Buffalo HD-CELU2 DRIVESTATION Manuale utente

Package Contents:

•DriveStation

•USB Cable

•Ethernet Cable

•Power Adaptor

•DriveNavigator Installation CD

•Quick Setup Guide (this manual)

•Warranty Card

www.buffalotech.com

Quick Setup Guide

HD-CELU2

DriveStation FlexNet

v1.3

Front Panel Layout

Power/Access LED

Mode Button/LED

Red - USB mode

Green - LAN mode

Note: The DriveStation FlexNet can be connected to a

computer as both an Ethernet NAS and a USB external

hard drive at the same time. To switch between the two

modes, press the mode button.

Back Panel Layout

Reset button

Ethernet (to router)

Power

USB (to PC)

Power button

Click Install.

Installing Your DriveStation

Insert the installation

CD into your PC’s CD-

ROM drive. Setup will

automatically launch. Click

on Begin Installation.

The wizard will guide you

through installation. First,

you’ll install the DriveStation

FlexNet as a USB device.

Then, you’ll switch modes

and install the DriveStation

FlexNet in LAN mode as

a NAS device. Follow the

directions on each screen and

continue pressing Next to

step through the installation.

When installation is complete,

you may close the installation

window.

Congratulations! Your DriveStation is ready to use. Turn to page 6

for instructions on DriveStation as a networked LAN drive, or page 7

for instructions on using it as a USB drive.

Please see the User Manual on your DriveStation CD for more help

and conguration options.

Transmission Speed: 10/100 Mbps (Ethernet); 480 Mbps (USB)

Hard Drives: 3.5” SATA

Ethernet Connector: RJ-45

USB Connector: USB 2.0

Power Supply: 100-240V 50/60Hz

Client OS Support: Windows® 2000, XP, Vista™

Power Consumption: Max 24W, Average 17W

Dimensions: 6.1” x 6.9” x 1.8”

Weight: 35 ounces (1 kg)

Operating Environment: 41°- 95° F; 20 - 80% non-

condensing

Using your DriveStation in LAN Mode

In LAN mode, the mode button will

glow green. If it’s red, press it. The

LED will change to green. To use the

DriveStation in LAN mode, it should be

connected to a router on your network

via an Ethernet cable.

After running the installation wizard,

this icon will be on your desktop:

BrowseHD-CEL.

In LAN mode, clicking BrowseHD-CEL

takes you directly to the main folder on

your DriveStation FlexNet.

Using your DriveStation in USB Mode

In USB mode, the mode button will

glow red. If it’s green, press it. The

LED will change to red. To use the

DriveStation in USB mode, it must be

connected to your computer with a

USB cable.

In USB mode, the DriveStation

functions as a normal external USB

hard drive. It can be accessed from My

Computer. By default, it will receive

the next available drive letter and will

be named HD-CELU2.

FCC Warning

This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:

(1) This device may not cause harmful interference, and (2) this device must accept any interference

received, including interference that may cause undesired operation.

Windows is a registered trademark of Microsoft Corporation in the United States and other countries.

USA/Canada Technical Support is available 24 hours a day, 7 days a week

Toll-Free: 866-752-6210

email: [email protected]

http://www.buffalotech.com
