Byiba P002 Manuale utente
L max = 3000 mm
12
3
TRASFORMATORE
COSTANT VOLTAGE L1 L2 L...
V in
230 V
F
N
+
-
CONSTANTVOLTAGE
4
4b SOLO PER P002/ONLY FOR P002 56
78910
13 14
11 12
MAX 30W/m
P002
P003
P004
P005
IP 20
MADE IN ITALY
025.481(REV03)
P002/3/4/5.KIT01
x4
x2
023.700 - 023.701 - 023.702 - 023.703 - 023.704
es. 023.701 - connessione “L” - “L” connection - “L” Verbindung
IMPORTANT
To ensure equipment safety you must carefully follow the instructions below. This leaflet must be kept handy by personnel entrusted with all ordinary and
extraordinary maintenance.
• Before any installation or maintenance operation on the bulb, make sure it is disconnected from power.
• Fit the correct bulbs, according to the type and power indicated on the lamp data label.
• Make sure the lamp technical features are compatible with the use you are going to make of it.
• Should you have any doubt, refer to the dealer or ask an electrician.
• When connecting to the mains, fallow the correct colour code far power cables: (N) blue, (L) brown or black and, only far class I equipment, (T) yellow/green.
• When lamps are to be fitted to the wall directly through their ceramic parts, fasten the fixing screws lightly, to avoid breaking the ceramic.
• To clean the lamp on the outside, use a soft cloth, possibly wet. Do not use solvents or abrasive products. No liquid must get in contact with the lamp interior
parts.
• Do not touch the equipment with dirty hands.
= Class I equipment, must be connected to an earth terminal.
= Double insulated lamp, does not need earthing.
= Electrical equipment in class III, electrical safety guaranteed by low voltage tension, does not require grounding
= Replace immediately the safety glass, if damaged, with the original part.
= Minimum distance to be observed from all lit up objects.
= The lamp uses low pressure bulbs, and needs no protection glass.
= Device with CE marking
= The equipment at the end of its life must be collected separately from other waste
