology

Synology RS2212+ Manuale utente

Allnet

Allnet ALL69000 Manuale utente

Adaptec

Adaptec 5325301580 Manuale utente

Motorola

Motorola EXORdisk II Manuale utente

Sony

Sony XDAAI1PK Manuale utente

Cisco

Cisco Linksys NAS200 Istruzioni operative originali

Sans Digital

Sans Digital MR4UT6G Manuale utente

AIC

AIC FB128-LX Manuale utente

Dell

Dell PowerVault NX3500 Istruzioni utente
