OWNER’S MANUAL PAG.2

Dear Customer,

We would like thank you for your preference. Your new

espresso machine combines advanced technology

and attractive, innovative design.

You will experience all the benefits of a brand new

concept in coffee making that lets you prepare your

favourite coffee by simply inserting a coffee capsule

and pressing a button. Enjoy a range of coffee

possibilities including light, medium and strong coffee.

IMPORTANT SAFEGUARDS

When using electrical appliances, basic safety precautions should always be

followed, including the following:

1. Read all Instructions.

2. Do not touch hot surfaces. Use handles or knobs.

3. To protect against fire, electric shock and injury to persons do not immerse the

appliance body and/or the cord and/or the plugs in water or other liquid.

4. Close supervision is necessary when the appliance is used by or near children.

5. Unplug from outlet when not in use and before cleaning. Allow to cool before

putting on or taking off parts, and before cleaning the appliance.

6. Do not operate any appliance with a damaged cord or plug or after the

appliance malfunctions, or has been damaged in any manner. Return appliance

to the nearest authorized service facility for examination, repair or

adjustment.

7. The use of accessory attachments not recommended by the appliance

manufacturer may result in fire, electric shock or injury to persons.

8. Do not use outdoors.

9. Do not let cord hang over edge of table or counter, or touch hot surfaces.

10. Do not place on or near a hot gas or electric burner, or in a heated oven.

11. Always attach plug to appliance first, then plug cord into the wall outlet. To

disconnect, turn any control to “off”, then remove plug from wall outlet.

12. Do not use appliance for other than intended use.

Components

Control panel

Capsule holder

Lever (metal)

Drip tray with grating

Shelf for cups

Water tank

Steam/hot

water control knob

Steam wand

Power cable

Push-buttons and their respective functions (from left to right)

ON/OFF button

Except for the ON/OFF button,

all buttons incorporate an indicator light.

Steam fonction switch

Strong coffee selection button

Medium coffee selection button

Caffè lungo selection button

Text contained in this booklet has been accurately checked through. However, should

any printing mistakes be found, you are kindly requested to inform the manufacturer.

As part of our eort to constantly improve our products, we reserve the right to make

any amendments to and update this publication without prior notice. No part of this

booklet may be reproduced in any way of form, without the prior permission of the

manufacturer.

All instructions that are important for user safety are marked with the symbol

This coee-machine is equipped with safety devices. To prevent accidents or

damage, you are strongly advised to read all the notices and to use the machine

according to the instructions given in this manual. Retain this manual in a safe place

for future reference. If the coee machine is transferred to another user, the owner’s

manual should be supplied to the new owner with the appliance.

Intended use

The coee machine is designed to be used with "CAFFITALY SYSTEM" capsules only and for:

• Coee making

• Frothing milk and making cappuccino

• Dispensing hot water

Technical data

Rated voltage 220-240V

Power 950 Watt

Protection class I

Operating temperature

The appliance should be disposed of in accordance with the relevant

laws on the disposal of electrical equipment. For more information, enquire

with the relevant oce.

Electrical hazards

• To prevent electric shock, do not immerse the appliance, plug or power cable in water.

• Do not use the coffee-machine out in the open.

• Connect the machine to a power outlet with grounding system. The voltage must correspond to

the voltage specified in the data plate under the machine.

• Do not use the coffee machine if the appliance itself, the power cable or the plug is damaged

or after the machine has been knocked down.

• Do not make any alterations to the coffee machine or power cable. The coffee machine should

only be repaired by authorized service centres or qualified personnel to avoid any risks resulting

from inappropriate repair.

• The machine should be sited in a place that is inaccessible to children.

• Never leave the machine ON while unattended.

Always remove the power cable from the power outlet:

•Before removing or re-installing the water tank

•To fill the water tank

•In the event of a malfunction

•When the coffee machine is not being used for long periods of time

•Before cleaning the machine.

Do not pull the power cable to disconnect the plug from the power outlet.

Precautions against burns

• Steam and/or hot water can cause burns.

Do not aim the steam jet toward yourself and/or other people, animals, materials that are sensitive

to high temperatures and/or to humidity.

In the event that boiling water and/or steam escapes, beware of the danger of burns!

Do not touch the hot parts of the coffee machine, i.e. the steam wand. Use the steam function or

froth function only if the steam wand is immersed in a suitable container.

• When coffee is being made, water is pushed at high pressure through the coffee capsule in the

capsule holder. Always ensure, before coffee is dispensed, that the capsule holder is correctly

introduced and that the lever is pulled down completely.

• Do NOT lift the stop lever or remove the capsule-holder while coffee is being dispensed.

Safety notice – cutting hazard

Two sharp spikes are fitted in the capsule holder and capsule holder support. The purpose of the

spikes is to pierce the coffee capsule at the top and at the bottom when the capsule is introduced

in the capsule holder. Should you need to move the coffee machine to another location, you are

strongly advised to grab it from the casing.

Safety instructions

Caution. Follow the instructions given below in order to prevent damage to the machine:

• Do not install or store the machine close to sources of heat.

• Rest the machine on a level surface that is resistant to dampness and heat.

The coffee machine is fitted with anti-slip feet. Beware that worktops are coated or finished with a

variety of different materials and protective products, some of which may contain aggressive

substances that are likely to damage or soften the feet. If in doubt, place an anti-slip mat under the

machine.

• Do not expose the coffee machine to temperatures lower than , as the water remaining

inside the water heating system may freeze and cause damage to the appliance.

• Route the power cable in such a way as to avoid the risk of being caught up in it.

Keep the power cable away from sharp edges and sources of heat.

• Use cold tap water only to fill the water tank.

Use fresh water at all times. Do not use fizzy mineral water or other liquids.

• To prevent the pump from working with no load and overheating, the water tank should never

be left without water.

Caution

The manufacturer accepts no liability for damage caused by:

• Improper use outside the defined operating parameters;

• Repairs carried out by anyone other than authorized service centres;

• Tampering with the power cable;

• Tampering with any component of the machine;

•Use of non original spare parts and accessories;

In such cases the warranty shall be null and void.

Unpacking:

Check the appliance for damage after you have taken it out of its packing.

If in doubt, do not use the appliance and contact the retailer.

The packaging materials should never be left within the reach of children since these materials can

pose a hazard. They should be disposed of or stored in accordance with local environment protection

regulations.

Assembling the parts of the machine that are supplied separately.

Essential and safety components of the coffee machine are factory-assembled. Some secondary

elements of the appliance may be supplied in a separate packaging. The user should assemble

these parts in accordance with the assembly instructions given in this booklet.

Preliminary operations

Caution: rest the coffee machine on a level

surface that is resistant to dampness and heat, in

a place that is out of the reach of children.

•Introduce the capsule holder into the coffee machine

(Fig. 1)

•Pull the lever down completely (Fig. 2)

•Ensure that the steam and hot water dispenser knob is

in the closed position. Rotate the knob fully clockwise.

(Fig. 3)

• Ensure that the steam wand is locked. The knurled ring

should be tightened in the direction shown by the arrow.

(Fig. 4)

•Connect the power cable plug to a power outlet with

grounding system.

The power outlet should be easily accessible.

Before making your first cup of coffee, read these instructions

and the information regarding the brand new technology

incorporated in this appliance.

This coffee machine uses a single-cup capsule concept.

The appliance operates with "CAFFITALY SYSTEM"

capsules of fresh aromatic coffee. To provide a full,

delicious aroma, one capsule makes one cup of coffee.

Fig. 1

Fig. 2

Fig. 3

Fig. 4
