BUILDONE BO-DH2100 Manuale utente
www.buildone.co.kr
MANUFACTURER
MODEL
ADDRESS
COUNTRY OF ORIGIN
SERVICE CENTER
BUILDONE CO., LTD.
BO-DH2100
22-12 CHEONGDAM-RO, 39BEON-GIL,
YANGJU-SI, GYEONGGI-DO, 11459
REPUBLIC OF KOREA
PLACE OF PURCHASE
Safety Cautions
!
Do not disassemble the product, as this may cause malfunction
and damage the product.
Do not expose the product to flammable materials such as gas
lighters. It may cause product malfunction.
Do not operate the product with wet hands and keep liquids away
from the product , as it can disturb an electronic circuit.
Do not use the excessive force or remodel the product.
Avoid exposure to direct sunlight or high temperature.
Do not install the product in direct exposure to rain or snow.
Do not use water, benzene or alcohol when cleaning the product,
as these fluids can cause product malfunction.
Product Name and Components
01
Product Components
Product Name
Outer Body Parts
Battery Replacement
Alert
Reset Button
External Power
Contact Part
Emergency Key Hole
Card Reader
Outer Body Handle
Inner Body Parts
Inner Body Handle
Battery Cover
MADE IN KOREA
Battery Cover
Open Button
Close Button
Manual Open/Close Switch
Inner Body MortiseOuter Body
Installation GuideUser Manual
HOTEL LOCK USER MANUAL
BO-DH2100
WARNING
BE WELL-INFORMED OF HOW TO OPERATE MANUAL
OPEN/CLOSE SWITCH IN CASE OF EMERGENCY
‘AA’Batteries (LR6)
Emergency Key, Handle Shaft, Remote Contral (Optional), Bluetooth Module (Optional),
Video Phone Module (Optional)
Strike
WARNING
BE WELL-INFORMED OF HOW TO OPERATE MANUAL
OPEN/CLOSE SWITCH IN CASE OF EMERGENCY
■ BO-DH2100
HOTEL LOCK USER MANUAL
How to Use
02
Adding Master Card
Open the battery cover on the indoor unit
with the door open, press [R] button for
5 seconds
Hold a key tag to card reader
(Max. 30 cards)
Press [R] button to complete
1
2
3
Delete All User Card(User card can not be deleted individually)
Open the battery cover on the indoor unit
with the door open, press [R] button
Hold a registered master card to card
reader
Press [R] button for 5 seconds to
complete
1
2
3
Adding Additional Master Card
Open the battery cover on the indoor unit
with the door open, press [R] button for
5 seconds
Hold a registered master card to card
reader
Hold new master card to card reader
Press [R] button to complete
1
2
3
4
Adding User Card(Same for adding additional user card)
Open the battery cover on the indoor unit
with the door open, press [R] button
Hold a registered master card to card
reader
Hold user card to card reader
(Max. 10 cards)
Press [R] button to complete
1
2
3
4
NOTE
Deleting Master Card(Master card can not be deleted individually)
Open the battery cover on the indoor unit
with the door open, press [R] button for
5 seconds
Hold a master card to be deleted to card
holder
Press [R] button for 5 seconds to
complete
1
2
3
※ Min. of one registered master card is required for all features.
※ Registered master card is required for auto lock feature.
※ Only master card can open if double lock is activated from inside.
Additional Features
03
Emergency Keys
Use emergency key to open door if access is
denied due to product failure.
※ Emergency keys must be stored outside
Open door lock with remote control or from video phone with interlocking
module installed (Remote Control, Video Phone )
Wireless Interlocking (Optional)
1
2
Setting : With the door locked, press
[Close] button for 3 seconds
Deactivate : Press [Close] button for
3 seconds or open the door
with Manual Open/Close
Switch
Double Lock Mode (Inside) Setting / Deactivate
NOTE
1. Master card can open double lock mode (Inside)
2. User card can’t open double lock mode (Inside)
Product Specifications
04
※ The information of this user manual may vary without any notices to improve the performance of
this product.
Item Specifications
Voltage 4~8 AA Alkaline 1.5V Batteries (LR6) (DC 6V)
Emergency
Power Source 9V battery (6LF22) (sold separately)
Operation Method Electronic control method
(RF Card, Emergency Key)
Weight 2.8 kg
(including inner and outer bodies)
81.2mm(W) X 313.2mm(H) X 41mm(D)
83.3mm(W) X 313.3mm(H) X 25mm(D)
Product Dimensions
Inner Body
Outer Body
Open the battery cover on the indoor unit
with the door open, press [Close] and [R]
button at the same time for 10 seconds
Initialize to factory default setting
completed with beep sound.
1
2
Initialization(All registered data will be deleted)
Emergency Battery Use
※ If batteries are completely discharged, contact 9V
battery to external power contact part, open with card.
※ Be sure to connect external power contact point with
the battery (External power contact part has no
polarity).
NOTE
Battery Replacement
※ Four to eight 1.5V “AA” batteries can be inserted
※ Duration of Battery Use : 12 months (average use of
10 times a day)
※ Battery Replacement Notification : Replace all
batteries when battery alarm melody sounds. Open
battery cover from inner body and replace all 1.5V “
AA” batteries. Make sure to correctly match the ends
+/- when inserting and do not mix used batteries with
new batteries.
NOTE
MEMO
05
