Bushnell Back Track 360400 Manuale utente
Instruction Manual
Lit # 98-2280/05-12
Model # 360400 / 360401 / 360402
™
English .......... 4
Français .......13
Español ...... 22
Deutsch .......31
Italiano ....... 40
Português ... 49
4
Control & Display Guide
Note: Display as shown above is for reference only. All icons and data will not appear
simultaneously on the BackTrack’s display during normal operation.
MODE/Power Button
Satellite Locked Icon
Battery Indicator
Distance Units
Distance to Marked Location
or Compass Heading
(in compass mode only)
Location Mode Icons
(Home, Car, Favorite Spot)
MARK/Backlight
Button
Direction to Marked
Location
or North Indicator
(in compass mode only)
Degrees (compass mode)
ENGLISH
5
1. Remove the battery cover on the back of the BackTrack after sliding the switch to the “unlock” position,and insert two
AAA batteries (alkaline or lithium)*. Replace the cover and slide the switch back to “lock”. Change batteries when low
power is shown by the battery indicator icon. Make sure the battery contacts are clean and replace both batteries at once.
Remove the batteries when storing the unit longer than a few weeks.
2. HOLD (keep pressed for 2 seconds) the MODE/POWER button to turn on the BackTrack. The BackTrack is ready
to use when the Satellite icon on the display stops flashing (be sure you are outdoors with a clear view of the sky).
Batteries Inserted
HOLD Mode/Power Button
HOLD
Take the
BackTrack
Outdoors
Slide battery cover switch to unlock
Satellite Icon
+
+
*Do Not Mix Old and New Batteries.
Do not mix battery types-use ALL lithium or ALL alkaline.
6
3. The BackTrack starts out in Compass Mode the first time you turn it on. An arrow points North, and the display shows
the direction you’re facing in degrees (e.g. East=90 degrees). The directional arrow works best in both Compass and
Location Modes with the unit held horizontally or “flat” in front of you. Return to Compass Mode anytime by pushing
the MODE/POWER button briefly until the “Compass” icon is selected again.
4. To mark a location you want to get back to, PUSH the MODE/POWER button one or more times to select one of the
three Location Mode icons (“Home”, “Car”, or “Star”) .
Compass Mode
Compass
Degrees
North
Arrow
PUSH
“Home”
Icon
“Car”
Icon PUSH “Star”
Icon PUSH
PUSH Mode/Power to select from three Location icons
7
PUSH
5. After selecting the icon you want, HOLD the MARK button (while you are physically at or near the location you want
to save), until the distance indication changes to “0”. Note: it does not matter which direction you face when marking
the location.
6. You may now turn the BackTrack’s power off by HOLDING down the MODE/POWER button, or proceed to another
location you want to mark. Be sure to select a different icon before marking this new spot. If you hold down MARK
with a previously used Location icon selected, you will replace that one with your current location.
HOLD
HOLD the MARK button down to save the location of
your campsite (with the “Home” icon selected here)
Home Icon
Marking an
additional location
12At the new location,
1-Select another icon
2-MARK the new location
Car
Icon
HOLD
8
7. Returning to one of your previously marked locations is easy! Simply turn the BackTrack’s power back on (HOLD the
MODE/POWER buttons) and the BackTrack display will indicate the direction and distance back to the most recent
location you marked. If you want to return to a different previous location, just PUSH the MODE/POWER button
to select the icon you used when you marked it earlier. To find your way back to the selected location, simply move in
the direction the arrow points and watch for the distance to decrease. When you reach your destination, the distance
displayed will be “0”.
PUSH
HOLD
HOLD MODE/Power to turn unit back on.
Display shows distance & direction
to the last (most recently) marked location.
149 yds distance in direction of the
arrow to your car in the parking lot
616 yds distance in direction
of the arrow to your campsite
PUSH MODE/POWER to select the icon
you used to store another location. Distance
& direction to it are now displayed.
Car Icon
Home Icon
9
8
To ensure directional accuracy, hold the BackTrack out horizontally in front of you (parallel to the ground) and move it in
a “figure 8” pattern a few times to re-calibrate the compass.
To use the BackTrack as a digital compass, simply PUSH the MODE/POWER until you see the arrow surrounded by the
compass scale (circle of dots/lines), and the BackTrack will again display an arrow pointing North, and the compass degrees
for the direction it’s pointed (see red arrow above).
Degrees symbol
PUSH MODE/POWER to select the
BackTrack’s Compass Mode
Returning to Compass Mode
Compass heading in
degrees (towards
forward direction)
10
HOLD
HOLD
HOLD both MODE/POWER and
MARK to select English or Metric
units for displayed distance
(yd & mi or m & km).
In a
Location
Mode
PUSH
PUSH MARK to
activate backlight.
Changing the Distance Units
• To change the units from English to Metric, HOLD both the MARK and MODE/POWER buttons when any
of the three location icons is selected- the distance units display changes from “yd” to “m”. The BackTrack will
automatically switch from yards to miles (or meters to km) for longer distances. It can display up a maximum
distance of 999 miles or kilometers.
Turning on the Backlight
• PUSH MARK to turn on the display backlight at anytime. It will automatically turn off in 30-45 seconds.
Auto Power Off
• Power automatically turns off after 10 minutes if no buttons have been pressed, or HOLD down MODE/POWER
to turn off manually. When the BackTrack is turned back on, it returns to the last mode you selected.
Other Operations
