Safety Notice

Toprevent fire or electric shocks please read the instructionbefore

installing, using and cleaning the television.

Please read all the instructions before operation;

Please keep themanual for future reference ;

Do not useany accessories that are not recommended by the manufacturer:

Before operation, make sure the operating voltage of this unit is corresponds

with your houseelectrical supply;

Do not placethe unit on unstable or in dusty and humidplaces;

Never put theunit in direct sunlight or near heat sources;

Allow enough space for proper ventilation;

Please keep wateraway from the LCD-TV . If water comes into contact with

the LCD-TV, disconnect the power cord from the power source, then wipe the

set with a dry soft cloth;

Do not removethe back cover. If servicing is required , please referto

customer helpline.

P. 0 5

Front Panel Control

Control Panel Function

1. Standby switch

2. SOURCE Call the Input Source menu/Confirm button when operation

menu.

3. MENU Press to select the main menu

4. VOL- Volume down/ Left orientation to adjust the item in the OSD

VOL+ Volume up / Right orientation to adjust the item/Press to enter

5. CH- TV channel down / to select the item in the menu

CH+ TV channel up / to select the item in the menu

6. Power indicator

7. Remote Sensor

(The figure above and the description of the button may be different,

all picture in this manual is just for reference, please see the actual set.)

SOURCE MENU VOL- VOL+ CH- CH+ STANDBY

02 About your LCD

02 About your LCD TV

ANT IN COAXIAL S-VIDEO

VGA IN

PC AUDIOIN

Common Interface

R-AUDIO-L TV SCART

TV SCART

Pr Pb Y

HDMI USB

Connection

USB

HDMI

TV SCART

YPbPr

Common Interface

S-VIDEO

AUDIO IN

VGA IN

PC AUDIO IN

ANT IN

Connect to HDMI output of other equipment

Connect a component video/audiodevice to these jacks

Component/S-Video Audio Input

Earphone port

COAXIAL

Connect to the VGA 15PIN analog output connector of the Pc display card for PC

display purpose

Connect the PC outpu tconnec tor from a PC to the audio

Connect cable or antenna signals to the TV, either direc-tly or through your

cable box.

P. 0 6

02 About your LCD TV

Just take oneTV with DVDfor example,

please see thereal)

DVD insert

STOP

PLAY/PAUSE

OPEN/CLOSE

(Please refer to actualproduct

of the DVD slotand buttons)

Remote Control

When using the remote control, aim it

towards the remotesensor on the TV

Stand By

DVD Menu

DVD open/close

Picture Mode

Sound Mode

Call Screen Display

Sleep button

DTV Audio/NICAM/DVD Audio

Aspect Ratio Control button(except for DVD&USB )

Channel list button

Subtitle button

Program Number Channel selection

Source Exchange

Q.VIEW

V+/V- :Volume selection

P+/P-:Channel selection

Mute

Menu button

GUIDE Button (only for DTV)

Favourite button

OK button

Cursor Mover Button

Back button (only for USB)

Exit Screen Display

REPEAT (only for USB)/CANCEL button

Zoom(only for DVD &USB)/Teletext index(only for TV)

Play/pause button(only for DVD &USB)

STOP(only for DVD &USB)

FAST REVERSE(only for DVD &USB)

FAST FORWARD(only for DVD &USB)

PREVIOUS(only for DVD &USB)

NEXT(only for DVD &USB)

DVD SET UP/ TEXT

DVD TITLE/TELETEXT MIX

DVD SEARCH/TELETEXT SUBCODE

DVD 10+/TELETEXT HOLD

DVD PROGRAM/TELETEXT REVEAL

DVD A-B REPEAT/TELETEXT SIZE

DVD ANGLE/TELETEXT TIME

DVD CALL/TELETEXT MODE

Buttons on the remote control

NOTE:Red button GREEN button

blue button andyellow button arefast

text button inanalog signal .Function

button in DVBT(just reference theOSD)

P. 0 7

SCREEN

STOP

Installing Batteries

1.Open the cover of the battery compartment at the back of the remote

control.

2.Insert two AAA alkaline batteries in the compartment. (plus and minus poles to

respective mark)

3.Replace the cover of the battery compartment.

Precautions

Make sure that there is no

obstacle between the remote

controller and television set.

As strong light may interfere the

signals, change your position to

operate the remote controller if

the television cannot be turned

on or off as you expect.

Keep the remote controller

away from heat source or

humid area to ensure

effective performance of

the remote controller.

Make sure that two AAA 1.5V alkaline

batteries are loaded. The batteries

must be of the same type. The batteries

must be located properly. The batteries

are not rechargeable. If your TV is to be

stored for a period of time, remove the

batteries from the remote control.

P. 0 8

02 About your LCD TV

Connection Instructions

External Equipment Connections

Antenna Connection

- Antenna or Cable Service with a Cable Box Connections

- For optimum picture quality, adjust antenna direction if needed.

Multi-family Dwellings/Apartments

(Connect to wall antenna socket)

wall antenna

socket

VHF antenna

UHF antenna

outdoor

antenna

Single-family Dwellings /Houses

(Connect to wall jack for outdoor antenna)

Be careful not to bend the bronze

wire when connecting the antenna.

To improve picture quality in a poor

signal area, purchase and install a

signal amplifier.

If the antenna needs to be split for two

TV s, install a 2-Way Signal Splitter

in the connections.

If the antenna is not installed properly,

contact your dealer for assistance.

NOTE: All cables shown are just for example.

RF coaxial wire (75 ohm)

ANT IN

P. 0 9
