USB 2.0 External Portable Hard Drive with Bus Power Booster –

HD-PH40U2/BST, HD-PH80U2/BST, HD-PH100U2/BST

Buffalo’s USB 2.0 Portable External Hard Drive with Power Booster offers a

compact light-weight storage solution for any mobile user. You can quickly

access and store backups of files, digital images, documents that will not take

up the room on your PC’s main drive. The Portable HD runs at 5400 rpm and is

available in 40, 80 and 100 GB capacities. The included Bus Power Booster

provides a reliable source of power for the external hard drive when a reliable

power current is not available. Using the Bus Power Booster reduces the power

consumption of your PC, however it is not required for operation on all

computers but is recommended for guaranteed operation, longevity, and

performance. Auto installation and easy operation makes the Portable

HD a true plug and play storage solution for anybody.

●●High Speed Mode at 5400 rpm

●●Includes Mobile Assist Cable with Bus Power Booster to Reduce Power

Consumption of Your PC

●●No Need to Install Drivers with Auto Setup

●●Pre-formatted Hard Drive for Immediate Use

●●Supports USB 2.0 and 1.1

●●Portable and Light Weight for Ease of Use

●●Silent Operation and Compact Design

Buffalo

①

②

③

When you connect the

Power Booster (PB) to your

PC, the PC starts charging

the power booster.

The PB charges the power

until the PB saves enough

power to boot up your

portable hard drive safely.

Your portable hard drive

boots up and runs using

the bus power from your

PC and the power from

the power booster.

The Bus Power Booster provides a reliable

source of power for the external hard drive.

Some computers have difficulty providing a

reliable current to the hard drive, resulting in

poor performance, unreliability, or non-

operability. Using the Bus Power Booster

resolves these types of problems. The Bus Power

Booster is a detachable accessory that is not

required for operation on all computers but is

recommended for guaranteed operation,

longevity, and performance.

Start Charging

Charging

After booting, the PB provides power if necessary.

HD-PH40U2/BST

4200 rpm Hard Drive

29.1 MB/s

21.3 MB/s fast

36%

Faster

HD-PH60U2/BST

4200 rpm Hard Drive

29.1 MB/s

21.3 MB/s fast

36%

Faster

HD-PH80U2/BST

4200 rpm Hard Drive

29.1 MB/s

21.3 MB/s fast

36%

Faster

HD-PH100U2/BST

4200 rpm Hard Drive

29.1 MB/s

21.3 MB/s fast

36%

Faster

USB 2.0

IEEE 1394

UltraSCSI

USB 1.1

480 Mbps

400 Mbps

Theoretical Numbers

160 Mbps (20 MB/s)

12 Mbps

High-Speed USB 2.0 is Faster Than IEEE 1394 (Firewire)

5400 rpm Hard Drives are up to 36% Faster than 4200 rpm Hard Drives

No AC Adapter Needed With Mobile Assist Cable

HD-PH40U2/BST

HD-PH80U2/BST

HD-PH100U2/BST

HD-PHXXU2/BST_DS final.qxd 6/30/05 3:09 PM Page 1

Technical Specifications

USB Standards USB Specification Rev. 2.0

Capacity 40, 80, 100 GB

Seek Time Max. 13 milliseconds

Transmission Speed Max. 480 Mbps

Power Consumption Max. 2.5 W

Power Supply DC5V™5%

Dimensions

Portable Hard Drive: 4.7 x 3.0 x 0.6 in. (119 x 76.5 x 15.7 mm)

UC-BST: 2.5 x 2.3 x 0.7 in. (63 x 58 x 18 mm)

Weight

Portable Hard Drive: Approx. 5.3 oz. (150g)

UC-BST: Approx. 1.8 oz. (50g)

Operating Environment 5 - 35°C 20-80% humidity (non-condensing)

OS Support

Windows®XP, Windows®2000, Windows®Me

Mac OS®X 10.2.7 (for USB 2.0 support), Mac OS®X 10.0.4, Mac®OS 9.0.4

Package Contents

Portable Hard Drive, USB 2.0 Cable with Bus Power Booster (UC-BST), USB

Cable A to Mini-B (2.6 ft.), User’s Manual (read first), Warranty Statement

Technical Specifications

USB 2.0 External Portable Hard Drive with Bus Power Booster –

HD-PH40U2/BST, HD-PH80U2/BST, HD-PH100U2/BST

4030 W. Braker Lane #120

Austin, TX 78759

800-456-9799

www.buffalotech.com

Buffalo Technology (USA), Inc. is a leading

global provider of affordable, easy-to-use,

next-generation wired and wireless network

solutions for the consumer, SOHO and SMB

markets. With its expansion into the U.S.

retail market, Buffalo offers home users a

full suite of wireless home networking

solutions such as its award-winning line of

AirStation 54g products; its 125* High-

Speed Mode™ 802.11g products; and its

versatile line of 802.11a/b/g combo

products. Buffalo completes its offerings

with additional world-class networking

solutions that include memory, storage and

multimedia products – perfectly suited for

any wireless environment.

(USA), Inc. The names and logos of other companies mentioned herein belong to their respective owners.

HD-PH40U2/BST

HD-PH80U2/BST

HD-PH100U2/BST

HD-PHXXU2/BST_DS final.qxd 6/30/05 3:09 PM Page 2
