USE AND CARE OF YOUR

BUNN®POUR-OMATIC®

Model A-10 Coffee Brewer

Welcome to the world of ﬁne coffee.

The Bunn®Pour-Omatic®Coffee Brewer will enhance

your enjoyment of each cup of coffee. Bunn®coffee

brewers are recognized in homes and restaurants

throughout the world as the very ﬁnest. Read this

booklet, and in no time you will know how to make

a great cup of coffee.

Keep this booklet for future reference.

The Bunn logo is a trademark of Bunn-O-Matic

Corporation.

Our

best

wishes

for

your

coffee

enjoyment.

Table of Contents

IMPORTANT SAFEGUARDS ............................................4

GENERAL INFORMATION................................................5

PREPARING THE BREWER FOR USE..............................6

BREWING DELICIOUS COFFEE .......................................7

HOT WATER....................................................................7

COFFEE FUNDAMENTALS ...............................................8

BREWING TIPS...............................................................8

ROUTINE CLEANING.......................................................9

HANDLE MAINTENANCE.................................................9

DELIMING.......................................................................9

SOFTENED WATER AND/OR

DECAFFEINATED COFFEE................................................9

WATER QUALITY ............................................................9

DRAINING THE BREWER..............................................10

HIGH ALTITUDE USE.....................................................10

AUTHORIZED SERVICE.................................................10

BUNN COMPANION PRODUCTS ...................................11

LIMITED WARRANTY......................................Back Cover

SPECIFICATIONS

Electrical - UL Listed. This brewer has an attached, polarized cord and

requires 2-wire service with ground, rated 120 volts ac, 10 amps, single

phase, 60 Hz.

Dimensions - 14 1/4 inches high; 6 3/4 inches wide; 13 1/2 inches deep.

Capacity - Two to eight 6-ounce cups (12-48 ounces) per batch.

Tank Size - 75 ounces.

Weight - 15 pounds; Includes decanter, water pitcher, ﬁlters, coffee funnel,

water funnel and deliming spring probe.

10070 111607

BUNN-O-MATIC CORPORATION

1400 STEVENSON DRIVE

SPRINGFIELD, ILLINOIS 62703

www.bunnomatic.com

If you need any assistance, please call us at:

1–800–352–2866

In order to receive full assistance, please have your Date Code ready

when calling for service.

(Located on the back of your brewer)

Bunn®Pour-Omatic®

MODEL A-10 COFFEE BREWER

LID

WARMER

SWITCH

BREW

FUNNEL

DECANTER

HOT WATER

TANK

(LOCATED INSIDE)

VACATION

SWITCH

P2076

Hazardous Voltage!

Can Cause Fire Or Electrical Shock!

Do Not Disassemble The Brewer!

There Are No User Serviceable Parts Inside!

Repair Should Be Done By Authorized Service Personnel!

(Refer to Page 10)

This symbol alerts you to the risk

of ﬁre or electrical shock in the

accompanying message.

This symbol alerts you to

important operating and

service instructions.

P-229/P-230

10070 010704

RISK OF FIRE OR ELECTRICAL SHOCK

WARNING

IMPORTANT SAFEGUARDS

Follow these basic safety precautions when using electrical appliances to reduce

the risk of ﬁre, electric shock, and/or personal injury:

• Read all instructions.

• Do not touch hot surfaces. Use

handles or knobs.

• Do not place cord, plugs, or brewer

in water or liquid.

• Close supervision is necessary when

the brewer is used by or near chil-

dren.

• Unplug from outlet when not in use

and before cleaning. Allow to cool

before putting on or taking off parts,

and before cleaning.

• Do not operate the brewer with a

damaged cord or plug or after the

brewer malfunctions, or has been

damaged in any manner. Return

the brewer to an Authorized Service

Facility for examination, adjustment,

or repair. (Refer to page 10.)

• The use of an accessory not evaluated

for use with this brewer may cause

injuries.

• For household use only. Do not use

outdoors.

• Do not let cord hang over edge of

table or counter, or touch hot sur-

faces.

• Do not place the brewer on or near

a hot gas or electric burner, or in a

heated oven.

• Do not use brewer for other than its

intended use.

• Do not place or remove funnel,

decanter, or decanter lid while brew-

ing.

• The decanter is designed for use with

this brewer. It must never be used on

a range top or in a microwave.

• Do not set a hot decanter on a cold

surface.

• Do not use a cracked decanter or a

decanter having a loose or weakened

handle.

• Do not clean decanter with cleansers,

steel wool pads, or other abrasive

materials.

SAVE THESE INSTRUCTIONS

• A short power supply cord is used to reduce the risks resulting from becoming

entangled in or tripping over a longer cord.

• If an extension cord is used, the marked electrical rating of the extension cord

should be at least as great as the electrical rating of the brewer and the cord

should be arranged so that it will not drape over the counter top or table top

where it can be pulled on by children or tripped over.

10070 030100

GENERAL INFORMATION

NOTE - THE BREWER IS NOT READY TO PLUG IN

Improper installation will result in permanent damage and void the limited

warranty. Read & follow the instructions on the next page.

• Be certain the tank is full of water before plugging in the brewer. (Requires at

least three quarts to ﬁll).

• This brewer is designed to remain plugged in at all times (except during initial

installation or when cleaning.)

• A power switch is provided on the lower left side to completely shut off all elec-

trical components when your plans take you away from home for several days.

Safety features, designed into the Bunn®Pour-Omatic® coffee brewer, make the

daily use of this switch unnecessary.

• Whenever the brewer has been shut off or unplugged, allow the water in the tank

to heat to the proper temperature before using (about ﬁfteen minutes or until the

heating sound stops).

• Your Bunn®Pour-Omatic®coffee brewer has a specially designed tank to keep

the water at the proper temperature. This constant supply of hot water assures

the correct method of brewing coffee, in less than three minutes.

• The brewed coffee ﬂows into the decanter where it is kept at serving temperature

on the porcelain decanter warmer. The warmer is controlled by the lighted on/off

switch on the front of the brewer.

NOTE - The warmer switch only controls the decanter warmer.

• While coffee is being brewed, the newest water in the tank is heated to the proper

temperature and held until needed.

• The decanter lid reduces coffee evaporation and temperature loss.

• Hot water, approximately 50˚F hotter than that available from your hot water

faucet, is always available for other uses.

• This brewer has an attached, polarized cordset and requires 2-wire grounded

service rated 120 volts ac, 120 amps, single phase, 60 Hz. Do not attempt to

bypass the safety aspect of this polarized plug.

• The sprayhead will periodically become loose. Using extreme caution not to burn

yourself, retighten the sprayhead with your ﬁnger tips.

NOTE - A severe burn may result if the sprayhead becomes

loose and falls off while brewing.

10070 030100

PREPARING THE BREWER FOR USE

NOTE: THE BREWER IS NOT READY TO PLUG IN

Raise the hinged ﬂip lid.

Place the decanter on the warmer. Pour two pitchers of water

(ﬁlled to the top line) into the screened area on top of the brewer.

Wait two minutes between pitchers to allow the water to ﬁll the

tank. When the tank is full, some water will ﬂow through the

funnel and into the decanter.

Close the lid and plug in the brewer.

Press the bottom of the vacation switch, located on

the lower left side of the brewer, to the “ON” position.

The vacation switch controls power to the tank heater.

Initially you will have to wait approximately ten minutes

in order for water to reach brew temperature.

P2078

P2079

P-214

P2080

10070 010704

BREWING DELICIOUS COFFEE

HOT WATER

The same basic steps can be used to obtain hot water by omitting the ﬁlter and

coffee and using the enclosed hot water funnel. The hot water from your Bunn®

coffee brewer is approximately 200˚F. This is hotter than the hot water from your

faucet and must be handled with care.

Insert a Bunn®coffee ﬁlter into the brew funnel. (Be sure

to use Bunn®coffee ﬁlters for proper brewing. There is a

difference.)

Measure coffee into the ﬁlter and gently shake to level the

bed of grounds.

Make sure that the sprayhead is tight. Slide the brew funnel

into the brewer under the warmer switch. Snap the decanter

cover in the decanter and place the decanter on the warmer

beneath the brew funnel. Place the lighted warmer switch

in the “ON” position.

Raise the hinged ﬂip-lid and pour water into the top of the

brewer. The water pitcher, supplied, will yield approximately

eight 6 ounce cups of brewed coffee when ﬁlled to the top

line. Your Bunn®Pour-Omatic®will begin brewing coffee

immediately.

When brewing has stopped, remove the brew funnel and

discard the ﬁlter and grounds. Do not touch hot grounds.

P2081

P-206

P-205

P2079

P-215

10070 030100

COFFEE FUNDAMENTALS

Brewing delicious coffee is similar to cooking any favorite food. Both require a

good recipe. Proper coffee-making needs quality equipment to precisely control water

temperature, volume, and brew time. The Bunn®coffee brewer assures consistency

in your recipe by controlling all of these elements. The only variables remaining in

the recipe are the grind and amount of coffee used.

The amount of ground coffee is generally determined by the grind. For best

results, we recommend a drip (medium) grind.

Hot water extracts many elements from the ground coffee, some desirable,

some not. The taste and aroma are referred to as strength, the acidity as bitterness.

Increasing the amount of coffee results in a stronger beverage, and decreasing it

results in a weaker beverage.

As the amount of ground coffee decreases, you’ll note an increase in the bit-

terness of the beverage. This happens because the hot water begins to remove the

undesirable elements such as acidity after all of the desirable tastes and aroma have

been removed.

Fresh ground coffee gives the best results. Always store the ground coffee in

a coo, dry area away from other food items with strong odors. When stored in a

refrigerator, keep it in an airtight container.

BREWING TIPS

When properly brewed, the difference between the best quality ground coffee

and a poor quality ground coffee becomes very dramatic. Proper brewing requires

little effort with the Bunn®Pour-Omatic®coffee brewer.

You’ll always have a great coffee experience if you follow these tips:

1) Always start with clean equipment.

2) Always use fresh cold water.

3) Always use Bunn®paper coffee ﬁlters for proper extraction.

4) Using 2 ounces of fresh drip grind coffee for each full pot (4 oz) will give you a

consistently great pot of coffee with a full-bodied ﬂavor and aroma. However,

the real criteria is personal taste. Adjust the recipe until it suits you. If you need

to make a smaller batch, experiment with less water and ground coffee.

5) Keep the beverage at the correct serving temperature by setting the decanter on

the porcelain warmer. For the freshest ﬂavor, don’t keep brewed coffee for longer

than an hour.

10070 010704

ROUTINE CLEANING

Rinsing the brew funnel and decanter after each use

is the only routine cleaning required. Occasionally, wipe

the outside of the brewer including the area above the

funnel with a damp cloth. (The brew funnel, hot water

funnel and decanter are top rack dishwasher safe.)

HANDLE MAINTENANCE

Using a phillips screw driver, periodically tighten the screw in the handle.

DELIMING

Periodically, you should delime the brewer to clear any deposits that may have

accumulated due to impurities in the water source.

P2084

P2085

1) Unscrew the sprayhead with your ﬁngertips and set

it aside.

2) Insert all but two inches of the ﬂexible deliming spring

probe (supplied) through the sprayhead opening.

3) Slide the tool in and out ﬁve or six times to loosen

mineral deposits collected in the sprayhead tube.

Remove it and set it aside.

4) Check the holes in the sprayhead for mineral deposits.

These may be cleared by using a toothpick. Rinse the

sprayhead with water before reinstalling.

5) Plug in the brewer and allow the water in the tank

to reheat before using the brewer. The frequency

of deliming depends on the mineral content of your

water.

SOFTENED WATER and/or DECAFFEINATED COFFEE

Bunn®coffee brewers will brew a perfect decanter of coffee when used with

unsoftened tap water and regular coffee. If there’s a noticeable difference when us-

ing softened water and/or decaffeinated coffee, telephone or write us to request a

special sprayhead and use a coarser grind of coffee.

WATER QUALITY

Install a water conditioner if your water contains excessive amounts of sediment,

taste, or odors.

10070 030100

P2083

DRAINING THE BREWER

The water in your Bunn®Coffee Brewer should be emptied whenever it is taken

on a trip, shipped, or stored in an unheated location with a chance of freezing.

P2084

P2082

1) Unplug the brewer and cool the hot water in the tank.

Place the empty decanter on the warmer. Simply pour a

full water pitcher of cold water into the top of the brewer,

close the lid and wait for the water to stop ﬂowing from

the funnel. Empty the decanter, repeat. This will cool the

water in the tank.

2) Remove sprayhead by turning counterclockwise with your

ﬁngertips and set it aside.

3) Grasp the back of the brewer and quickly turn it upside

down over a sink as shown. Most of the water in the tank

will ﬂow from the sprayhead opening but some water may

ﬂow from the area around the top lid. Continue tipping

the brewer until the ﬂow of water ceases.

4) Reinstall the sprayhead when all water has drained from

the brewer. Securely tighten it by turning clockwise.

HIGH ALTITUDE USE

Your Bunn®Pour-Omatic®Coffee Brewer is designed to operate in most areas

of the country. For high altitude use, over 5000 feet, the model A10-D should be

used.

AUTHORIZED SERVICE

For service (whether or not warranty is still in effect), drain the brewer, carefully

pack it so it is fully protected against breakage and send it to one of the authorized

Bunn-O-Matic facilities listed below:

Bunn-O-Matic Corporation

Retail Products Division

1400 Stevenson Drive

Springﬁeld, Illinois 62703

(800) 352-2866

Bunn-O-Matic Corporation

Retail Products Division

16431 Carmenita Road

Cerritos, California 90701

(800) 637-2866

10070 010704

NOTE: Refer to “PREPARING THE BREWER FOR USE” before us-

ing the brewer.

Altri manuali per A10 Automatic

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali Bunn Macchina per il caffè

Bunn

Bunn Single TF DBC Manuale utente

Bunn

Bunn DV Manuale utente

Bunn

Bunn My Cafe Single Cup Manuale utente

Bunn

Bunn Tiger XL M-2 EXT Manuale utente

Bunn

Bunn G9 HD Manuale di istruzioni

Bunn

Bunn Pour-Omatic B8 Istruzioni per l'installazione

Bunn

Bunn VP17 Series Manuale di istruzioni

Bunn

Bunn Single SH Manuale di istruzioni

Bunn

Bunn U3 Manuale di istruzioni e di sicurezza

Bunn

Bunn AXIOM 35-3 Guida alla risoluzione dei problemi

Bunn

Bunn Trifecta Manuale utente

Bunn

Bunn ThermoFresh Series Guida di riferimento rapido

Bunn

Bunn Coffee machine Guida alla risoluzione dei problemi

Bunn

Bunn HB Manuale utente

Bunn

Bunn TWIN INFUSION SERIES ICB Manuale di istruzioni

Bunn

Bunn CDBC-DV Manuale di istruzioni e di sicurezza

Bunn

Bunn Home Brewer Manuale utente

Bunn

Bunn CDBCF Airpot Manuale di istruzioni e di sicurezza

Bunn

Bunn Trifecta Guida alla risoluzione dei problemi

Bunn

Bunn LCA-1 Guida alla risoluzione dei problemi

Bunn

Bunn HC-2 HC-3 Manuale di istruzioni e di sicurezza

Bunn

Bunn Sure Immersion 220 Guida alla risoluzione dei problemi

Bunn

Bunn AutoPOD Guida alla risoluzione dei problemi

Bunn

Bunn DUAL SH DBC Manuale utente

Manuali Macchina per il caffè popolari di altre marche

Taurus

Taurus Livorno 6 Manuale utente

Delta-q

Delta-q QUICK Manuale utente

Black & Decker

Black & Decker BLACK DECKER HOME DE790 Istruzioni per l'installazione

Saeco

Saeco Vienna Plus Sup 018M Manuale utente

DeLonghi

DeLonghi DC300 Manuale utente

INCAPTO

INCAPTO BXCO1470E Manuale utente

Bosch

Bosch TASSIMO finesse TAS16B Series Manuale utente

Exido

Exido 245-072 Manuale utente

Animo

Animo OptiVend Choco Manuale utente

Siemens

Siemens TQ505DF Series Manuale utente

DeLonghi

DeLonghi ECI341 Manuale utente

Krups

Krups KT406511 Manuale utente

Cimbali

Cimbali M32 Classic Manuale utente

Philips

Philips HL3844N Manuale utente

Bosch

Bosch TES 515 SERIES Manuale utente

Tekmatix

Tekmatix TMFM - 65 Manuale utente

Scarlett

Scarlett SC-CM33005 Manuale utente

LAVAZZA

LAVAZZA CLASSY PLUS Manuale utente
