CU S T O M E R CO N V E N I E N C E / P E RS O N A L IZ AT I O N GU I D E

SRX

DRIVER INFORMATION

Instrument Panel . . . . . . . . . . . .1

Instrument Panel Cluster . . . . . . .2

Driver Information Center . . . . . .3

COMFORT

Manual Seat Adjustments . . . . . .4

Power Seat Adjustments . . . . . .4

Power Lumbar . . . . . . . . . . . . . .5

HeatedSeats ...............5

Memory Seat and Mirrors . . . . . .5

Second-Row Seat . . . . . . . . . . .6

Third-Row Access . . . . . . . . . . . .6

Power Third-Row Seat . . . . . . . .6

Child Restraints (LATCH) . . . . . .7

Climate Control . . . . . . . . . . . . .7

Rear Air Conditioning . . . . . . . . .8

ENTERTAINMENT

AudioSystem...............9

XM™ Satellite Radio . . . . . . . . .11

Touch Screen Navigation

Entertainment System . . . . . . .11

Rear Seat Entertainment

System ...................11

CONVENIENCE

OnStar®...................12

Universal Home Remote . . . . .13

Ultrasonic Rear Parking Assist

(URPA) ...................13

UltraView/UltraView Plus

Sunroof ..................13

Power Adjustable Pedals . . . . .14

Cruise Control . . . . . . . . . . . . . .14

Adaptive Remote Start . . . . . . .14

Instrument Panel

and Courtesy Lights . . . . . . . . .15

Rear Washer/Wiper . . . . . . . . . .15

PERFORMANCE & MAINTENANCE

EngineFuel................16

Transmission . . . . . . . . . . . . . . .16

Traction & Stability . . . . . . . . . .16

OWNER PRIVILEGES™

Roadside Service . . . . . . . . . . .17

Customer Assistance . . . . . . . .17

Cadillac Online . . . . . . . . . . . . .17

TABLE F C NTENTS

Refer to your Owner Manual for more information.

Driver

Information

Comfort Entertainment Convenience Performance &

Maintenance

wner

Privileges™

Driver Information

A. Air utlets

B. Turn Signal/Multifunction Lever

C. Instrument Panel Cluster

D. Windshield Wiper Lever

E. Audio System/Navigation System

(if equipped)

F. Driver Information Center Controls

G. Audio Steering Wheel Controls

H. Climate Control

I. Traction Control Button

J. Shift Lever

K. Hazard Warning Flashers Button

L. Glove Box

INSTRUMENT PANEL

AB C D A

GI K

INSTRUMENT PANEL

CLUSTER

A. Engine Coolant

Temperature Gage

B. Tachometer

C. Speedometer

D. Fuel Gage

ABCD

SRX

Note: Some of the gages and indicators may differ from the illustration presented. The

instrument panel cluster is designed to let you know about many important aspects of your

vehicle’s operation.

It is important for you to read your Owner Manual and become familiar with the information

that is being relayed to you by the lights, gages and indicators, particularly the message center,

as well as what action can be taken to ensure your safety and to prevent damage.

❏Reviewed with Customer (Please Check Box)

Refer to your Owner Manual for more information.

Driver

Information

Comfort Entertainment Convenience Performance &

Maintenance

wner

Privileges™

Your vehicle’s Driver Information

Center (DIC) provides vehicle

information, vehicle feature

personalization and vehicle warning

messages. The DIC messages will be

shown on your instrument cluster

display.

The following DIC buttons are located

on the left side of the instrument

panel:

(Personalization): Press this

button to scroll through the following

personalization settings:

• Display Language

• Auto Door Lock

• Auto Door Unlock

• Remote Door Lock

• Remote Door Unlock

• Delay Door Lock

• Exit Lighting

• Approach Lighting

• Automatic High Beams

(if equipped)

• Chime Volume

• Park Tilt Mirrors

• Easy Exit Seat (if equipped)

• Memory Seat Recall (if equipped)

• Remote Start

• Factory Settings

(Trip/Fuel): Press this button to

scroll through the following trip and

fuel information:

• Trip A or Trip B

• Fuel Range (until empty)

• Average Fuel Economy

• Instantaneous Fuel Economy

• Fuel Used

• Timer Off

• Average Speed

• Battery Voltage

(Vehicle Information): Press

this button to scroll through the

following vehicle information:

• Oil Life Remaining

• Units (English/Metric)

• Parking Assist

• Front Tires or Rear Tires

(Current tire pressures)

• Relearn Tire Positions (Required

after tire service only; see your

Owner Manual)

• Relearn Remote ey

DRIVER INF RMATI N CENTER (DIC)

(Set/Reset): Press this button to

reset DIC information while it is

displayed or to acknowledge a

warning message.

(Menu Up/Down): Press this

button to scroll up or down the

menu items.

Personalization Settings

To personalize features:

1. Place the vehicle in Park (P).

2. Press the (Personalization)

button to enter the Feature

Settings menu and scroll through

the available features.

3. Press the (Set/Reset) button to

access the settings for the feature

being displayed.

4. Press the (Menu Up/Down)

button to scroll through the

available settings for each feature.

5. Press the (Set/Reset) button to

choose the setting being displayed

and move to the next feature.

Warnings and Messages

The DIC provides a variety of vehicle

warning messages (depending on

optional equipment) if a problem is

sensed in a vehicle system.

To acknowledge a message and clear

it from the display, press the

(Set/Reset) button. Some urgent

messages cannot be cleared from the

DIC display.

Check Engine or ther Warning

Lights with nStar®(if equipped)

If your Check Engine light, or any

other warning message appears, you

can push the blue OnStar button and

speak to a live advisor. OnStar

Advisors can access certain

diagnostic information and can tell

you how serious the problem is,

what you should do about it, or can

contact a dealer or Roadside service

for you. Refer to the OnStar Owner

Guide for details.

Comfort

MANUAL SEAT ADJUSTMENTS

(Passenger side only)

Use the bar at the front of the seat to

adjust seat position. Use the lever at

the side of the seat to raise or recline

the seatback.

P WER SEAT ADJUSTMENTS

The power seat controls are located

on the outboard sides of the front

seats.

SRX

Note: Your vehicle’s warning messages

provide critical information that can

prevent damage to your vehicle. Review

your Owner Manual to become familiar

with the information displayed and the

action required.

❏Reviewed with Customer (Please Check Box)

Refer to your Owner Manual for more information.

Driver

Information

Comfort Entertainment Convenience Performance &

Maintenance

wner

Privileges™

Power Seat Adjustments

Use the horizontal control (A) to:

• Move the seat forward or

rearward by sliding the control

forward or rearward.

• Move the seat up or down by

moving the entire control up or

down.

• Raise or lower the front or rear

part of the seat cushion by moving

the front or rear of the control up

or down.

Seatback Adjustments

Use the vertical control (B) to:

• Recline the seatback by tilting the

top of the control rearward.

• Bring the seatback forward by

tilting the top of the control

forward.

P WER LUMBAR

(If equipped)

The power lumbar switch is located

beneath the power seat switch

controls. Hold the control forward or

rearward to increase or decrease

support.

HEATED SEATS

(If equipped)

The following heated seat controls

are located on the front doors:

(Heated Seatback): Press this

button to turn on the heated

seatback.

(Heated Seat and Seatback):

Press this button to turn on the

heated seat and seatback.

There are three heated seat

temperature settings (high, medium

and low). Continue to press the

desired button to decrease the

temperature setting. To turn off the

feature, press the button until all

indicator lights are off.

MEM RY SEAT AND MIRR RS

(If equipped)

The memory seat controls are

located on the front doors.

Memory Recall

Press memory button 1 or 2 to recall

the memory settings for the driver’s

seat, outside mirrors and adjustable

pedals. The memory seat setting also

can be programmed to be recalled

automatically using the DIC.

To save memory settings:

1. Adjust the driver’s seat, outside

mirrors and steering wheel to a

comfortable position.

2. Press and hold button 1 or 2 until

two beeps sound.

3. Repeat these steps for a second

driver.

Easy Exit Seat

With the vehicle in Park (P), press the

(Easy Exit Seat) button to recall

the exit position for the driver’s seat.

Press the button again to move the

seat back farther. The easy exit seat

also can be programmed to move

automatically using the DIC.

SEC ND-R W SEAT

Adjusting the Seat

An adjustment lever to move the seat

forward or rearward is located under

each side of the 60/40 seat. After

adjustment, move the seat back and

forth to make sure it locks into place.

THIRD-R W ACCESS

The right side of the second-row

60/40 seat has an easy entry feature

to make it easier to get into and out

of the third-row seat, if equipped.

To operate the easy entry seat:

1. Pull the release lever located on

the top of the seat upward.

2. Tilt the seatback forward by

pulling the top of the seat

forward.

3. Pull upward on the release lever

located on the back of the seat

and rock forward until it stops.

P WER THIRD-R W SEAT

(If equipped)

The third-row seat includes a power-

folding feature to provide additional

cargo space. Before the seat can be

folded, the headrests must be

removed and stored.

Removing Headrests

1. Press the button on top of the

seatback below the headrest and

pull up on the headrest.

2. Open the storage compartment

cover behind the seat and insert

the headrest posts through the

slats in the carpet.

3. Position and snap the headrests in

the storage tray provided.

The seatback will not fold all the way

down if the headrests are not

removed.

Folding/Unfolding Seat

Before folding or unfolding the third-

row seat,

all

of the following

conditions must be met:

• The vehicle must be in Park (P) and

not have a low battery.

• The liftgate or right-side rear

door must be open.

S R X

❏Reviewed with Customer (Please Check Box)

Refer to your Owner Manual for more information.

Driver

Information

Comfort Convenience Performance &

Maintenance

wner

Privileges™

• The carpet seatback panel must be

folded and attached to itself.

• The ignition must be in ON or

ACC. If not, pressing the Unlock

button on the key fob or door

three

times will enable power

folding or unfolding for two

minutes.

Two buttons are located on the

right- side panel behind the third-

row seat. One button (A) folds and

raises the seat and another button (B)

changes the seatback angle.

The other button

seat is located on

the right-side trim

panel behind the

second-row seat.

Press and hold either folding button

to fold or unfold the seat.

After the seat is folded, the panel on

the back of the seat must be flipped

forward to create a flat floor space.

Before returning the seat to its

upright position, the panel must be

returned to its folded position.

CHILD RESTRAINTS (LATCH)

Your vehicle is equipped with LATCH

anchors, and may have top tethers

for use with a LATCH compatible

child restraint. If your child restraint

is not compatible with the LATCH

system, you may still use it by

installing the child restraint with the

seat belt system.

Choose a child restraint that is

appropriate for the child’s age and

size (weight and height).

See Section 1 of your Owner Manual

for more information.

CLIMATE C NTR L

The dual-zone climate control system

can be operated manually or can be

set to automatically adjust to the

individual settings of the driver and

front seat passenger.

Automatic peration

In the automatic mode, the system

adjusts the airflow, fan speed, air

conditioning and recirculation

functions to reach and maintain the

set temperature(s).

To set the automatic mode:

1. Turn the Fan knob to the AUTO

position.

2. Turn the airflow knob to the AUTO

position.

3. Adjust the temperature to a

comfortable setting using the

temperature arrow buttons.

Entertainment

Manual peration

Use the following controls to operate

the system manually:

( n/ ff): Press this button to turn

the climate control system on or off.

(Fan): Turn the Fan knob to

increase or decrease fan speed.

(Air Conditioning): Press the Fan

knob to turn the air conditioning on

or off.

Airflow Control: Turn the airflow

control knob to the following

positions to change the direction of

the airflow.

(Vent): Directs air to the

instrument panel outlets.

(Bi-Level): Directs air to the

instrument panel outlets and floor

outlets.

(Floor): Directs air to the floor

outlets.

(Defog): Directs air to the

windshield, side window outlets and

floor outlets.

(Defrost): Directs most of the air

to the windshield and some air to the

side window outlets.

(Rear Window Defogger): Press

the airflow control knob to turn the

rear window defogger on or off.

Temperature Control: Press the

arrow buttons next to the Fan knob

to adjust the driver’s temperature

setting, and press the arrow buttons

next to the airflow control knob to

adjust the passenger’s temperature

setting.

(Recirculation): Press this

button to recirculate inside air and

keep outside air from entering the

vehicle. Recirculation will not

function in defog or defrost mode.

PASS (Passenger’s Climate Control):

Press this button to turn the front

passenger’s climate control system

on or off.

REAR AIR C NDITI NING

(If equipped)

The rear air conditioning system

provides air conditioning to the

second- and third-row occupants.

The system includes four air outlets:

two over the outboard second-row

seats and two more near the cargo

area or third-row seat (if equipped).

The system can be controlled from

the front overhead console or it can

be placed in the AUX mode to allow

rear passengers to control the system

from the second-row overhead

console.

SRX

Altri manuali per SRX 2008

Indice

Altri manuali Cadillac Automobile

Cadillac

Cadillac ESCALADE - BROCHURE 2009 Manuale utente

Cadillac

Cadillac ATS 2013 Manuale utente

Cadillac

Cadillac SRX 2013 Manuale utente

Cadillac

Cadillac 2014 XTS Manuale utente

Cadillac

Cadillac 2014 ELR Manuale utente

Cadillac

Cadillac 2004 XLR Manuale utente

Cadillac

Cadillac 1995 Eldorado Manuale utente

Cadillac

Cadillac 2013 XTS Manuale utente

Cadillac

Cadillac 2004 SRX Manuale utente

Cadillac

Cadillac XT4 2019 Manuale utente

Cadillac

Cadillac 2014 XTS Manuale utente

Cadillac

Cadillac 1933 V8 Manuale utente

Cadillac

Cadillac 1998 Catera Manuale elenco delle parti

Cadillac

Cadillac Escalade 2016 Manuale utente

Cadillac

Cadillac 2013 XTS Manuale utente

Cadillac

Cadillac 2004 Seville Guida di riferimento

Cadillac

Cadillac 2003 Seville Manuale utente

Cadillac

Cadillac STS 2005 Guida di riferimento

Cadillac

Cadillac ATS 2017 Manuale utente

Cadillac

Cadillac CTS-V COUPE 2014 Manuale utente

Cadillac

Cadillac 2011 Escalade Hybrid Manuale utente

Cadillac

Cadillac Calais 1969 Guida del prodotto

Cadillac

Cadillac ATS 2013 Manuale utente

Cadillac

Cadillac 2014 Escalade ESV Manuale utente

Manuali Automobile popolari di altre marche

Toyota

Toyota 2000 Tundra Manuale utente

CITROËN

CITROËN DS4 DSign Manuale utente

Lexus

Lexus 2015 CT 200h Manuale utente

Mercedes-Benz

Mercedes-Benz M-class ML 55 AMG Manuale utente

Porsche

Porsche Boxster S Manuale utente

GMC

GMC 2010 Savana 1500 Cargo Manuale utente

KIAM

KIAM SPORTAGE 2014 Manuale elenco delle parti

GMC

GMC 2013 Terrain Istruzioni per il montaggio

GMC

GMC T-Series 1999 Manuale utente

Mercury

Mercury 1998 Mystique Manuale utente

Mercury

Mercury 2007 Mariner Manuale utente

Mazda

Mazda 2007 Mazdaspeed 3 Guida

Mazda

Mazda 2014 CX-5 Manuale utente

GMC

GMC Chevrolet Express 2022 Manuale utente

GMC

GMC 1997 Jimmy Manuale utente

Chevrolet

Chevrolet 2012 Malibu Manuale utente

Skoda

Skoda FABIA RS - ANNEXE 118 Manuale utente

Seat

Seat toledo Manuale utente
