P/N 466-2946-ML • REV D • ISS 16MAR21 3 / 26
Specifications
12.0 to 13.5 VDC (provided by panel)
175 mA max. in alarm state with sounder
and screen on maximum brightness,
100 mA typical in non-alarm state,
40 mA in idle mode
Resistive touch 3.5” colour TFT LCD screen
512 zones, 96 areas, 644 outputs,
256 users
10 000 (4 digits)
There are no invalid code combinations.
Opal white with silver frame
0 to +49°C (+32° to 120°F)
−34 to +60°C (−30° to +120°F)
Placed on the market by:
Carrier Fire & Security Americas Corporation, Inc.
13995 Pasteur Blvd
Palm Beach Gardens, FL 33418, USA
Authorized EU manufacturing representative:
Carrier Fire & Security B.V.
Kelvinstraat 7, 6003 DH Weert, Netherlands
This equipment has been tested and found to
comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These
limits are designed to provide reasonable
protection against harmful interference when the
equipment is operated in a commercial
environment. This equipment generates, uses,
and can radiate radio frequency energy and, if not
installed and used in accordance with the
instruction manual, may cause harmful
interference to radio communications.
You are cautioned that any changes or
modifications not expressly approved by the party
responsible for compliance could void the user's
authority to operate the equipment.
Check local ordinances, this device is not listed
by an approved test lab to meet NFPA 72 and
therefore may not be sold or installed for use with
a fire system in some localities.
INCERT
EN 50131-1 System requirements
EN 50131-3 Control and indicating equipment
NXG-1820-EUR: Security Grade 2, Environmental
class II
Tested and certified by Telefication B.V.
Compliance labelling should be removed or
adjusted if non-compliant configurations are
selected.
Product warnings
and disclaimers
THESE PRODUCTS ARE INTENDED FOR SALE
TO AND INSTALLATION BY QUALIFIED
PROFESSIONALS. CARRIER FIRE &
SECURITY CANNOT PROVIDE ANY
ASSURANCE THAT ANY PERSON OR ENTITY
BUYING ITS PRODUCTS, INCLUDING ANY
“AUTHORIZED DEALER” OR “AUTHORIZED
RESELLER”, IS PROPERLY TRAINED OR
EXPERIENCED TO CORRECTLY INSTALL FIRE
AND SECURITY RELATED PRODUCTS.
For more information on warranty disclaimers and
product safety information, please check
https://firesecurityproducts.com/policy/product-
warning/ or scan the QR code.
European Union
directives
Carrier Fire & Security hereby declares that this
device is in compliance with the applicable
requirements and provisions of the Directive
2014/30/EU and/or 2014/35/EU. For more
information see
www.firesecurityproducts.com/en/page/caddx
Product may contain substances that are also
Candidate List substances in a concentration
above 0.1% w/w, per the most recently published
Candidate List found at ECHA Web site.
Safe use information can be found at
https://firesecurityproducts.com/en/content/intrusi
on-intro
2012/19/EU (WEEE directive): Products marked
with this symbol cannot be disposed of as
unsorted municipal waste in the European Union.
For proper recycling, return this product to your
local supplier upon the purchase of equivalent
new equipment, or dispose of it at designated
collection points. For more information see:
recyclethis.info
Contact information
www.firesecurityproducts.com/en/page/caddx
EL: Φύλλο εγκατάστασης
Σύνοψη προϊόντος
Η μονάδα NXG-1820-EUR είναι μια έξυπνη οθόνη αφής με
γραφικά που έχει δημιουργηθεί για όσους χρησιμοποιούν
κάποιο από τα συστήματα ασφαλείας της οικογένειας xGen.
Παρέχει δυνατότητα εύκολου χειρισμού του συστήματος
ασφαλείας με απλά πατήματα σε μια ευκρινή οθόνη αφής 3,5''
με κατανοητά γραφικά. Κατά την εγκατάστασή της, υπάρχει
δυνατότητα προσαρμογής ανάλογα με την τοποθεσία. Οι
προσαρμόσιμες ρυθμίσεις περιλαμβάνουν την ονομασία
ζωνών, υποσυστημάτων, χρηστών και εξόδων. Οι χρήστες
μπορούν ακόμα και να αφήνουν μηνύματα για τους
υπόλοιπους χρήστες, μέσω του κέντρου εσωτερικών
μηνυμάτων. Με την οθόνη NXG-1820-EUR, είστε ασφαλής με
ένα μόνο πάτημα.
